Table 70: Configuration parameters limits error (0x6383 / 0x164)
Code PROFINET Name
®
code
0x6383 0x164 Configuration parame-
ters limits error
9.4.45 Power EEprom configuration error (0x6384 / 0x166)
This error is valid for PSM 510, DAM 510, ACM 510, and ISD 511.
Table 71: Power EEprom configuration error (0x6384 / 0x166)
Code Name
0x6384 0x166 Power EEprom con-
figuration error
9.4.46 Brake chopper failure (0x7111 / 0x141)
This error is valid for PSM 510.
Table 72: Brake chopper failure (0x7111 / 0x141)
Code PROFINET Name
®
code
0x7111 0x141 Brake chop-
per failure
9.4.47 Brake chopper overcurrent (0x7112 / 0x167)
This error is valid for PSM 510.
Table 73: Brake chopper overcurrent (0x7112 / 0x167)
Code PROFINET
®
code
0x7112 0x167
9.4.48 Brake chopper module overload (0x7181 / 0x142)
This error is valid for PSM 510.
Table 74: Brake resistor maximum power limit (0x7181 / 0x142)
Code PROFINET Name
®
code
0x7181 0x142 Brake chop-
per module
overload
9.4.49 External brake chopper overload (0x7182 / 0x143)
This error is valid for PSM 510.
110 | Danfoss A/S © 2023.08
Severity (warning/
error/trip lock)
Trip lock
Severity (warning/
error/trip lock)
Trip lock
Severity (warning/
error/trip lock)
Warning, error
Name Severity (warning/error/
trip lock)
Brake chopper Trip lock
overcurrent
Severity (warning/
error/trip lock)
Warning, error
Description
≥1 parameter in the configuration
parameter set is out of limits.
Description
The power device EEprom is corrupt or in-
compatible with this control board. Contact
Danfoss.
Description
The brake chopper is monitored during oper-
ation.
A brake failure has been detected by the
brake check function.
Description
The brake chopper current ex-
ceeds the limit.
Description
The power load of the brake chopper is monitored
during operation. This error appears when the maxi-
mum power limit of the brake chopper module is
reached.
Diagnostics
LCP name
conf par lim
LCP name
conf par EE-
PROM
LCP name
brake ch fail
LCP name
brake ch over-
curr
LCP
name
mod ovl
