VLT® Servo Drive System ISD 511
Operating Guide
Table 35: AUX user limit current warning (0x2394 / 0x128)
Code PROFINET
®
code
0x2394 0x128

9.4.10 AUX supply failure (0x2395 / 0x129)

This error is valid for DAM 510.
Table 36: AUX supply failure (0x2395 / 0x129)
Code PROFINET
®
code
0x2395 0x129

9.4.11 Current overload trip (0x2396 / 0x15C)

This error is valid for DAM 510.
Table 37: Current overload trip (0x2396 / 0x15C)
Code PROFINET code
®
0x2396 0x15C

9.4.12 Power overload trip (0x2397 / 0x12B)

This error is valid for PSM 510.
Table 38: Power overload trip (0x2397 / 0x12B)
Code PROFINET code
®
0x2397 0x12B

9.4.13 Mains phase loss (0x3130 / 0x12F)

This error is valid for PSM 510.
Table 39: Mains phase loss (0x3130 / 0x12F)
Code PROFINET
™
code
0x3130 0x12F

9.4.14 DC link overvoltage (0x3210 / 0x103)

This error is valid for PSM 510, DAM 510, ACM 510, and ISD 511.
Danfoss A/S © 2023.08
Name Severity (warning/
error/trip lock)
AUX user limit cur- Warning
rent warning
Name Severity (warning/error/
trip lock)
AUX supply fail- Error
ure
Name Severity (warning/error/trip
lock)
Current overload Error
trip
Name Severity (warning/error/trip
lock)
Power overload trip Error
Name Severity (warning/
error/trip lock)
Mains Error
phase loss
Description
Current on the AUX line has reached
the user-defined limit for warning.
Description
AUX supply failure indicated by
hardware circuit..
Description
Current overload trip error.
Description
Power overload trip error.
Description
Mains phase loss detected.
This occurs when a phase on mains is missing, or
when the mains is imbalanced.
AQ377148425069en-000101 / 130R1213 | 103
Diagnostics
LCP name
AUX curr
warn
LCP name
AUX supply fail
LCP name
curr ovld trip
LCP name
pwr ovld trip
LCP name
phase loss
