Product Activation Guide
Read before starting up the printer for the first time
Rev
ACTE-V-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VJ-628 and is the answer not in the manual?

Questions and answers

Related Manuals for MUTOH VJ-628

Summary of Contents for MUTOH VJ-628

  • Page 1 Product Activation Guide Read before starting up the printer for the first time ACTE-V-06...

  • Page 2: Table Of Contents

    Printer activation from the printer ..................... 3-1 3.1. Enter the code into the printer....................3-1 3.2. Reboot a printer ......................... 3-2 VJ-628/628X/628MP .......................... 4-1 VJ-404GT / 405GT..........................5-1 5.1. Enter activation code ........................5-1 5.2. Execute activation ........................5-3 XPJ-1682SR/1641SR/1682WR/461UF/661UF ..................

  • Page 3: Introduction

    See "3. Printer activation from the printer ". 4. When using following printer models ●VJ-628 ●VJ-628X ●VJ-628MP See "4. VJ-628/628X/628MP ". 5. When using following printer models ●VJ-404GT ●VJ-405GT See "5. VJ-404GT / 405GT ". 6. When using following printer models ●XPJ-1682SR/1641SR/1682WR...

  • Page 4: Printer Activation From Your Computer

    • The user must log on with administrator rights. (2) Work Flow 2-1. User Registration. 2-2. Connect printer to your computer. 2-3. Install MUTOH Status Monitor(MSM) into your computer. 2-4. Set up MSM 2-5. Register the printer and perform activation. 2-6. Reboot a printer.

  • Page 5: Complete User Registration

    Connect printer to your computer". If you use the computer that cannot be connected to the printer, follow the appropriate notes described in this document. Access to the MUTOH Club from the following URL and complete user registration. URL：https://club.mutoh.co.jp/mutoh/guser ACTE-V-06...

  • Page 6: Connect Printer To Your Computer

    Product Activation Guide 2.2. Connect printer to your computer 1. Install the printer. “Installation mnual” 2. Turn printer power on and set the IP address. NOTE  When connecting the printer to the network, there should be no IP address overlap between the printer and other network devices.
  • Page 7 Product Activation Guide 2-4 Press the [Enter] key on the operation panel to enable modification of the settings. • The default IP address “192.168.1.253” is displayed on the operation panel. • To go back to the previous menu, press the [Cancel] key. 2-5 Use the [+] or [-] keys to change the settings.
  • Page 8 Product Activation Guide 4. Turn on the computer and set the IP address. NOTE  If your computer is already connected to the network and the network settings have been already complete, skip this step.  The following explanation describes how to set up Windows XP by retaining the printer default IP address “192.168.1.253”...
  • Page 9 Product Activation Guide 4-4 If the printer IP address is "192.168.1.253", enter any value from "192.168.1.1" to "192.168.1.252" or "192.168.1.254" in [IP address] field. NOTE  When the printer IP address has been changed from the default value, specify the computer IP address field by entering the same values as those of the printer IP address up to the third dotted octet (third comma) and a different value for only the last dotted octet.

  • Page 10: Install Msm Into Your Computer

    If the initial setting has been already done, move to 2.5. Register printer and perform activation.  For the MSM initial setting procedure, see the MSM Operation Manual (3. Initial Setting).  In this initial setting, make sure to check [MUTOH Club Service] and log in to MUTOH Club. ACTE-V-06...

  • Page 11: Register The Printer And Perform Activation

    Product Activation Guide 2.5. Register the printer and perform activation. NOTE To register a printer, make sure  The printer is powered on.  The printer and your computer are connected over the network. 1. Register the printer. NOTE  For the printer registration details, see the MSM Operation Manual (3.9 Printer Registration).
  • Page 12 (3-a) Internet connection is available 1. The Activation window will change to the Releasing Activation Code window. • Printer activation is automatically performed by accessing MUTOH Club to obtain an "Activation Code".This may take a few minutes. 2. After successful activation, the Activation window changes to the Activation completion window.
  • Page 13 Product Activation Guide (3-b) Internet connection is not available If MSM cannot connect to the Internet, obtain an Activation Code or Activation Code File to manually perform activation. NOTE  Please contact your dealer to obtain an activation code or activation code file. Follow the procedure below to manually perform activation on MSM.

  • Page 14: Reboot A Printer

    Product Activation Guide 2. When activation is properly completed, the Activation completion window will be displayed. • Click [OK] to complete the operation. NOTE  If the activation fails, the error code will be displayed. Please inform your dealer and provide the error code (Err Code).

  • Page 15: Printer Activation From The Printer

    Product Activation Guide 3. Printer activation from the printer If the printer cannot be connected to a computer, you can activate the printer from the printer operation panel with the following steps. (1) Work Flow 3-1. Enter activation code from the operation panel. 3-2.

  • Page 16: Reboot A Printer

    Product Activation Guide 4. After entering the code, press the [Enter] key to execute the activation. • When activation is complete, "Reboot a Printer" will be displayed on the operation panel. • If the wrong code was entered, "Err! Reboot a Printer" will be displayed on the operation panel.

  • Page 17: Vj-628/628X/628Mp

    Product Activation Guide 4. VJ-628/628X/628MP These printer models come with the all-in-one installer CD. Start the installer and follow the set-up wizard to activate the printer. NOTE  For details, check the wizard instruction. ACTE-V-06...

  • Page 18: Vj-404Gt / 405Gt

    Product Activation Guide 5. VJ-404GT / 405GT You can activate VJ-404GT/405GT from the printer touch-screen panel. Follow the work flow steps below. Work Flow 5.1. Enter activation code 5.2. Execute activation 5.1. Enter activation code Obtain the activation code and enter the code with steps below. NOTE NOTE ...
  • Page 19 Product Activation Guide Click the left-most area of the input areas displaying [FFFF]. ● The code input boxes are displayed. NOTE  Input the 16-digit activation code in 4-digit sections. Use the numerical keyboard to input the activation code. ● Input the first 4 digits of the activation code. ●...

  • Page 20: Execute Activation

    Product Activation Guide Input the 5 to 16 digit code to the rest of input boxes. 5.2. Execute activation Press [Enter]. ●The printer will be activated with the code you entered. NOTE  When you need to input the activation code again, tap [Reset]. ...

  • Page 21: Xpj-1682Sr/1641Sr/1682Wr/461Uf/661Uf

    Product Activation Guide 6. XPJ-1682SR/1641SR/1682WR/461UF/661UF If the printer cannot be connected to a computer, you can activate the printer from the printer operation panel with the following steps. (1) Work Flow 3-1. Enter activation code from the operation panel. 3-2. Reboot the printer. 6.1.

  • Page 22: Reboot A Printer

    Product Activation Guide 3. Use the [^] and [v] keys to change the value in the ranges "0-9 and A-F". Use the [>] and [<] keys to change the input position. Activation required [Cancel] [Enter] 0000 - 0000 - 0000 - 0000 Press[Setting/Value+] or [Setting/Value-] 1234 - FFFF - 0000 - 0000 key to change the Activation code key.
  • Page 23 ACTE-V-06...
