10.1 Introduction
10.1 Introduction
This chapter provides referential information such as service data.
10.2 Maintenance Part List
The following table lists the maintenance parts per unit (as of April 30, 2015).
The part number below is identical to that of the exploded view.
Table 10-1 Board Box
Name No.
Head Cable Assy DF-49017
JUNC ID Cable Assy DG-44717 H-54
JUNCTION2 Board Assy DG-43396 H-48
MAINBoard Assy DG-44712 H-16
MAIN DC Cable Assy DG-42993 H-24
IL Dummy Cable Assy DG-44713 H-18
Cooling FAN (24V) Assy DG-45354 H-29
FG Cable Assy DG-43741 H-40
AC SEL SW Cable Assy DG-44720 H-62
Slide Switch Assy DG-44719 H-60
Power Board Assy DG-43172 H-21
AC JUNC-Power Cable Assy DG-44714 H-23
JUNC ID Cable 2Assy DG-44718 H-55
JUNC FFC Assy DG-44716 H-51
Inlet AC JUNC Cable Assy DG-44715 H-39
AC Inlet Assy DG-43177 H-37
Explod Remarks
ed
View
H-50 -
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Table 10-2 Y Rail Assy
Name No.
CR Motor Relay A1Assy DF-48991
CR Motor Assy DG-44693 B-40
Pressure Roller Spring DF-49691
Pressure Roller Assy DF-49053
Pressure Roller Axis Assy DF-49054
Pressure Arm Assy DF-49052
Fence Guide Assy DF-49027
T Fence Spring Assy DG-44690 B-83
CR HP Sensor, Lever Sensor DF-49471
CR Origin Sensor Cable Assy DG-44691 B-63
Lever Sensor Cable Assy DG-44692 B-65
CR Return Pulley Assy DF-49047
P_REAR Sensor Assy DG-42945 B-74
CR Belt A1Assy DF-49044
T Fence A1Assy DF-49024
VJ628XE-M-00
Explod Remarks
ed
View
B-43 -
-
B-16 -
B-18 -
B-19 -
B-17 -
B-82 -
-
B-62 -
-
-
B-49 -
B-50 -
-
B-44 -
B-81 -
