Page 3: Important Notice
VJ-1324 OPERATION MANUAL Important Notice For Users in Europe The CE marking is a mandatory European marking for certain product groups to indicate conformity with the essential health and safety requirements set out in European Directives. By affixing the CE marking, the manufacturer, his authorized representative, or the person placing the product on the market or putting it into service ensures that the item meets all the essential requirements of all applicable EU directives and that the applicable conformity assessment procedures have been applied.
Page 4 • The product and the contents of this publication may be changed without prior notification. • MUTOH INDUSTRIES LTD. has made the best efforts to keep this publication free from error, but if you find any uncertainties or misprints, please call us or the shop where you bought this equipment.
Page 5: Warranty Limitations
VJ-1324 OPERATION MANUAL Warranty Limitations 1. MUTOH INDUSTRIES LTD. warrants part repair or replacement as a sole measure only if a failure is found in the system or in the materials and workmanship of the product the seller produced. However, if the cause of failure is uncertain, decide the action after due mutual consultation.
Page 6: About This Manual
Explains operating procedures along with unpacking, installation and preparation before use. Operation Manual (this manual) Purpose and Target Readers This manual explains preparations before use and operation procedures for MUTOH Full Color Ink Jet Printer VJ-1324 This manual is prepared for the owners and operators of this printer.
Page 7 VJ-1324 OPERATION MANUAL Manual Notation This section explains general cautions that must be followed in order to use this printer safely. Warning Meaning Used for dangerous situations where death or serious injury may be caused. WARNING Used for dangerous situations that may cause slight or medium injury, or when all or parts of CAUTION products are damaged.
Page 8 VJ-1324 OPERATION MANUAL...
Page 9: Table Of Contents
TABLE OF CONTENTS Safety instructions Types and meanings of warnings ......1-16 Important safety instructions .
Page 10 Table of Contents VJ-1324 OPERATION MANUAL Loading media ..........3-56 3.4.1 Loading roll media .
Page 11 VJ-1324 OPERATION MANUAL Table of Contents Operating from the operation panel ......4-135 4.4.1 Feeding media .
Page 12 Table of Contents VJ-1324 OPERATION MANUAL 5.1.19 CR Maintenance menu ......... 5-189 5.1.20 Initialization menu .
Page 13 VJ-1324 OPERATION MANUAL Table of Contents Troubleshooting Malfunctions and failures ........7-246 7.1.1 Problems in installation and introduction .
Page 14 Table of Contents VJ-1324 OPERATION MANUAL...
Page 15: Safety Instructions
VJ-1324 OPERATION MANUAL Safety instructions Safety instructions This chapter explains the installation of this printer, warning terms that operators need to know, caution items and warning labels on the printer main unit. WARNING • When installing and operating this printer, be sure to follow the directions and warnings in this book.
Page 16: Types And Meanings Of Warnings
Safety instructions VJ-1324 OPERATION MANUAL Types and meanings of warnings The warnings in the Operation Manual and the warning labels attached to the printer are categorized into three stages. Understand the meanings of the following warning terms and follow the contents (instructions) in this manual.
Page 17: Important Safety Instructions
It could lead to an electric shock or fire. Immediately turn OFF the power switch, disconnect the power plug from the electric socket, and contact your local MUTOH dealer. Wire the various cords as directed in the Operation Manual. Mistaken wiring could cause fire.
Page 18 Safety instructions VJ-1324 OPERATION MANUAL Make sure to use only the specified power supply (AC 100 V to 120 V or AC 220 V to 240 V). If a power supply other than the specified voltage is used, it could cause an electric shock and fire. Take power for the printer directly from the power socket (AC 100 V to 120 V or AC 220 V to 240 V).
Page 19 VJ-1324 OPERATION MANUAL Safety instructions When cleaning the cleaning wiper, • Do not touch the cleaning wiper and head cap unit. Head cleaning may not be performed correctly because of oil from your hands. • Make sure to wipe the print head using the cleaning stick. A wet cleaning stick may cause the print head to clog.
Page 20 Safety instructions VJ-1324 OPERATION MANUAL Move the printer maintaining a horizontal position. 1.2 Important safety instructions...
Page 21: Warning Labels
• Use cloth, water and mild detergent for removing dirt from the warning label. Avoid either organic solvents or gasoline. • It is necessary to replace the labels if they are damaged, lost or illegible. If the warning labels have to be replaced, contact your local MUTOH dealer. 1.3 Warning labels...
Page 22: Location And Type Of Warning Labels
Safety instructions VJ-1324 OPERATION MANUAL 1.3.2 Location and type of warning labels Pasting locations of the warning labels are shown in the following figure. (1) Front (2) Rear Types of warning labels 1.3 Warning labels...
Page 23: Operating Instruction Labels
Avoid either organic solvents or gasoline. • It is necessary to replace the operating instruction labels if they are damaged, lost or unreadable. If the operating instruction labels have to be replaced, contact your local MUTOH dealer. 1.4.2 Locations and Types of Operating Instruction Labels Locations of the operating instruction labels are shown in the following figure.
Page 24 Safety instructions VJ-1324 OPERATION MANUAL 1.4 Operating Instruction Labels...
Page 25: Product Overview
VJ-1324 OPERATION MANUAL Product overview Product overview This chapter explains the features of this printer along with the names and functions of each part.
Page 26: Features
Product overview VJ-1324 OPERATION MANUAL Features This section explains the main features of the printer. (1) High-speed output The new print head has realized high-speed output. For VJ-1324, the printing width of 1,361mm has been made possible. (2) Wide variety of compatible media The height of the print head is adjustable to two levels, which has made it possible to print on various paper with the width of 0.08mm to 1.3mm.
Page 27: Names Of Parts And Functions
VJ-1324 OPERATION MANUAL Product overview Names of parts and functions This section explains the names and functions of each part. 2.2.1 Front section Name Function Media loading lever Used for fixing or releasing media. Operation panel Operation condition setting, printer display and various function settings are performed.
Page 28: Rear Section
Product overview VJ-1324 OPERATION MANUAL Name Function Media cut groove Used to cut media straight. Pressurizing rollers Installed inside of the front cover. Press and hold the media when printing. Platen Installed inside of the front cover. Stabilizes the print side of the media. Maintenance cover Used to prevent the user from touching the inner mechanical section.
Page 29: Operation Panel
VJ-1324 OPERATION MANUAL Product overview Name Function Ink cartridge slot Insert the ink cartridge. Media guide Used for feeding media smoothly when the media is set or printed. Waste fluid tank Used for collecting waste ink discharged from the printer. Waste fluid valve Open and close when discharging the waste fluid from the waste fluid tank.
Page 30 Product overview VJ-1324 OPERATION MANUAL (1) Operation keys NOTE • The operation keys are assigned with different functions and names depending on printer status (Normal or Setup menu display). For details about printer status, refer to " ". 2.3 Printer status Name Normal Setup menu display...
Page 31 VJ-1324 OPERATION MANUAL Product overview (2) Display section Name Color Status Description Power lamp Blue Lamp Power ON. Lamp • Receiving and analyzing the data. blinks • Performing media initial operation. Lamp Power OFF. Error lamp Orange Lamp An error has occurred. Error content is displayed on the LCD.
Page 32 When an error requiring a restart (fatal malfunction for the printer operation) occurs, all lamps blink with an alarm. 7.2.3 Error requiring restart If the error persists even when the malfunction is fixed, contact your local MUTOH dealer. 2.2 Names of parts and functions...
Page 33: Ink Level Indicator
VJ-1324 OPERATION MANUAL Product overview 2.2.4 Ink level indicator When the “Remain Ink menu” on Display menu is set to “On”, the ink level indicator that discribes the ink or ink cartridge status is displayed on LCD monitor. 5.7 Display menu 5.7.4 Remain Ink menu •...
Page 34: Estimated Ink Level Graphic
Product overview VJ-1324 OPERATION MANUAL 2.2.4.1 Estimated Ink level graphic Indicator to display the conditions of ink/cartridges Remaining ink amount : More than 80%, less than 100% Remaining ink amount : More than 60%, less than 80% Remaining ink amount : More than 40%, less than 60% Remaining ink amount : More than 20%, less than 40%...
Page 35: Printer Status
VJ-1324 OPERATION MANUAL Product overview Printer status This section explains printer status. 2.3.1 Normal Printing is possible when media is loaded. The various functions for printing can be performed on the operation panel. 2.3.2 Setup menu display Various settings regarding printing can be made from the operation panel. The various functions for printing can be performed on the operation panel.
Page 36 Product overview VJ-1324 OPERATION MANUAL Normal [Cancel] key [Menu] key Leave the printer as it is for 3 minutes Setup Menu Display NOTE • For details on Status message, refer to " ". 7.2.1 Status messages 2.3 Printer status...
Page 37: Before Using
VJ-1324 OPERATION MANUAL Before using Before using This chapter explains necessary steps before using the printer.
Page 38: Power Cable Connection
• Do not route the power cable near heating appliances. NOTE • Contact your local MUTOH dealer in case of power cable damage. • This product is also designed for IT power distribution system with phase-to-phase voltage 230V. 3.1 Power cable connection...
Page 39 VJ-1324 OPERATION MANUAL Before using Follow the procedure below to install the power cable. 1. Make sure that the printer is turned OFF. NOTE • The power is ON when the [Power] key of the operation panel is pressed in. Press the key once again to turn OFF the power.
Page 40 Before using VJ-1324 OPERATION MANUAL 3. Insert the power cable plug firmly in the socket. WARNING • Do not pull out or insert the power plug with a wet hand. This could lead to an electric shock. • Make sure to use only the specified power supply (AC 100 V to 120 V or AC 220 V to 240 V).
