MUTOH Valuevet VJ-628X Maintenance Manual page 215

4.3 Working with MUTOH Service Assistance Software
(4-b)Logging method
First, set the conditions in the Logging setting menu.
"(4-a)Logging setting
1
Check the time and interval.
2
Press the Start button.
2
If the logging data save folder is not set before pressing Start button, an error
message is displayed.
3
The message box is displayed to confirm the start of logging.
Click [OK].
4
Logging starts.
2
5
Logging starts date is registered.
4.3.11 Diagnostic Mode
6
Measuring counter starts counting up.
The logging data is saved in the designated folder every time it is logged in. Even
when logging is interrupted by clicking the [Finish] or [Cancel] button, the logging
data up to that point is saved.
7
When more than the set time has passed, a message box is displayed to confirm the end
1
of logging.
8
Click OK to go back to the Head temperature transition logging window and confirm the
logging data in the save folder.
The saved file name for the logging data is "Head_*_Tmp_Log.txt" (* is the head
number).
1
