Illustration 91: AUX Connector
Table 130: Pin Assignment of AUX Connector
Description Notes
Pins
(left to
right)
1
AUX+ Used to connect the AUX output
from the Decentral access Module
(24/48 V)
(DAM 510) to the hybrid cable for
the servo drive line.
2 AUX– (GND)
-
Only PELV potential can be connected to the AUX output.
11.6.12 External Encoder Connectors
• DAM 510: E DAM
5
9 6
Illustration 92: External Encoder Connector
Table 131: External Encoder Connectors
Connector Description
name
E DAM Used to connect the ex-
ternal encoder to
DAM 510.
Danfoss A/S © 2023.08
N O T I C E
1
Pins Ratings/Notes
See Table
Nominal voltage: 24 V DC, isolated (see
132.
Nominal current: Depends on the number of servo drives in the applica-
tion.
Maximum current: 150 mA (see
Fulfill the following specifications:
•
Rating/parameter
Nominal voltage: 24/48 V DC ±10%
Nominal current: Depends on the number of servo drives in the
application.
Maximum current: 15 A
Conductor cross-section range: 0.2–2.5 mm
Plug terminal tightening torque: 0.5–0.6 Nm (4.43–5.31 in-lb)
Table
BISS/SSI
Specifications
2
(AWG 24–AWG 12)
Table 132)
132)
