MUTOH Valuevet VJ-628X Maintenance Manual page 407

Exploded View Cursor
Exploded View Cursor
1 2
A-40
A-42
A-133
A-132
Cutter Solenoid SpringAssy
DF-49062
A-131
A-135
A-129
A-127
Cutter Spring
DG-43484
1 2
407P.11-407
3
A-41
A-38 A-33
A-32
A-36
A-126
PG Origin Sensor Cable Assy
DG-43315
A-43
A-130
Cutter Solenoid Assy
DF-42234
CR HP Sensor, Lever Sensor
DF-49471
CR J11
A-138
A-137
A-140
A-134
P-Edge Sensor Assy
DG-43319
A-139
Cutter SOL Cable Assy
DG-43318
A-128
A-136
A-142
3
4 5
A-3
A-37
A-2
A-129
CR J12
A-34
A-15
A-48
A-141
CR Encoder Assy
DG-42947
A-47
CR J17
A-50
A-51
CR J15
A-23
A-21
A-22
Roller Arm Assy
DF-49065
4 5
6 7
Carriage Assy
DG-44688
A-13
A-28
A-14
A-49
A-1
A-36
A-29
A-20
A-23
Roller Arm Assy
DF-49065
A-19
A-21
2015.5.20 Rev.A
A-22
6 7
VJ628XE-M-00
8
(A part of following page is included)
A-8
A-9
A-7
A-8
Mini Latch S Assy
DG-44689
A-32
A-33
A-35
A-39
Cursor
Model : VJ-628X
8
