4.3 Working with MUTOH Service Assistance Software
(2) List of adjustment operations after replacing the board for each board replacement pattern
sequen Adjustment Items
ce
1
Requiring Printer Identification DATA (mpi file）
2
Resending Authorization code (ulk file）
3 Updating (*mpi) on the MB-web
4 Resetting Smart/C
5 Inputting Head rank
6 Adjusting Paper edge sensor
7 Adjusting Paper Rear Sensor
8 Setting Ink-NOT Filled Flag
9 Confirming Head nozzles
10 Adjusting Uni-D/Bi-D
11 Adjusting Top & Side
12 Test Printing
4.3.10 Board Replacement Wizard
Refer to
"4.3.12Acquiring Printer Identification Data
"4.3.13Sending Authorization code
Printer Activation guide
Printer Activation guide
"(2)Head Rank
"5.6.1Rear/ Edge Sensor Adjustment
"5.6.1Rear/ Edge Sensor Adjustment
"(5)Charge Flg
"5.6.2Head Nozzle Check Menu
"5.6.5Uni-D/ Bi-D Adjustment Menu
"5.6.7Margin adjustment Menu
"5.8Sample printing Menu
VJ628XE-M-00
Board replacement pattern
① ② ③ ④ ⑤
－ － ● ● ●
－ － ● ● ●
● ● ● ● ●
－ － ● ● ●
－ － － ● －
● ● ● ● ●
● ● ● ● ●
－ － － ● －
● ● ● ● ●
－ － － ● －
－ － － ● －
● ● ● ● ●
● : Need to work ／ － : Need not work
⑥
●
●
●
●
●
●
●
●
●
●
●
●