Page 41 VJ-1324 OPERATION MANUAL Before using NOTE • Contact the retail outlet of purchase if the earth connection cannot be established, or if the earth connection is not given. • When the power supply of the printer is ON, do not pull out the power cable from the power socket. Whenever the plug is pulled out from the power socket, allow one minute or more before inserting the plug in the power socket again.
Page 42: Turning The Power On/Off
Before using VJ-1324 OPERATION MANUAL Turning the power ON/OFF This section explains how to turn the printer ON/OFF. 3.2.1 Turning the power ON Follow the procedure below to turn the power ON. 1. Press the [Power] key on the operation panel to turn ON the printer. •...
Page 43: Turning The Power Off
VJ-1324 OPERATION MANUAL Before using 3.2.2 Turning the power OFF Follow the procedure below to turn the printer OFF. 1. Verify the following regarding the operational condition of the product. • Printing or other operations are not in progress. • The operation panel display is Normal.
Page 44 Before using VJ-1324 OPERATION MANUAL NOTE • If the head height is set to High, "Set Height to Low" is displayed on the operation panel and the procedure to turn the power OFF stops. To restart the procedure, return the head height to Low. 4.2.5.2 When returning the print head to the original position •...
Page 45: Installing Ink Cartridges
VJ-1324 OPERATION MANUAL Before using Installing ink cartridges This section describes the procedure to install the ink cartridges and high capacity pack adapter. CAUTION • Before operation, make sure to read the Safety Data Sheet (SDS). • When handling ink cartridges, pay attention so that ink does not get into your eyes or stick to your skin.
Page 46 • For types and details of ink cartridges and ink packs, contact your local MUTOH dealer. • Do not give ink cartridges or ink packs strong shakes.
Page 47: Installing 220Ml Ink Cartridges
VJ-1324 OPERATION MANUAL Before using 3.3.1 Installing 220ml ink cartridges Follow the procedure below to install the 220ml ink cartridge. 1. Turn the printer ON. • The printer starts the initializing operation. • After the initial operation is compete, "Start Ink Charge – > E" is displayed on the operation panel.
Page 48 Before using VJ-1324 OPERATION MANUAL 4. Set the cleaning cartridge to the ink cartridge slot. • Keep mark of the cleaning cartridge facing up and insert towards the printer side. • Insert the cleaning cartridge all the way to the end of the slot. Name Cleaning cartridge Ink cartridge slots...
Page 49 VJ-1324 OPERATION MANUAL Before using NOTE • When performing head cleaning again before ink charge, press the [+] or [-] key on the operation panel to select "Yes", and press the [Enter] key to perform head cleaning. 6. Press the [Enter] key on the operation panel. •...
Page 50 If there is no improvement in the print result even after refill a small amount of ink, leave the printer unused for an hour or more. Then, refill a small amount of ink again and check the print result. If there is still no improvement, contact your local MUTOH dealer. 3.3 Installing ink cartridges...
Page 51: Installing High Capacity Pack Adapters (Option)
VJ-1324 OPERATION MANUAL Before using 3.3.2 Installing high capacity pack adapters (option) Use the optional high capacity pack adapters to use the 1000ml ink packs on this printer. Follow the procedure below to install the high capacity pack adapters. 1. Turn the printer ON. •...
Page 52 Before using VJ-1324 OPERATION MANUAL 5. Insert the high capacity pack adapters into the ink cartridge slot. NOTE • Do not insert the high capacity pack adapter into the ink cartridge slot without a cleaning fluid pack attached. The information of the remaining amount will be overwritten and the cleaning fluid pack will not be usable.
Page 53 VJ-1324 OPERATION MANUAL Before using • "Busy-Washing" is displayed on the operation panel and the printer starts head cleaning. • When head cleaning is complete, "Wash retry? No" is displayed on the operation panel. NOTE Do not remove only cleaning fluid pack while high capacity pack adapter is installed on the printer. The information of the remaining smart chip card will be rewritten and the cleaning fluid pack will not be usable.
Page 54 Before using VJ-1324 OPERATION MANUAL 10. Shake the high capacity pack adapter gently two to three times and insert it to the slot. NOTE •Do not insert the high capacity pack adapter into the ink cartridge slot without a cleaning fluid pack attached.
Page 55: The First Time
If there is no improvement in the print result even after refill a small amount of ink, leave the printer unused for an hour or more. Then, refill a small amount of ink again and check the print result. If there is still no improvement, contact your local MUTOH dealer. 3.3.3...
Page 56: Loading Media
This section explains how to load and set media, and settings for each media type. NOTE • Refer to the following for details about handling media. 4.2 Media • For details of the recommended media, contact your local MUTOH dealer. 3.4.1 Loading roll media This section describes the procedure to load the roll media.
Page 57 VJ-1324 OPERATION MANUAL Before using Follow the procedure below to load the roll media. CAUTION • When loading the roll media, place it on a flat surface such as a desk. If the roll media is loaded with the scroller up, the scroller may be damaged. 1.
Page 58 Before using VJ-1324 OPERATION MANUAL 4. Attach the movable media stopper firmly to the core of the roll media. Name Movable media stopper Roll media 5. Set the scroller on the holder with the fixed media stopper on the ink cartridge slot side. Name Scroller Fixed media stopper...
Page 59: Setting Roll Media
VJ-1324 OPERATION MANUAL Before using 3.4.2 Setting Roll Media This section explains how to set the roll media. Follow the procedure below to set the roll media. 1. Turn the printer ON. CAUTION • Do not operate the media loading lever during the initial operation or printing. The print head portion may touch the pressurizing roller portion, and cause a malfunction.
Page 60 Before using VJ-1324 OPERATION MANUAL 3. Set the roll media to the media feed slot. NOTE • If the end of the roll media is not wound tightly, wind it tightly again, and then load it. Name Roll media Media feed slot 4.
Page 61 VJ-1324 OPERATION MANUAL Before using 5. While holding the edge of the media, rewind the roll media a little by turning the scroller by hand and eliminate any slack or slant. Name Roll media Scroller 6. Lower the media loading lever. Name Media loading lever NOTE...
Page 62 Before using VJ-1324 OPERATION MANUAL 7. Close the front cover. Name Front cover • The User type setup menu is displayed on the operation panel. 3.4.3 Setting the User Type Setting To change the media type, follow " " and set the media type. 3.4 Loading media...
Page 63: Setting The User Type Setting
VJ-1324 OPERATION MANUAL Before using 3.4.3 Setting the User Type Setting This section explains how to set the user type setting. Follow the procedure below to set the user type setting. 1. Turn ON the printer and load media. • After loading the media, the printer enters the user type setting menu.
Page 64 Before using VJ-1324 OPERATION MANUAL 3. Press the [Enter] key on the operation panel. • The user type setting is set. • "Media initial" is displayed on the operation panel and media initialization starts. NOTE • If the following operations are performed in the user type setting menu, the printer starts media initial operation without specifying a user-defined setting.
Page 65: Test Print
VJ-1324 OPERATION MANUAL Before using Test print Follow the procedure below to perform Test printing to confirm that the printer works correctly. 1. Turn ON the printer and load the media. 3.4.2 Setting Roll Media 2. Confirm that the printer functions normally. 3.
Page 66 Before using VJ-1324 OPERATION MANUAL c. Press the [>] key on the operation panel. • "Test1: Nozzle Check" is displayed on the operation panel. • The display shifts to the Test Print menu. 5.2 Test Print Menu 4. Press the [+] key or [–] key on the operation panel to select an item for printing from the following items.
Page 67 VJ-1324 OPERATION MANUAL Before using 5. Press the [Enter] key on the operation panel. • Start performing Test Print for the selected item. Refer to the following for details on each of the print list items. 3.5.1 Nozzle check 3.5.5 Color Verify 6.
Page 68: Nozzle Check
Before using VJ-1324 OPERATION MANUAL 3.5.1 Nozzle check It is used to check whether there are any clogged heads, or missing or blurred prints. NOTE • If the nozzle check result indicates that the checked points are blurred or missing, clean the head. 6.2.3 Head cleaning Perform the nozzle check once again at the end of the work.
Page 69: Mode Print
VJ-1324 OPERATION MANUAL Before using 3.5.2 Mode print Used to confirm the following printing conditions. • Print Mode • Effect • Preset Pre heater temperature • Preset platen-heater temperature • Preset dryer temperature • Adjustment value Refer to the following for printing procedure. 3.5 Test print 3.5 Test print...
Page 70: Setup Print
Before using VJ-1324 OPERATION MANUAL 3.5.3 Setup print Used to check the current setup of the printer. NOTE • Keep the printed setup print at hand. Refer to the following for printing procedure. 3.5 Test print 3.5 Test print...
Page 71: Palette Print
VJ-1324 OPERATION MANUAL Before using 3.5.4 Palette print Palette print is executed for the color demonstration. Refer to the following for printing procedure. 3.5 Test print 3.5 Test print...
Page 72: Color Verify
NOTE • The optional SPECTROVUE VM-10 is required to perform this function. For more information, contact your local MUTOH dealer. • Before performing this function, make sure to print the nozzle check pattern to check if there is no missing nozzle.
Page 73 VJ-1324 OPERATION MANUAL Before using Follow the procedure below to perform the Color Verify 1. Turn ON the printer and load the roll media. 3.4.2 Setting Roll Media 2. Set the user type setting. 3.4.3 Setting the User Type Setting 3.
Page 74 Before using VJ-1324 OPERATION MANUAL c. Press the [>] key on the operation panel. • "Test1: Nozzle Check" is displayed on the operation panel. • The display shifts to the Test Print menu. 5.2 Test Print Menu 5. Press the [+] key or [–] key on the operation panel to select " Test5: Color Verify". 3.5 Test print...
