VLT® Servo Drive System ISD 511
Operating Guide
11.3.2 Dimensions of Flange Screw for Mounting the ISD 511 Servo Drive
46
(1.8)
6 40
(0.23) (1.6)
Ø10
(0.4)
Ø5.4 ±0.1
(0.2 ±0 )
3
(0.1)
Illustration 71: Flange Screw Dimensions
11.3.3 Dimensions of Power Supply Module (PSM 510)
All dimensions are in mm [in].
137.3
[5.41]
16 100 21.3
[0.63] [3.94] [0.84]
STATUS PSM
DEV
SVS ST
NET ST
LINK/ACT
X1
X2
LCP
Illustration 72: Dimensions of PSM 510
11.3.4 Dimensions of Decentral Access Module (DAM 510)
All dimensions are in mm [in].
132 | Danfoss A/S © 2023.08
5
14 (0.2)
(0.6)
M6 x 1
(0.2)
270
[10.63]
Specifications
25 50 25
[0.98] [1.97] [0.98]
2xØ5.2
[0.2]
2xØ5.2
[0.2]
AQ377148425069en-000101 / 130R1213
