VLT® Servo Drive System ISD 511
Operating Guide
Table 85: Fan feedback inconsistent (0xFF21 / 0x145)
Code PROFINET
®
code
0xFF21 0x145
9.4.60 Fan lifetime critical (0xFF22 / 0x15A)
This error is valid for PSM 510.
Table 86: Fan lifetime critical (0xFF22 / 0x15A)
Code PROFINET code
®
0xFF22 0x15A
9.4.61 Timing violation 1 (0xFF60 / 0x115)
This error is valid for ISD 511.
Table 87: Timing violation 1 (0xFF60 / 0x115)
Code PROFINET code
®
0xFF60 0x115
9.4.62 Timing violation 2 (0xFF61 / 0x116)
This error is valid for ISD 511.
Table 88: Timing violation 2 (0xFF61 / 0x116)
Code PROFINET code
®
0xFF61 0x116
9.4.63 Timing violation 3 (0xFF62 / 0x117)
This error is valid for ISD 511.
Table 89: Timing violation 3 (0xFF62 / 0x117)
Code PROFINET code
®
0xFF62 0x117
9.4.64 Timing violation 4 (0xFF63 / 0x118)
This error is valid for ISD 511.
Table 90: Timing violation 4 (0xFF63 / 0x118)
Code PROFINET code
®
0xFF63 0x118
9.4.65 Timing violation 5 (0xFF64 / 0x119)
This error is valid for ISD 511.
Danfoss A/S © 2023.08
Name Severity (warning/error/
trip lock)
Fan feedback in- Warning
consistent
Name Severity (warning/error/
trip lock)
Fan lifetime criti- Warning
cal
Name Severity (warning/error/trip lock)
Timing violation 1 Trip lock
Name Severity (warning/error/trip lock)
Timing violation 2 Trip lock
Name Severity (warning/error/trip lock)
Timing violation 3 Trip lock
Name Severity (warning/error/trip lock)
Timing violation 4 Trip lock
Description
Internal fan fault.
Internal fan not running/mounted.
Description
The theoretical lifetime of the fan
has been exceeded.
Description
Contact Danfoss.
Description
Contact Danfoss.
Description
Contact Danfoss.
Description
Contact Danfoss.
AQ377148425069en-000101 / 130R1213 | 113
Diagnostics
LCP name
fan feedback
LCP name
fan lifetime
LCP name
timing err 1
LCP name
timing err 2
LCP name
timing err 3
LCP name
timing err 4