Page 75 VJ-1324 OPERATION MANUAL Before using 6. Press the [Enter] key on the operation panel. • The printing of following items starts. • Color Patches • User Type • Preset Heater Temperature • Preset Pre Heater Temperature • Preset Platen Heater Temperature •...
Page 76 Before using VJ-1324 OPERATION MANUAL 7. Press the [Enter] key. • "Open mainte. cover." is displayed on the operation panel. 8. Open the maintenance cover. Name Maintenance cover • "Set white plate then close mainte. cover." is displayed on the operation panel. 3.5 Test print...
Page 77 VJ-1324 OPERATION MANUAL Before using 9. Remove the white reference plate from the plate installation place, turn it over so that the white side faces up, and install it back to the original place. Name White reference plate Plate installation place NOTE •...
Page 78 Before using VJ-1324 OPERATION MANUAL 11. Open the front cover. Name Front cover • "Remove connector cap and attach instrument [ENTER]" is displayed on the operation panel. 12. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap forward to remove it from the print head.
Page 79 VJ-1324 OPERATION MANUAL Before using 13. Press the release buttons on both sides of spectrophotometer, install it to the connector at the print head. Name Spectrophotometer Release buttons Print head section Connector NOTE • Make sure that spectrophotometer is NOT installed at an angle, and that there in no gap between the connector and spectrophotometer.
Page 80 Before using VJ-1324 OPERATION MANUAL 15. Close the front cover. Name Front cover • "Wait for a while..." is displayed on the operation panel. • The printer starts white calibration. 16. When "Start measurement [ENTER]" is displayed on the operation panel, press the [Enter] key. •...
Page 81 VJ-1324 OPERATION MANUAL Before using 17. Press the [Enter] key. • "Open front cover." is displayed on the operation panel. 18. Open the front cover. Name Front cover • "Detach instrument and Set connector [ENTER]" is displayed on the operation panel. 19.
Page 82 Before using VJ-1324 OPERATION MANUAL 20. Firmly pinch the tabs on both sides of the connector cap with your fingers, and install it to the connector at the print head. Name Connector cap Tabs Print head section Connector 21. Press the [Enter] key. •...
Page 83 VJ-1324 OPERATION MANUAL Before using 22. Close the front cover. Name Front cover • "Open mainte. cover." is displayed on the operation panel. 23. Open the maintenance cover. Name Maintenance cover • "Remove white plate then close mainte. cover." is displayed on the operation panel. 3.5 Test print...
Page 84 Before using VJ-1324 OPERATION MANUAL 24. Remove the white reference plate from the plate installation place, turn it over so that the black side faces up, and install it back to the original place. Name White reference plate Plate installation place NOTE •...
Page 85: Specifications
VJ-1324 OPERATION MANUAL Before using • The printing of following items starts. • Date • Serial Number • Color Difference (dE) C o l o r V e r i f i c a t i o n 2011/11/01 15:25 Serial No.
Page 86 Before using VJ-1324 OPERATION MANUAL 27. Press [Enter] key to save the measurement value of the currently printed color patches. NOTE • When the measurement value is saved, the baseline will be replaced by the currently measured value. • Press [Cancel] key to not to save the measurement value. •...
Page 87: Adjust Print
VJ-1324 OPERATION MANUAL Before using Adjust Print It is used for optimizing the quality of image prints. This printer has the following adjustment methods. Adjustment Description Reference method Standard Adjusts only the print mode in the user type setting which is 3.6.1 Standard Adjust Print currently set.
Page 88: Standard Adjust Print
Before using VJ-1324 OPERATION MANUAL 3.6.1 Standard Adjust Print Adjusts only the print mode in the user type setting which is currently set. This menu is made up with the following menus. Menu Name Description Reference Standard Confirmation Print the confirmation pattern and check the amount 3.6.1.1 Standard Confirmation Pattern of misalignment.
Page 89 VJ-1324 OPERATION MANUAL Before using 3.6.1.1 Standard Confirmation Pattern Print the confirmation pattern for the print mode in the user type setting which is currently set. 1. Turn ON the printer and load the roll media. 3.4.2 Setting Roll Media 2.
Page 90 Before using VJ-1324 OPERATION MANUAL d. Press the [+] key or [–] key to select the type of media to load. e. Press the [Enter] key on the operation panel. • "**>1: Print Mode" is displayed on the operation panel. f.
Page 91 VJ-1324 OPERATION MANUAL Before using h. Press the [+] key or [–] key to select "Adj.Print1: Standard>". i. Press the [Enter] key on the operation panel. • "Adj.1: Confirm Ptn." is displayed on the operation panel. • The display enters the Adjust Print menu. 5.1.1.1.3 Adjust Print menu 3.
Page 92 Before using VJ-1324 OPERATION MANUAL NOTE • To start printing during warming up, press the [Enter] key while "Warming Up Skip -> E" is displayed. 4.4.7 Start Printing during Warm up • A confirmation pattern for print quality adjustment is printed after warming up. •...
Page 93: Standard Confirmation Pattern
VJ-1324 OPERATION MANUAL Before using 3.6.1.2 Standard Rough Adjustment Pattern Check the confirmation pattern, and when the misalignment is big, perform rough adjustment. Print a rough adjustment pattern and register the setting value. 1. Display the Adjust Print menu on the operation panel in the same way as in step 2 of "...
Page 94 Before using VJ-1324 OPERATION MANUAL 4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the number from 1 to 11 that is not out of alignment. • "4" is selected in the next printing sample. NOTE •...
Page 95 VJ-1324 OPERATION MANUAL Before using 7. Press the [Enter] key on the operation panel. • The value is set in the "Adjustment: *" (* indicates a number from 1 to 11). • The operation panel display returns to "Adj.2: Rough Pattern". 3.6 Adjust Print...
Page 96: Standard Micro Adjustment Pattern
Before using VJ-1324 OPERATION MANUAL 3.6.1.3 Standard Micro Adjustment Pattern Check the confirmation pattern, and when the misalignment is small, perform micro adjustment. Print a micro adjustment pattern and register the setting value. 1. Display the Adjust Print menu on the operation panel in the same way as in step 2 of "...
Page 97 VJ-1324 OPERATION MANUAL Before using 4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the number from 1 to 7 that is not out of alignment. • "6" is selected in the next printing sample. NOTE •...
Page 98 Before using VJ-1324 OPERATION MANUAL 7. Press the [Enter] key on the operation panel. • The value is set in the "Pattern: *" (* indicates a number from 1 to 7). • The operation panel display returns to "Adj.3: Fine Pattern". 3.6 Adjust Print...
Page 99: Custom Adjustment Pattern
VJ-1324 OPERATION MANUAL Before using 3.6.2 Custom Adjustment Pattern All patterns from A to F can be adjusted. By performing this adjustment, all print modes will be adjusted. This menu is made up with the following menus. Menu Name Description Reference Custom Confirmation Pattern Print the confirmation patterns A to F and...
Page 100 Before using VJ-1324 OPERATION MANUAL 3.6.2.1 Custom Confirmation Pattern From this menu, you can print all confirmation patterns A to F to check the amount of misalignment. 1. Turn ON the printer and load the roll media. 3.4.2 Setting Roll Media 2.
Page 101 VJ-1324 OPERATION MANUAL Before using d. Press the [+] key or [–] key to select the type of media to load. e. Press the [Enter] key on the operation panel. • "**>1: Print Mode" is displayed on the operation panel. f.
Page 102 Before using VJ-1324 OPERATION MANUAL h. Press the [+] key or [–] key to select "Adj.Print2: Custom>". i. Press the [Enter] key on the operation panel. • "Adj.1: Confirm Ptn." is displayed on the operation panel. • The display enters the Adjust Print menu. 5.1.1.1.3 Adjust Print menu 3.
Page 103 VJ-1324 OPERATION MANUAL Before using NOTE • To start printing during warming up, press the [Enter] key while "Warming Up Skip -> E" is displayed. 4.4.7 Start Printing during Warm up • A confirmation pattern for print quality adjustment is printed after warming up. •...
Page 104 Before using VJ-1324 OPERATION MANUAL 4. Confirm that the confirmation pattern printing result is as follows. • Check each of the confirmation patterns A to F. a. When the printing result is OK; You do not need perform Adjust Print. The procedure for Adjustment is complete.
Page 105: Custom Confirmation Pattern
VJ-1324 OPERATION MANUAL Before using 3.6.2.2 Custom Rough Adjustment Pattern Check the confirmation pattern, and when the misalignment is big, perform rough adjustment. Print a rough adjustment pattern and register the setting value. 1. Display the Custom Adjust Print menu on the operation panel in the same way as in step 2 of "...
Page 106 Before using VJ-1324 OPERATION MANUAL 4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the number from 1 to 11 that is not out of alignment. • "3" is selected in the next printing sample of "Micro Adjustment Pattern A". •...
Page 107 VJ-1324 OPERATION MANUAL Before using 6. Press the [+] key or [–] key to enter the number that you selected in Step 4. NOTE • When you press the [Cancel] key, the input operation is not executed and "Adj.2: Rough Pattern" is displayed on the operation panel.
Page 108: Custom Micro Adjustment Pattern
Before using VJ-1324 OPERATION MANUAL 3.6.2.3 Custom Micro Adjustment Pattern Check the confirmation pattern, and when the misalignment is small, perform micro adjustment. This menu is made up with the following menus. Menu Name Description Reference Custom Micro Adj. PatternALL Adjust all confirmation patterns A to F.
Page 109 VJ-1324 OPERATION MANUAL Before using NOTE • To start printing during warming up, press the [Enter] key while "Warming Up Skip -> E" is displayed. 4.4.7 Start Printing during Warm up • An Adjust print pattern for print quality adjustment is printed after warming up. Six micro adjustment patterns will be printed.
