VLT® Servo Drive System ISD 511
Operating Guide

9.3.14 Brake Chopper Error

This fault applies to the PSM 510.
Possible causes
• Faulty brake chopper.
• Brake chopper power exceeds the power cycle limit.
• Incorrect parameterization.
Troubleshooting
• Check the parameterization of the brake chopper.
• Check the brake chopper connection.
• Measure the resistance of the brake chopper and compare it with the parameter settings.

9.3.15 Internal Fan Error

This fault applies to PSM 510.
Possible causes
• Fan is not mounted.
• Fan is blocked.
Troubleshooting
• Check if the fan is blocked.
• Check the fan cables for proper connection or damage.

9.4 Error Codes for ISD 511 Servo System

9.4.1 No error (0x0000 / 0x0)

This error code is valid for PSM 510, DAM 510, ACM 510, and ISD 511.
Table 27: No error (0x0000 / 0x0)
Code PROFINET code
®
0x0000 0x0

9.4.2 Generic application error (0x1000 / 0x100)

This error is valid for PSM 510, DAM 510, ACM 510, and ISD 511.
Table 28: Generic err (0x1000 / 0x100)
Code PROFINET code
®
0x1000 0x100

9.4.3 High cont. power overload (0x2313 / 0x161)

This error is valid for PSM 510.
Table 29: High cont. power overload (0x2313 / 0x161)
Code PROFINET code
®
0x2313 0x161

9.4.4 Continuous power overload (0x2314 / 0x162)

This error is valid for PSM 510.
Danfoss A/S © 2023.08
Name Severity (warning/error/trip lock)
No error Error
Name Severity (warning/error/trip
lock)
Generic application error Error
Name Severity (warning/error/trip
lock)
High cont. power Warning, error
overload
Description
No error.
Description
Generic application error.
Description
High continuous power
overload error.
AQ377148425069en-000101 / 130R1213 | 101
Diagnostics
LCP name
–
LCP name
generic err
LCP name
high pwr ovld
