5.6 Adjustment Menu
(2) Measuring Platen reflecting value (Sensing Platen)
• Measuring AD values of Edge sensor at four positions of Platen.
• Measuring AD values at the four positions as shown below, and the AD values is
displayed on the panel.
Platen
After removing paper push [Enter] key
[Enter] or [Cancel]
5.6.1 Rear/ Edge Sensor Adjustment
(3) Input
NOTE
• Do not usually use this function.
• Use only in:
When any problems are occurred at paper recognition, while adjusting the sensor
at Calibration.
Origin side
When adjustment is needed for using environment (environment light , media type
and so on) of user.
• You can Set the sensor parameter manually which was adjusted automatically at
Calibration.
• Setting values are displayed immediately.
AD (Sensor reflecting value) : 0 to 255
[Cancel]
[Enter]
[Enter]
Setting by
/ Key
VJ628XE-M-00
[Enter]
When saving setting values,
push [Enter] key while
displaying Edge VR