Page 110 Before using VJ-1324 OPERATION MANUAL NOTE • "4" is the current setting value. 5. "PatternA: 4" is displayed on the operation panel. 6. Press the [+] key or [–] key to enter the number that you selected in Step 4. NOTE •...
Page 111: Each Adjust Patterns
VJ-1324 OPERATION MANUAL Before using 3.6.2.3.2 Each Adjust Patterns Select and print one of the adjust patterns A to F and register the set value. Follow the procedures below to adjust "Pattern A" only. 1. Display the Custom Adjust Print menu on the operation panel in the same way as in step 2 of "...
Page 112 Before using VJ-1324 OPERATION MANUAL 4. Check the both ends and the center of the print result that printed with Adjust pattern, and select the number from 1 to 7 that is not out of alignment. • "6" is selected in the next printing sample. NOTE •...
Page 113 VJ-1324 OPERATION MANUAL Before using 7. Press the [Enter] key on the operation panel. • The value is set in the "Pattern A: *" (* indicates a number from 1 to 7). • Press the [Enter] key to register the setting value for "Fine PatternA" to the printer. •...
Page 114: Connecting The Printer To Pc
Before using VJ-1324 OPERATION MANUAL Connecting the printer to PC This section explains how to connect the printer and a PC. 3.7.1 System requirements The following are the system requirements for this printer. Operating system Windows7, Windows Vista, Windows XP NOTE •...
Page 115: Connecting A Network Interface Cable
VJ-1324 OPERATION MANUAL Before using 3.7.3 Connecting a network interface cable This section explains how to connect a network interface cable. Follow the procedure below to connect this printer to your PC. 1. Turn OFF both the printer and PC. 2.
Page 116 Before using VJ-1324 OPERATION MANUAL 3.7 Connecting the printer to PC...
Page 117: Handling The Printer
VJ-1324 OPERATION MANUAL Handling the printer Handling the printer This chapter explains how to handle the printer.
Page 118: Print Flow Chart
Handling the printer VJ-1324 OPERATION MANUAL Print flow chart The following flow chart illustrates the procedure to perform printing with the printer. Refer to each section as required. 1. Create print data. Create print data with application software. ↓ 2. Turn the power ON and set the media. 3.4 Loading media 4.2 Media ↓...
Page 119: Media
Select the appropriate media according to the usage. NOTE • For details of the recommended media, contact your local MUTOH dealer. • If failures or malfunctions of the printer occur by the use of media that is not dedicated: • The printer will not be covered by the warranty and repair expenses will be paid by the customer.
Page 120: Cautions On Handling Media
Handling the printer VJ-1324 OPERATION MANUAL 4.2.2 Cautions on handling media Note the following points when handling the media. NOTE • Use recommended media under an appropriate environment. The appropriate temperature and humidity for printing are as follows. Temperature Humidity 22 C to 30 C 40% to 60% Guaranteed range of printing accuracy...
Page 121: Printing Area
VJ-1324 OPERATION MANUAL Handling the printer 4.2.4 Printing area The printable area of this printer is as follows. a=Max. 15mm b=5mm to 25mm c=5mm d=5mm to 25mm Printable Area 4.2.5 Head height adjustment Printing with high printing rate or using strongly-curved media can cause print heads to rub. Changing the distance from the print head surface to media (head height) may allow you to avoid headrub.
Page 122: When Raising The Print Head
Handling the printer VJ-1324 OPERATION MANUAL 4.2.5.1 When raising the print head NOTE • If the head height adjustment lever is raised, high print quality is not guaranteed. • Do not open the front cover or change the head height during printing. If the head height is changed, the alignment will be changed and high print quality will not be guaranteed.
Page 123 VJ-1324 OPERATION MANUAL Handling the printer 3. Close the front cover. Name Front cover 4.2 Media...
Page 124: When Returning The Print Head To The Original Position
Handling the printer VJ-1324 OPERATION MANUAL 4.2.5.2 When returning the print head to the original position NOTE • Do not open the front cover or change the head height during printing. If the head height is changed, the alignment will be changed and high print quality will not be guaranteed.
Page 125 VJ-1324 OPERATION MANUAL Handling the printer 3. Close the front cover. Name Front cover 4.2 Media...
Page 126: Media Feed Compensation
Handling the printer VJ-1324 OPERATION MANUAL 4.2.6 Media feed compensation This section explains the Media feed compensation. The feeding length depends on the media type. The following or similar results may be seen in prints. • Printed images overlap. • White lines are printed on images.
Page 127 VJ-1324 OPERATION MANUAL Handling the printer 2. Performs Initial Print. a. Press the [Enter] key on the operation panel. • "Feed Length: 250 mm" is displayed on the operation panel. •The length of media that is fed (feeding length) for Initial Print is normally set at 250 mm. •If you increase the feeding length, the accuracy of the Media feed compensation improves.
Page 128 Handling the printer VJ-1324 OPERATION MANUAL 4. Sets up Initial Adjust Change. a. Press the [+] key or [–] key on the operation panel to select "PF2: Initial Change". b. Press the [Enter] key on the operation panel. • "Init.: 250.0/250 mm" is displayed on the operation panel. c.
Page 129 VJ-1324 OPERATION MANUAL Handling the printer d. After the Confirm Print, the media is cut. 4.4.3 Cutting media 6. Measure the distance between the two pluses in the Confirm Print using a ruler. Then, confirm that the distance matches the feeding length when printing. a.
Page 130 Handling the printer VJ-1324 OPERATION MANUAL 0.05 Current adjustment value 0.05 • After the micro adjustment printing is completed, "PF4:Micro Print" is displayed on the operation panel. 8. Refer to the illustrations below and check the printing result. Input the adjustment value 4.2 Media...
Page 131 VJ-1324 OPERATION MANUAL Handling the printer 9. Sets up Micro Adjustment Change. a. Press the [+] key or [-] key to select "PF5: Micro Change". b. Press the [Enter] key on the operation panel. • "Micro Change: 0.00%" is displayed on the operation panel. c.
Page 132: Menu Setups On The Operation Panel
Handling the printer VJ-1324 OPERATION MANUAL Menu setups on the operation panel 4.3.1 Menu setup procedure Follow the procedure below to configure each setup menu. 1. Confirm that the operation panel is Normal. 2. Press the [Menu] key on the operation panel. •...
Page 133 VJ-1324 OPERATION MANUAL Handling the printer 4. The setting in the blinking part on the LCD monitor of the operation panel can be changed. Press the [+] key or [-] key to change the set value. 5. To save the changed setting, press the [Enter] key on the operation panel. •...
Page 134: Panel Setup Menu Overview
Handling the printer VJ-1324 OPERATION MANUAL • The previous setup menu is displayed. • When the main menu is displayed, the screen turns to Normal. 4.3.2 Panel setup menu overview This section explains the Panel setup menu of the printer. There are the following items in the Panel setup menu.
Page 135: Operating From The Operation Panel
VJ-1324 OPERATION MANUAL Handling the printer Operating from the operation panel This section explains various functions that can be operated from the operation panel. 2.2.3 Operation panel •For names and functions of each key, refer to " ". 4.4.1 Feeding media You can feed the roll media at a position that you want.
Page 136: Stopping Printing Operation
Handling the printer VJ-1324 OPERATION MANUAL 4.4.2 Stopping printing operation If you want to stop printing for some reason, operate as follows. 1. Stop sending printing data from the computer to the printer. 2. Press the [Cancel] key on the operation panel for two seconds. •...
Page 137: Cutting Media
VJ-1324 OPERATION MANUAL Handling the printer 4.4.3 Cutting media This section explains how to cut media. If Media ejection mode is set to "Cut", the printer cuts the media automatically after printing. 5.1.6 Output Mode menu If you press the [Cutting] key on the operation panel more than two seconds while the operation panel is Normal, you can cut the media at the desired position.
Page 138: Cutting Media Manually
Handling the printer VJ-1324 OPERATION MANUAL 4.4.4 Cutting media manually This section explains how to cut the roll media manually. CAUTION • Right after printing, the media guide becomes very hot. Allow the media guide to cool down before the next operation. Follow the procedure below to cut the roll media.
Page 139: Changing And Confirming Settings While Printing
VJ-1324 OPERATION MANUAL Handling the printer NOTE • When loading the new roll media, cut the front edge of the media if it is not straight. 4.4.5 Changing and confirming settings while printing While the printer is operating, you can change or confirm settings for the Panel setup menu. 4.4.5.1 Procedure for changing and confirming settings while printing Follow the procedure below to change or confirm settings for the Panel setup menu.
Page 140: Settings That Can Be Changed Or Confirmed While Printing
Handling the printer VJ-1324 OPERATION MANUAL 4.4.5.2 Settings that can be changed or confirmed while printing NOTE • When you change a setting during operation, be sure to select "Backup" to save the setting that you changed. If the printer returns to Normal without "Backup" being selected, the changed setting is not saved. •...
Page 141: Pausing Printing
VJ-1324 OPERATION MANUAL Handling the printer 4.4.6 Pausing printing It is possible to pause to print during printing. Follow the procedure below to pause or restart printing. NOTE • If the printing is paused, the print quality will not be guaranteed. 1.
Page 142: Start Printing During Warm Up
Handling the printer VJ-1324 OPERATION MANUAL 4.4.7 Start Printing during Warm up You can start printing even when the heater temperature has not reached the preset value while the printer is being warmed up. NOTE • Even when printing is started during warm up, the printer continues to be warmed up until the preset temperature has been reached.
Page 143: Normal Display While Printing
VJ-1324 OPERATION MANUAL Handling the printer 4.4.8 Normal Display while Printing The remaining length and remaining time to complete the currently printing data can be displayed by an easy operation. NOTE • The values displayed in this function are just standard values, not guarantee the accuracy. •...
