VLT® Servo Drive System ISD 511
Operating Guide
Illustration 22: Grounding for Electrical Safety
• To comply with CE requirements, ensure a minimum ground wire cross-section of at least 16 mm
comply with UL requirements, ensure a minimum ground wire cross-section of 6 AWG (minimum 60 °C, Cu).
- If a PSM 510 module with 10 kW is used, the cable cross-section can be reduced to 10 mm
with CE requirements and 8 AWG (minimum 60 °C, Cu) to comply with UL requirements.
• Keep the ground wire connections as short as possible.
• Follow the wiring requirements in the VLT® Multiaxis Servo Drive System MSD 510 Operating Guide.
-
If 2 separate backlinks are used (connected via 1 or 2 pairs of EXM 510 modules), the 2 grounding bars must also be connec-
ted together with a 16 mm

5.4 Grounding for EMC-Compliant Installation

• Establish electrical connection between the cable shield and the enclosure using the I/O shielding plate on each module.
48 | Danfoss A/S © 2023.08
N O T I C E
2
(6 AWG) cable cross-section.
Electrical Installation
2
(minimum 70 °C, Cu). To
2
(minimum 70 °C, Cu) to comply
AQ377148425069en-000101 / 130R1213
