MUTOH Valuevet VJ-628X Maintenance Manual page 16

2.2 Troubleshooting with Error Messages
No. Message Event/symptom
3 End of Roll Media has run out.
4 No media Media is not loaded.
2.2.1 Operation Status
Table 2-1 Events and Check Items for Operation Status Messages (Continued)
Check item
1. Is the cable of P Rear Sensor placed
under Paper guide R securely
connected?
2. Check if there is paper in "Sen : Rear" in
the self-diagnosis function.
3. P Rear Sensor may need adjustment or it
may be damaged.
4. MAIN board may be damaged.
1. Check if there is paper in "Sen. : Rear" in
the self-diagnosis function.
Does the media in use have low
2.
?
reflectance
3. Is the cable of P Rear Sensor placed
under Paper guide R securely
connected?
4. P Rear Sensor may need adjustment or it
may be damaged.
5. MAIN board may be damaged.
Action
Securely connect it.
If "No media" is displayed even when paper is
loaded, check the item 5.
Adjust P Rear Sensor.
If the same error continues to be displayed,
replace P Rear Sensor.
Replace MAIN board.
If "No media" is displayed even when paper is
loaded, replace P Rear Sensor.
Instruct the user that media with low
reflectance cannot be used.
Securely connect it.
Adjust P_REAR sensor.
If the same error continues to be displayed,
replace P_REAR sensor.
Replace MAIN board.
VJ628XE-M-00
Reference
"Electric Wiring Diagram
"5.4.4Sensor Menu
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
"3.5.10Replacing MAIN Board
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
-
"Electric Wiring Diagram
"5.6.1Rear/ Edge Sensor Adjustment
"3.6.14Replacing P_REAR Sensor
"3.5.10Replacing MAIN Board