Page 144 Handling the printer VJ-1324 OPERATION MANUAL 3. Press [-] key on the operation panel to display [Remain Time]. • The remaining length of data currently printing will be displayed. 4. To return the display to [Printing], press [-] key on the operation panel. 4.4 Operating from the operation panel...
Page 145: Using Spectrophotometer (Spectrovue Vm-10)
The optional spectrophotometer (SPECTROVUE VM-10) can be attached to print and measure the color target. Performing color calibration or profiling of the printer by using RIP software compatible with SPECTROVUE VM-10 enables printing with more accurate colors. For more information about the option, contact your local MUTOH dealer. Follow the procedure below. NOTE •...
Page 146 Handling the printer VJ-1324 OPERATION MANUAL • "Printing" is displayed on the operation panel. • After printing is complete, "Attaching instrument [ENTER]" is displayed on the operation panel. NOTE • Do not open the covers or move media loading lever during printing. 6.
Page 147 VJ-1324 OPERATION MANUAL Handling the printer 7. Open the maintenance cover. • "Set white plate then close mainte. cover." is displayed on the operation panel. Name Maintenance cover 8. Remove the white reference plate from the plate installation place, turn it over so that the white side faces up, and install it back to the original place.
Page 148 Handling the printer VJ-1324 OPERATION MANUAL 9. Close the maintenance cover. • "Open front cover." is displayed on the operation panel. Name Maintenance cover 10. Open the front cover. • "Remove connector cap and attach instrument [ENTER]" is displayed on the operation panel. Name Front cover 4.5 Using spectrophotometer (SPECTROVUE VM-10)
Page 149 VJ-1324 OPERATION MANUAL Handling the printer 11. Firmly pinch the tabs on both sides of the connector cap with your fingers, pull the connector cap forward to remove it from the print head. Name Connector cap Tabs Print head section 12.
Page 150 Handling the printer VJ-1324 OPERATION MANUAL 13. Press the [Enter] key. • The printer checks the connection between the printer and spectrophotometer. • "Close front cover" is displayed on the operation panel. 14. Close the front cover. • "Wait for a while..." is displayed on the operation panel. •...
Page 151 VJ-1324 OPERATION MANUAL Handling the printer 15. When "Start measurement [ENTER]" is displayed on the operation panel, press the [Enter] key. • Spectrophotometer starts measuring the color target. • "Measuring..." is displayed on the operation panel. • After measuring is complete, "Detaching instrument [ENTER]" is displayed on the operation panel.
Page 152 Handling the printer VJ-1324 OPERATION MANUAL 17. Open the front cover. • "Detach instrument and Set connector [ENTER]" is displayed on the operation panel. Name Front cover 18. While pressing the release buttons on both sides of spectrophotometer, pull it forward to remove it from the print head.
Page 153 VJ-1324 OPERATION MANUAL Handling the printer 19. Firmly pinch the tabs on both sides of the connector cap with your fingers, and install it to the connector at the print head. Name Connector cap Tabs Print head section Connector 20. Press the [Enter] key. •...
Page 154 Handling the printer VJ-1324 OPERATION MANUAL 21. Close the front cover. • "Open mainte. cover." is displayed on the operation panel. Name Front cover 22. Open the maintenance cover. • "Remove white plate then close mainte. cover." is displayed on the operation panel. Name Maintenance cover 4.5 Using spectrophotometer (SPECTROVUE VM-10)
Page 155 VJ-1324 OPERATION MANUAL Handling the printer 23. Remove the white reference plate from the plate installation place, turn it over so that the black side faces up, and install it back to the original place. Name White reference plate Plate installation place NOTE •...
Page 156 Handling the printer VJ-1324 OPERATION MANUAL 4.5 Using spectrophotometer (SPECTROVUE VM-10)
Page 157: Panel Setup Menu
VJ-1324 OPERATION MANUAL Panel setup menu Panel setup menu The section explains the Setup menu of the printer. Setup item Description Setup menu Various settings of the printer are configured. 5.1 Setup menu Test Print menu Performs nozzle check of the print head and setup list. 5.2 Test Print Menu Cleaning menu Performs head cleaning.
Page 158: Setup Menu
Panel setup menu VJ-1324 OPERATION MANUAL Setup menu Various settings of the printer are configured. Setup item Description User Type Sets the user type setting for printing. • [Enter] key: shifts to the sub menu. 5.1.1 User Type menu Spitting Sets up the spitting operation while printing.
Page 159 VJ-1324 OPERATION MANUAL Panel setup menu Setup item Description Slant Check Sets up slanting detection during media loading. • [Enter] key: shifts to the sub menu. 5.1.14 Slant Check menu Auto Cleaning Sets up the time for auto cleaning during standby, before printing, and during printing. •...
Page 160: User Type Menu
• End detection of roll media cannot be performed, etc. The problems caused by the use of the media other than recommended one will not be covered by the warranty and repair expenses will be paid by the customer. For details, contact your local MUTOH dealer. 5.1 Setup menu...
Page 161 VJ-1324 OPERATION MANUAL Panel setup menu Setup item Setting Description Type 1 to 30 PrintMode Sets up the Print Mode according to the usage of print data or print speed. • [Enter] key: shifts to the sub menu. 5.1.1.1.1 Print Mode menu Effect Sets up the Effect menu.
Page 162: Print Mode Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.1.1.1 Print Mode menu Settings for print quality (Print Mode) are set according to the usage of print data or print speed. Setup item Setting Description Mode Quality 1 Set the print mode. • Quality 1 to 4: Quality 2 Suitable for printing photographs.
Page 163: Effect Menu
VJ-1324 OPERATION MANUAL Panel setup menu Details of Print Mode The set values of print quality that are registered in each print mode are as follows. NOTE In the following chart, the print speed becomes faster as it matches the chart. •...
Page 164 Panel setup menu VJ-1324 OPERATION MANUAL 5.1.1.1.2 Effect menu Sets up the Effect menu. Set up this menu when you want to improve print quality by adjusting the set Print Mode. NOTE • The print quality may not be improved depending on the printing condition. Setup item Setting Description...
Page 165: Adjust Print Menu
VJ-1324 OPERATION MANUAL Panel setup menu Print Mode Effect Default Value Quality1 to 4 Fine&Fuzz Graphics1 to 2 Fine&Fuzz Graphics3 to 4 Fine&Fog Banner1 to 2 Banner3 to 4 None 5.1.1.1.3 Adjust Print menu Sets up when adjusting the printer for the optimum quality of image print. This setting is different for each user type setting.
Page 166 Panel setup menu VJ-1324 OPERATION MANUAL Standard Adjust Print Menu Adjusts only the print mode in the user type setting which is currently set. Setup item Setting Description Standard Standard Confirmation Print the test pattern for the alignment. Pattern Check before adjusting. 3.6.1.1 Standard Confirmation Pattern Standard Rough Adjustment Perform this adjustment when the misalignment is big.
Page 167: Dist.adj Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.1.1.4 Dist.Adj menu Sets up various settings on the media feed compensation. Setup item Setting Description Initial Print Performs initial adjustment printing. • [Enter] key: shifts to the sub menu. (1) Initial Print menu Init.Adj.Change Sets up Initial Adjust Change.
Page 168 Panel setup menu VJ-1324 OPERATION MANUAL (2) Init.Adj.Change menu Sets up Initial Adjust Change. Setup item Setting Description Init. The set value ±50.0mm in Sets up Initial Adjust Change. "Feed length" of Initial adjust e.g) When the set value in "Feed length*" of Initial adjust print print is set to 250mm, the adjustment range in this menu is 200mm to 300mm.
Page 169: Pre-Heater Menu
VJ-1324 OPERATION MANUAL Panel setup menu (5) Micro Adj.Change menu Sets up Micro Adjustment Change. Setup item Setting Description Micro Adj.Change -5.00% to <0.00> to 5.00% Sets up Micro Adjustment Change. — • [Enter] key: saves the setting and shifts to the previous menu.
Page 170: Platen Heater Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.1.1.6 Platen heater menu Sets the temperature of the platen heater. Set to improve print quality by allowing the ink to settle by heat. NOTE • The set temperature of the platen heater differs depending on the media. For the set temperatures of the platen heater, refer to "recommended media list".
Page 171: Dryer Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.1.1.7 Dryer menu Sets the temperature of the dryer. Set to dry the print side after printing. NOTE • The set temperature of the dryer differs depending on the media. Setup item Setting Description Dryer Off / <30 °C>...
Page 172: Spitting Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.2 Spitting menu Sets up the spitting operation while printing. NOTE • When Spitting is set to "Off", the nozzle will become easily clogged because spitting is not performed. In this instance, print quality cannot be guaranteed. •...
Page 173: Spitting Pass Count Menu
VJ-1324 OPERATION MANUAL Panel setup menu Setup item Setting Description Spitting <On> Perform the flushing operation on the spitting box located on the origin side for every shuttle. •[Enter] key: saves the setting and shifts to the sub menu. 5.1 Setup menu On Media Perform the spitting operation on the page margins.
Page 174 Panel setup menu VJ-1324 OPERATION MANUAL <Example of spitting operation> Spitting setting Return Count setting Operation 1 time Performs the spitting operation on the flushing box on the origin side every time the print head returns to the origin position. Spitting is not performed over the media.
Page 175: Side Margin Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.3 Side Margin menu Set up the right and left margins (side margins) while printing. NOTE • When the spitting menu is set to "On Media", the maximum printable media width becomes 10mm shorter. Therefore, the side margin becomes "value set on side margin menu"...
