MUTOH Valuevet VJ-628X Maintenance Manual page 404

Electric Wiring Diagram
Electric Wiring Diagram
1 2
PANEL Board Assy
connected
not connected
not mounted
DG- DF-
are Maintenance part number.
Cooling Fan(MAIN board)
AC
Inlet
DG-43741
Waste fluid Pump
DG-44715
DG-44714
AC
JUNCTION
Board Assy
DG-44710
(HEATER
DRIVE
Board Assy)
DG-44720
230V
Slide Switch
100/200V selection Switch
1 2
404P.11-404
3
DG-44727
DG-44726
F_Cover Sensor
DG-44729
(Inter lock)
MAIN Board Assy
DG-44713
P_REAR Sensor
DG-44723
Wiper Solenoid
DG-44711
DF-48995
Power Board Assy
DG-42993
DG-43172
DG-44695
DG-44695
3
4 5
DG-44703
DG-44703
DG-44703
DG-44703
DG-44703
DG-44699
DF-48991
DG-44694
DG-44712
DF-49017
DG-44717
Cable color (white/Black)
Circulation pump (origin side)
Circulation pump the opposite side of origin
Cable color White/Red
DG-45567
CR Origin Sensor
Lever Sesnor
DG-44716
DG-44718
4 5
6 7
DG-43318
CR Board Assy
DG-42959
PF Motor
PF Encoder
CR Motor
adsorption Fan
DG-44691
JUNCTION 2 Board
DG-44692
DG-43396
Exhaust Fan
Origin Side
JUNCTION 2 Board
DG-43396
Exhaust Fan
Oposite side
of Origin
2015.4.30 Rev.A
6 7
VJ628XE-M-00
8
CR Encoder
P_EDGE Sensor
DG-43315
PG Origin Sensor
Cutter Solenoid
DF-49018
DG-44687
DG-44687
DG-44687
DG-44687
I/C Cable 1 Assy
Micro Switch
INK ID Cable 1 Assy
I/C Cable 2 Assy
Micro Switch
INK ID Cable 2 Assy
I/C Cable 3 Assy
Micro Switch
INK ID Cable 3 Assy
I/C Cable 4 Assy
Micro Switch
INK ID Cable 4 Assy
I/C Cable 4 Assy
Micro Switch
INK ID Cable 4 Assy
I/C Cable 3 Assy
Micro Switch
INK ID Cable 3 Assy
I/C Cable 2 Assy
Micro Switch
INK ID Cable 2 Assy
I/C Cable 1 Assy
Micro Switch
INK ID Cable 1 Assy
Electric Wiring Diagram
Model : VJ-628X
8
