5.6 Adjustment Menu
(1) "Head slant: slant 1"
(1-a)Confirming horizontal direction (left / right) (4-color setting)
Print Adjustment pattern
[Enter]
[Enter]
[Enter]
after printing [Enter]
Check Head Slant 1 (Horizontal)
1pass Uni-D/Bi-D
PF:360dpi CR:360dpi
Check the slant (Horizontal):
For CW printing, the nozzles combination are, from the media
origin side, A/C, A/E, B/D, B/F, and B/H.
320cps, VSD1, Small dot
Connecting point enlargement Ex. Nozzle A,C
(1) Check th eposition of Black and each color.
In , No need for adjustments.
In , it adjust, respectively and be set to
. Refer to the
4.7.1 Head Alignment (Horizontal Slant)
(2) Repeat printing and adjustment
until a result becomes
5.6.4 Head Slant Check Menu
Check the Slant (Horizontal) at Connecting points (Refer to the following and an enlargement.)
B H B
.
B F B B D B A
According to the width of media,
following adjustment pattern is printed on
three places or less.
for checking for checking
Vertical slant Horizontal slant
G A A E A A C
VJ628XE-M-00
Origin side
20mm
Nozzle
A