Page 176: Media Initial Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.4 Media Initial menu Sets whether to detect the media width and edge while initializing the media. NOTE • Set the media width that is set in the Media Width menu when setting "Off" in the Media detection menu.
Page 177: Media Width Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.5 Media Width menu Specifies the media width between 7mm away from the right edge of the platen and the left end if media detection is not performed during media initialization. (1) Media Width menu Displays the detected media width if media detection is performed during media initialization.
Page 178: Output Mode Menu
Panel setup menu VJ-1324 OPERATION MANUAL (2) MediaWidth menu Setup item Setting Description MediaWidth **** mm Display the media width that is detected while initializing. — • [Cancel] key: shifts to the previous menu. 5.1 Setup menu 5.1.6 Output Mode menu Sets the media operation after printing.
Page 179: Method Of Cut Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.7 Method of Cut menu Sets the media cutting operation after printing. NOTE • When the the media detection is set to "Off", the media cannot be cut automatically. • Some media may not be cut (cannot be cut at all or cannot be cut finely). In such a case, set the "Output Mode menu"...
Page 180: Origin Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.8 Origin menu Sets the beginning of printing (origin) of the print data. Set the menu when reprinting on the margin with changing the printing data position to the printed media. NOTE • When Output Mode menu is set to "Take-up", the set value X (media feeding distance) becomes 0 mm to 15000 mm.
Page 181 VJ-1324 OPERATION MANUAL Panel setup menu Setup item Setting Description Origin • X (media feeding distance): Change the print head position and media feeding distance with the following -15000 mm to 15000 mm keys. • Y (print head transferring • [>] key: Decreases the print head transferring distance distance): •...
Page 182: Prev. Stick Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.9 Prev. Stick menu Sets up to prevent media from sticking when printing starts. NOTE • When the Output Mode menu is set to "Take-up", the setting for the Prev. Stick menu is disabled. 5.1.6 Output Mode menu Setup item Setting...
Page 183: Head Travel Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.11 Head Travel menu Sets up the range that the print head moves while printing. Setup item Setting Description CR Movement <Data> The print head moves the range of the print data width. The printing speed will be improved since the moving range of the print head is optimized.
Page 184: Strike Wait Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.13 Strike Wait menu Sets up the waiting time while overwrite printing. NOTE • When using the media with a narrow width, the media cannot be warmed up adequately, therefore the print quality may not be preserved. In such a case, set up the Strike Wait time while overwrite printing to warm up the media adequately before printing.
Page 185: Auto Cleaning Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.15 Auto Cleaning menu Configure the settings for the auto-cleaning operation. •The cleaning mode reflects the settings in the operation panel. 6.2.3 Head cleaning Setup item Setting Description Auto Cleaning WaitingTime Set the value for auto-cleaning in standby mode. 5.1.15.1 Idle Auto Cleaning Print time Set the value for auto-cleaning in printing mode.
Page 186: Printing Mode Auto Cleaning
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.15.2 Printing Mode Auto Cleaning Set the auto cleaning interval for printing mode. Setup item Setting Description PrintingTime <Off> to 5 mins to 180 mins Selects the time for auto-cleaning while printing. • Off: Auto cleaning is not performed. •...
Page 187: Ink Status Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.16 Ink Status menu Displays the various information of smart chips. 5.1.16.1 SmartChip menu NOTE • To display the various information of Smart chips, use genuine ink and S/C cards. If ink other than genuine ink is used, the ink status will not be displayed correctly. Setup item Setting Description...
Page 188: Longstore Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.17.1 Roll Length menu Sets up the roll media length. NOTE • After replacing the roll media, set the roll media length again. If the roll media length is not set, the residual quantity of roll media may not be displayed correctly. Setup item Setting Description...
Page 189: Cr Maintenance Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.19 CR Maintenance menu Performs maintenance. Used in the following cases. • Cleaning the cleaning wiper 6.2.4 Cleaning the cleaning wiper • Cleaning around the print head 6.2.5 Cleaning around the print head • Replacing Cutter 6.1.3 Replacing Cutter Setup item...
Page 190: Life Times Menu
(20 %). PF Motor • The part should be changed when all of the asterisks have disappeared, and "Change" is displayed. Contact your local MUTOH dealer to ask for replacing parts. — • [Cancel] key: shifts to the previous menu.
Page 191: Subnet Mask Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.1.23 Subnet Mask menu Sets the subnet mask of the printer. NOTE • Be sure to set the subnet mask after consulting the network administrator. Setup item Setting Description Subnet Mask 000.000.000.000 to Change the subnet mask by operating the following keys. <255.255.255.000>...
Page 192: Header Dump Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.1.25 Header Dump menu This function is to specify whether to print the following information (dump data) of print data. • Data Header • Number of Dot in Data (Printed only when the header dump setting is "On".) •...
Page 193: Test Print Menu
VJ-1324 OPERATION MANUAL Panel setup menu Test Print Menu Performs nozzle check of the print head and setup list. •Refer to the following for the operation procedure of test print. 3.5 Test print Setup item Description Nozzle Check Perform the nozzle check printing. It is used to check whether there are any clogged heads, or missing or blurred prints.
Page 194: Cleaning Menu
Panel setup menu VJ-1324 OPERATION MANUAL Cleaning menu Performs head cleaning. •Head cleaning can be operated when the printer is Normal. Refer to the following for operation procedures. 6.2.3 Head cleaning Setup item Description Short Discharges smaller amount of ink compared to "Normal". Normal Select this mode normally.
Page 195: Menu Option Menu
VJ-1324 OPERATION MANUAL Panel setup menu Menu Option menu Sets up the contents of the Setup menu. You can make setup items that you do not normally use invisible. Switch the setting "On (displayed)" to "Off (undisplayed)" using the [<] key or [>] key on the operation panel.
Page 196 Panel setup menu VJ-1324 OPERATION MANUAL Setup item Setting Description Strike Wait Sets up whether to display the Strike Wait menu. <On> Slant Check Sets up whether to display the Slant Check menu. <On> Auto Cleaning Sets up whether to display the Auto Cleaning menu. <On>...
Page 197 VJ-1324 OPERATION MANUAL Panel setup menu Setup item Setting Description ALL Off No items in the Setup menu are displayed. • Pressing the [Enter] key deletes "*" for all items in the Menu Option menu. • Even if you select "ALL Off", you can display the items temporarily by selecting "Temporary"...
Page 198: Version Menu
Panel setup menu VJ-1324 OPERATION MANUAL Version menu Displays the versions of the firmware. Setup item Setting Description Ver. M/C *.**(Main side)/ Displays the versions of the firmware of the main side (M) and *.**(Controller side) controller side (C). — •...
Page 199: Sleep Mode Menu
VJ-1324 OPERATION MANUAL Panel setup menu Sleep Mode menu Sleep mode settings are configured. When you activate sleep mode, the printer operates as follows. • The vacuum fan stops. • All heaters stop. • All lamps turn off except for the power lamp. •...
Page 200: Timer Setting Menu
Panel setup menu VJ-1324 OPERATION MANUAL 5.6.1 Timer Setting menu Set the head cleaning interval of this printer for Sleep Mode. When more than the set time has passed, the print head is cleaned automatically. NOTE • During Sleep Mode, even if the set amount of time has passed, print-head cleaning is not performed under the following circumstances.
Page 201: Sleep Mode Start Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.6.2 Sleep Mode Start menu Activate Sleep Mode During Sleep Mode, "Restart –> Enter" will be displayed in the operation panel. During Sleep Mode, pressing [Enter] key will return the printer to normal operation. NOTE •...
Page 202: Display Menu
Panel setup menu VJ-1324 OPERATION MANUAL Display menu Sets the language and unit displayed on the LCD monitor of the operation panel. Setup item Setting Description Display Language Sets the language used in the menu items displayed on the LCD monitor of the operation panel. 5.7.1 Language menu Temperature Sets the unit of temperature display.
Page 203: Length Menu
VJ-1324 OPERATION MANUAL Panel setup menu 5.7.3 Length menu Sets the unit to display the length. Setup item Setting Description Length <mm> Displays the length in millimeters (mm). inch Displays the length in inches (inch). — • [Enter] key: saves the setting and shifts to the previous menu.
Page 204: Job Status Menu
Panel setup menu VJ-1324 OPERATION MANUAL Job Status Menu Various information of previous print will be displayed. The length of printed data and if the print is completed will be displayed. When the print is canceled, the information how much the print is completed will be displayed. Setup item Setting Description...
Page 205: Maintenance
VJ-1324 OPERATION MANUAL Maintenance Maintenance This chapter describes daily maintenance of the product.
Page 206: Replacing Consumable Components
Maintenance VJ-1324 OPERATION MANUAL Replacing consumable components This section describes the replacement time and steps of ink cartridge (or ink packs), roll media, razor blade. 6.1.1 Replacing ink cartridges This section describes when to replace the ink cartridges. (1) Replacement time a.
Page 207 NOTE • To use 1000ml ink packs, high capacity pack adapters (option) are required. For details on high capacity pack adapters, contact your local MUTOH dealer. • Use genuine ink cartridges for replacement. This printer is designed to use genuine ink cartridges.
Page 208 Maintenance VJ-1324 OPERATION MANUAL NOTE • Do not share the ink cartridge once installed with another printer. The cartridge will not be usable from that time onward. • Do not give ink cartridges or ink packs strong shakes. Doing so may cause ink leakage. •...
Page 209 VJ-1324 OPERATION MANUAL Maintenance NOTE • Open the bag just before attaching the ink cartridge to the ink cartridge slot. Leaving the ink cartridge with the bag open for a long time may result in abnormal printing. • Do not insert or remove the ink cartridge more than 10 times. If the ink cartridge has been removed/inserted more than 10 times, it cannot be used even though ink remains.
