VLT® Servo Drive System ISD 511
Operating Guide
3.
Right-click on the network interface used for fieldbus communication and select Properties.
4. If the TCP/IPv6 is available for the network interface, disable it.

6.6.4.4 Direct Communication

6.6.4.4.1 Overview
For Ethernet-based fieldbus communication (direct communication), the VLT
face on the VLT Servo Toolbox host system. Do not use this network interface simultaneously for any other communication.
®
STATUS PSM
DEV STATUS DAM STATUS DAM
DEV DEV
STO STO STO
NET ST NET ST NET ST
AUX AUX
LINK/ACT LINK/ACT LINK/ACT
X1 X1 X1
X2 X2 X2
X3 X3
1
LCP LCP LCP
PSM DAM DAM
510 510 510
Illustration 48: Logical View of Direct Ethernet-based Fieldbus Communication
A Ethernet-based fieldbus communication
B VLT Servo Toolbox host system
®
-
The logical view only shows the connectivity from a high-level software perspective and does not reflect the actual physical
topology of the network.
6.6.4.4.2 Network Settings for Direct Communication with Ethernet POWERLINK®
Disable all network protocols except TCP/IPv4 on the network interface used for direct Ethernet POWERLINK
prevents other PC software or the operating system using this network interface for other tasks, such as file and printer sharing and
network discovery. Disabling these protocols reduces the number of non-relevant packets sent over the network interface and thus
reduces the overall network load.
6.6.4.4.3 Disabling Unused Protocols on the Network Interface on the PC
Procedure
1. Open the Network and Sharing Center.
2. On the left, click on Change adapter settings.
3.
Right-click on the network interface used for fieldbus communication and select Properties.
4.
Uncheck all checkboxes except the one for Internet Protocol Version 4 (TCP/IPv4).
80 | Danfoss A/S © 2023.08
2 n
. . .
A
B
W A R N I N G
Servo Toolbox must use a dedicated network inter-
®
AQ377148425069en-000101 / 130R1213
Commissioning
communication. This
®
