Table 122: Pin Assignment of LCP Connector
Pins Description
1 Not connected
2 /LCP RST
3 LCP RS485
4 /LCP RS485
5 GND
6 VCC
-
Only PELV potential can be connected to the LCP input.
11.6.7 AC Mains Connector
The AC mains connector is on the bottom of the Power Supply Module (PSM 510).
Illustration 83: AC Mains Connector
Table 123: Pin Assignment of AC Mains Connector
Descrip- Notes
Pins
tion
(left to
right)
1 L3 Used to connect
L1/L2/L3
2 L2
3 L1
11.6.7.1 Mains Cable Cross-Sections for PSM 510
Table 124: Mains Cable Cross-Sections for PSM 510
Minimum cable cross-section for CE
Minimum cable cross-section for UL
11.6.8 Relay Connector
The relay connector is used for a user-defined reaction and is located as follows:
140 | Danfoss A/S © 2023.08
Notes
–
Reset
Positive RS485 signal
Negative RS485 signal
GND
5 V supply for LCP
N O T I C E
Rating/parameter
Nominal voltage: 400–480 V AC ±10%
Nominal power: 30 kW
Maximum cross-section: 16 mm
Conductor cross-section range 0.75–16 mm
PSM 510 (10 kW)
2
4 mm
(minimum 70 °C, Cu)
AWG 10
(minimum 60 °C, Cu)
Rating/parameter
–
Active at ≦0.5 V
Speed:
38.4 kBd
The levels fulfill the RS485 specification.
–
5 V ±10% at 120 mA maximum load
2
(AWG 4)
2
, solid or flexible (AWG 18–AWG 4)
PSM 510 (20 kW)
2
16 mm
(minimum 70 °C, Cu)
AWG 6
(minimum 60 °C, Cu)
AQ377148425069en-000101 / 130R1213
Specifications
PSM 510 (30 kW)
2
16 mm
(minimum 90 °C, Cu)
AWG 4
(minimum 75 °C, Cu)