Page 210 Maintenance VJ-1324 OPERATION MANUAL Name High capacity pack adapter Ink cartridge slot NOTE • Do not remove only ink pack while high capacity pack adapter is installed on the printer. The information of the remaining smart chip card will be rewritten and the ink pack will not be usable. 3.
Page 211: Replacing Roll Media
VJ-1324 OPERATION MANUAL Maintenance 6.1.2 Replacing Roll Media This section describes when and how to replace the roll media. (1) Replacement time Replace the roll media when the following situation occurs. a. When the roll media loaded in the printer runs out •...
Page 212 Maintenance VJ-1324 OPERATION MANUAL 3. Hold the both edges of the scroller to rewind the roll media by hands. Name Roll media Scroller 4. Remove the scroller unit, and place it on a flat floor. Name Scroller 6.1 Replacing consumable components...
Page 213 VJ-1324 OPERATION MANUAL Maintenance 5. Hold the movable media stopper and lightly tap it as illustrated to remove the movable media stopper. NOTE • When removing the roll media, do not strike the left edge of the scroller (on the movable media stopper side) strongly on the floor.
Page 214: Replacing Cutter
Maintenance VJ-1324 OPERATION MANUAL 8. When not loading the roll media, install the movable stopper to the scroller and set the scroller to the printer. Name Movable media stopper Scroller 6.1.3 Replacing Cutter This section describes when and how to replace the cutter. (1) Replacement time Replace the cutter when the following situation occurs.
Page 215 VJ-1324 OPERATION MANUAL Maintenance (3) Replacing steps Follow the procedure below to replace the cutter. 1. If the printer is turned ON, make sure the following. • Printing or other operations are not in progress. • The operation panel display is Normal. 2.
Page 216 Maintenance VJ-1324 OPERATION MANUAL c. Press the [+] key or [–] key to select "Set20: CR Maintenance". d. Press the [Enter] key on the operation panel. • "CR Mainte.: Start" is displayed on the operation panel. • The display enters the CR Maintenance menu. 5.1.19 CR Maintenance menu 3.
Page 217 VJ-1324 OPERATION MANUAL Maintenance 4. Open Maintenance cover. Name Maintenance cover NOTE • Replace the cutter in a short time. Leaving the print head at the cutter replacement position may result in clogging of the print head. 5. Press the tab of the cutter lightly, turn the cutter holder in the direction as illustrated below. NOTE •...
Page 218 Maintenance VJ-1324 OPERATION MANUAL Name Cutter holder Cutter holder lever 6. Remove the cutter. CAUTION • Do not touch the blade edge. It may cause an injury. • Do not touch the cutter blade edge with a hard substance or drop the cutter. The cutter blade may be damaged or chipped.
Page 219 VJ-1324 OPERATION MANUAL Maintenance 7. Install a new cutter as illustrated. NOTE • Make sure that the spring in the cutter holder does not fly out while installing. Name Razor blade 8. Press the tab of the cutter lightly, return the cutter holder to its initial position. NOTE •...
Page 220 Maintenance VJ-1324 OPERATION MANUAL Name Cutter holder Cutter holder lever Close Maintenance cover. Name Maintenance cover 6.1 Replacing consumable components...
Page 221 VJ-1324 OPERATION MANUAL Maintenance 10. Press the [Enter] key on the operation panel. • The print head returns to its original position. • "CR Mainte.: Start" is displayed on the operation panel. 11. Press the [Menu] key on the operation panel. •...
Page 222: Cleaning The Printer
It could lead to an electric shock or fire. Immediately turn OFF the power switch, disconnect the power plug from the electric socket, and contact your local MUTOH dealer. CAUTION • When cleaning the areas other than the wiper, make sure to turn OFF the power and unplug the power cable.
Page 223: Cleaning The Outer Case
VJ-1324 OPERATION MANUAL Maintenance 6.2.1 Cleaning the outer case This section describes how to clean the outer case. Wipe out dust and dirt attached to the outer case by using a soft cloth. 6.2 Cleaning the printer...
Page 224: Cleaning The Inside Of The Printer
Maintenance VJ-1324 OPERATION MANUAL 6.2.2 Cleaning the inside of the printer This section describes how to clean the inside of the printer. Follow the procedure below. 1. Open the front cover. Name Front cover 2. Remove paper powder and dust attached to the pressurizing rollers using a soft brush. NOTE •...
Page 225 VJ-1324 OPERATION MANUAL Maintenance 3. Apply a damp and tightly squeezed soft cloth to wipe out paper powder and ink attached to the platen and media guide. Name Platen Media guide 4. Apply a damp and tightly squeezed soft cloth to wipe off the dirt of the unpainted (silver color) area in the center of the grid roller.
Page 226: Head Cleaning
Maintenance VJ-1324 OPERATION MANUAL 6.2.3 Head cleaning If printed data is blurred or lacks part of it, clean the print head surface and nozzle (Head cleaning). Follow the procedure below to perform Head cleaning. NOTE • When not using the printer for a long period (one week or more), perform Head cleaning once a week.
Page 227: Cleaning The Cleaning Wiper
VJ-1324 OPERATION MANUAL Maintenance NOTE • If you fail to remove blurs or incompleteness of printing in one Head cleaning, perform strong cleaning. • If blurs or lacking parts in printed media do not disappear with several times of Head cleaning, refer to "...
Page 228 Maintenance VJ-1324 OPERATION MANUAL • The operation panel shifts to the Setup menu display. b. Press the [>] key on the operation panel. • "Set1: User Type" is displayed on the operation panel. c. Press the [+] key or [–] key to select "Set20: CR Maintenance". d.
Page 229 VJ-1324 OPERATION MANUAL Maintenance 3. Press the [Enter] key on the operation panel. • Maintenance starts. • The print head moves to the left. • "CR Mainte.: End" is displayed on the operation panel. 4. Open the front cover. Name Front cover CAUTION •...
Page 230 Maintenance VJ-1324 OPERATION MANUAL 5. Use the cleaning stick to remove the ink and dust on the cleaning wiper. a. Front side of the cleaning wiper: Remove the ink and dust in the horizontal direction. Name Cleaning wiper Cleaning stick Head cap unit b.
Page 231 VJ-1324 OPERATION MANUAL Maintenance 6. Close the front cover. Name Front cover 7. Press the [Enter] key on the operation panel. • The print head returns to its original position. • "CR Mainte.: Start" is displayed on the operation panel. 8.
Page 232: Cleaning Around The Print Head
Maintenance VJ-1324 OPERATION MANUAL • The printer enters Normal. • Cleaning the cleaning wiper is complete. 6.2.5 Cleaning around the print head This section describes how to clean around the print head. (1) Time for cleaning When foreign substances such as dust or ink clump that can cause missing dots or ink leakage is attached around the print head (2) Cleaning procedures Follow the procedure below to clean around the print head.
Page 233 VJ-1324 OPERATION MANUAL Maintenance 2. Display the CR Maintenance menu on the operation panel. a. Press the [Menu] key on the operation panel. • "Menu1: Setup>" is displayed on the operation panel. • The operation panel shifts to the Setup menu display. b.
Page 234 Maintenance VJ-1324 OPERATION MANUAL d. Press the [Enter] key on the operation panel. • "CR Maine.: Start" is displayed on the operation panel. • The display enters the CR Maintenance menu. 5.1.19 CR Maintenance menu 3. Press the [Enter] key on the operation panel. •...
Page 235 VJ-1324 OPERATION MANUAL Maintenance 4. Open the maintenance cover on the left of the printer. Name Maintenance cover 5. Move the print head section by hand to where the circumference of the Print head is visible. Name Print head section Circumference of the Print head CAUTION •...
Page 236 Maintenance VJ-1324 OPERATION MANUAL 6. Use a penlight, etc to check if any foreign substance, such as dust or ink clump, is attached to the following places. Name Around the print head Head guide Nozzles Dust, ink clump, etc CAUTION •...
Page 237 VJ-1324 OPERATION MANUAL Maintenance 7. When some foreign substance such as dust or ink clump is attached, use the cleaning stick to remove Name Around the print head Head guide Nozzles Cleaning stick 8. Close the left maintenance cover. • Close the cover firmly until it is locked.
Page 238 Maintenance VJ-1324 OPERATION MANUAL 9. Press the [Enter] key on the operation panel. • The print head returns to its original position. • "CR Maine.: Start" is displayed on the operation panel. 10. Press the [Menu] key on the operation panel. •...
Page 239: Disposal Of Waste Fluids
VJ-1324 OPERATION MANUAL Maintenance Disposal of waste fluids The timing and method for the disposal of waste fluid are described below. (1) Disposal timing Dispose of waste fluids in the following cases: a. When the waste fluid tank is more than half full. b.
Page 240 Maintenance VJ-1324 OPERATION MANUAL Name Waste fluid valve Empty container 4. After pouring the waste fluid to the empty container, close the waste fluid valve securely. Name Waste fluid valve Empty container 5. Wipe the opening of the waste fluid valve with a cloth, etc. 6.
Page 241: Moving Or Transporting The Printer
VJ-1324 OPERATION MANUAL Maintenance Moving or transporting the printer This section describes how to move or transport the printer. 6.4.1 Moving the printer This section describes how to move the printer. CAUTION • Move the printer maintaining a horizontal position. •...
Page 242 Maintenance VJ-1324 OPERATION MANUAL 6. Remove the scroller. 7. Remove all the cables, such as the power cable. 8. Unlock the casters to move it. NOTE • The casters supplied with the dedicated stand are manufactured for little movement in flat indoor areas, not for transporting equipment.
Page 243: Transporting The Printer
When transporting the printer, make sure to pack it in the same condition as purchased, using protective and packing materials to protect the printer from vibration and shocks. NOTE • When transporting the printer, consult the MUTOH product dealer at your point of purchase. 6.4 Moving or transporting the printer...
Page 244 Maintenance VJ-1324 OPERATION MANUAL 6.4 Moving or transporting the printer...
Page 245: Troubleshooting
Troubleshooting This chapter describes possible troubles during the use of this product and countermeasures. If the error not included in any items of this section occurs, contact your local MUTOH dealer. NOTE • If you want to receive product warranty, prepare the warranty certificate.
Page 246: Malfunctions And Failures
Troubleshooting VJ-1324 OPERATION MANUAL Malfunctions and failures This section describes undisplayed malfunctions and failures of the printer, possible causes and countermeasures. 7.1.1 Problems in installation and introduction (1) Cannot perform the initial ink charge Possible cause Remedy Reference Is the front cover open or media loading lever Close the front cover, or lower the media 3.4 Loading raised?
Page 247: Nothing Is Printed
VJ-1324 OPERATION MANUAL Troubleshooting Possible cause Remedy Reference Is the maintenance cover open? Close the maintenance cover. 6.2.4 Cleaning the cleaning wiper 6.2.5 Cleaning around the print head (2) Does not work after loading the media Possible cause Remedy Reference Is the front cover open or media loading lever Close the front cover.
Page 248: Media-Related Troubleshooting
Troubleshooting VJ-1324 OPERATION MANUAL Possible cause Remedy Reference Are the network settings configured Configure the network settings correctly. 5.1.22 IP correctly? Address menu 5.1.24 Gateway menu Match the printer’s network settings with the Match this product’s network settings with the 3.7.1 System computer side environment.
Page 249 VJ-1324 OPERATION MANUAL Troubleshooting (2) The media is crumpled during initialization NOTE • If the media is jammed or torn, remove it according to "7.3 The media is jammed". Possible cause Remedy Reference Are you using the recommended media? Use the recommended media. 4.2.1 Media type Is the loading position of the media correct?
Page 250: Printing-Related Troubleshooting
Troubleshooting VJ-1324 OPERATION MANUAL (4) Media jams frequently occur NOTE • If media other than the recommended one is used, correct media feeding cannot be assured. Possible cause Remedy Reference Are you using the recommended media? Use the recommended media. 4.2.1 Media type Is the media used in an environment other...
Page 251 VJ-1324 OPERATION MANUAL Troubleshooting Possible cause Remedy Reference Does the media bend? Use the recommended media. 4.2.1 Media When using media other than the dedicated type one, set the Vacuum Fan menu. 5.1.1.1.8 Vacuum Fan menu (2) The printing position is incorrect (some parts of the media cannot be printed Possible cause Remedy Reference...
Page 252 Troubleshooting VJ-1324 OPERATION MANUAL Possible cause Remedy Reference Did you perform Alignment? Perform Alignment. 3.6 Adjust Print Did you perform Media feed compensation? Perform Media feed compensation. 4.2.6 Media feed compensation Is the temperature setting of each heater Set the temperature appropriately. 5.1.1.1.5 Pre- appropriate? heater menu...
Page 253: Error Messages
VJ-1324 OPERATION MANUAL Troubleshooting Error messages This section describes messages displayed during normal printer operation or when errors occur, and solutions to the messages. 7.2.1 Status messages This section describes messages displayed during printer normal operation. When the product is operating correctly, each operation status is displayed on the operation panel as below.
Page 254: Message Type Error Display And Remedies
Troubleshooting VJ-1324 OPERATION MANUAL Display Description Reference Power Off Turning the printer off. 3.2.2 Turning Please wait a while. the power OFF Do not unplug the power cable till the operation panel is turned off. Change Head Gap Low Turning the power off. 4.2.5.2 When Set the head height to Low.
Page 255 Insert ink cartridges correctly 6.1.1 wrong slots. again. Replacing ink cartridges [*] S/C Ink Err The ink cannot be used for Contact your local MUTOH 6.1.1 this printer. dealer. Replacing ink cartridges [*] S/C CodeErr Inserted Ink cartridge is not a Contact your local MUTOH —...
Page 256 Troubleshooting VJ-1324 OPERATION MANUAL Display Description Remedy Reference Life Times The life CR motor is almost Contact your local MUTOH — [CR Motor] expired. dealer. (Continues operation) Life Times The operational life of the PF Contact your local MUTOH —...
Page 257 • Start printing and measuring the color target again. • If you still have trouble, contact your local MUTOH dealer. Measurement Error Colorimeter has been Remove the colorimeter. 4.5 Using...
Page 258: Error Requiring Restart
For an error requiring restart, operation will return to normal after removing the cause of the error and restarting the printer. If the same error continues to be displayed, contact the your local MUTOH dealer. Be sure to tell us the code no. of the error message when you contact us.
Page 259: The Media Is Jammed
VJ-1324 OPERATION MANUAL Troubleshooting The media is jammed When the set media is jammed, follow the procedure below to remove it. 1. Turn OFF the power of the printer. 3.2.2 Turning the power OFF 2. Open the front cover. Name Front cover 3.
Page 260 Troubleshooting VJ-1324 OPERATION MANUAL 4. Raise the media loading lever. Name Media loading lever 5. Pull the media to your side, and cut the torn part with cutting tools such as a razor blade. Name Razor blade Roll media 7.3 The media is jammed...
Page 261 VJ-1324 OPERATION MANUAL Troubleshooting 6. Hold the both edges of the scroller to rewind the roll media by hands. Name Roll media Scroller 7. If paper dust or pieces of paper remain inside the printer, remove them. 7.3 The media is jammed...
Page 262 Troubleshooting VJ-1324 OPERATION MANUAL 7.3 The media is jammed...
Page 263: Appendix
VJ-1324 OPERATION MANUAL Appendix Appendix This chapter describes specifications and included components with this printer.
Page 264: Product Specifications
Appendix VJ-1324 OPERATION MANUAL Product specifications 8.1.1 Printer specifications Items Specification Model name VJ-1324 Printing method On-demand piezo drive system Drive system Firmware servo/DC motor drive Media feed system Multipoint pressurizing grid roller system Media fixing system Pressurization roller down system by manual lever Media feed/ejection Roll media Rear feed/Front ejection...
Page 265 VJ-1324 OPERATION MANUAL Appendix Items Specification Power Power voltage AC 90 V to AC 132 V / AC 198 V to AC 264 V Frequency 50 Hz/60 Hz ± 1 Hz Power consumption Printing 1550W or less Standby Outer diameter Height 1218mm (including the stands) Width...
Page 266: Interface Specification
Appendix VJ-1324 OPERATION MANUAL Interface specification This section describes each type of interface specifications supported by this product. 8.2.1 Network interface specification Items Specification Network type Ethernet IEEE802.3 Network I/F 10BASE-T/100BASE-TX Automatic transfer type (RJ-45 Connector twist pair cable) MDI/MDI-X Automatic transfer Corresponding protocol TCP/IP 8.2 Interface specification...
Page 267: Options/Supply List
VJ-1324 OPERATION MANUAL Appendix Options/Supply list For more information about the options and the supply items, contact your local MUTOH dealer. 8.3 Options/Supply list...
Page 268 Appendix VJ-1324 OPERATION MANUAL 8.3 Options/Supply list...
Page 269: Setup Menu Diagram
VJ-1324 OPERATION MANUAL Setup menu diagram Setup menu diagram For details of the Setup menu configuration diagram, refer to the followings. NOTE • For details of each setup item, refer to followings: • Setup menu diagram (Ready to Print): " "...
Page 270 Setup menu diagram VJ-1324 OPERATION MANUAL Setup menu diagram (Ready to Print) (1/4) Setup User Type to Setup menu diagram(Ready to Print) (2/4) <On> Spitting On Media <5 mm> to 25 mm Side Margin Media Initial Top&Width <Width> Media Width 210mm to <1,000 mm>...
Page 271 VJ-1324 OPERATION MANUAL Setup menu diagram Setup menu diagram (Ready to Print) (2/4) To Setup menu diagram (Ready to Print)(1/4) <Type 1> to Type 30 Print Mode Quality 1 Quality 2 Quality 3 Quality 4 Graphics 1 <Graphics 2> Graphics 3 Graphics 4 Banner 1 Banner 2...
Page 272 Setup menu diagram VJ-1324 OPERATION MANUAL Setup menu diagram (Ready to Print) (3/4) Setup to Setup menu diagram(Ready to Print) (1/4) Head Life Times Pump CR Motor PF Motor 000.000.000.000 to <192.168.001.253> to IP Address 255.255.255.255 000.000.000.000 to <255.255.255.000> to Subnet Mask 255.255.255.255 000.000.000.000 to <192.168.001.254>...
Page 273 VJ-1324 OPERATION MANUAL Setup menu diagram Setup menu diagram (Ready to Print) (4/4) To Setup menu diagram (Ready to Print)(1/4) Nozzle Check Test Print Mode Print SetUp List Palette Color Verify Short Cleaning Normal Long LittleCharge Initial Charge User Type Off / <On>...
Page 274 Setup menu diagram VJ-1324 OPERATION MANUAL Setup menu diagram (Receiving / Converting / Printing) Temperature Pre Heater Platen Heater Dryer Pre Heater Off/30 C to 50 C Platen Heater Off/30 C to 50 C Dryer Off/30 C to 50 C PF Micro Adj.
Page 275: Revision History
VJ-1324 OPERATION MANUAL Revision History General Information Date Version Manual code Supported Firmware 2011.3 VJ1324E-A-00 V.1.00 2012.2 VJ1324E-A-01 V.1.07 2013.10 VJ1324E-A-02 V.2.04 2014.2 VJ1324E-A-03 V.2.07...
Page 276 VJ-1324 OPERATION MANUAL...
