2.2 Troubleshooting with Error Messages
No. Message Event/symptom
4 Ink cartridge is not
［*］No cartridge
*Ink color is inserted.
displayed in the
［*].
5 Broken Chip A dedicated S/C card
S/C Color Err may be malfunction.
S/C Ink Err
S/CCode Err
6 Full wasteInkTank Waste fluid bottle is full. 1.
2.2.2 Errors with Message
Table 2-2 Symptoms and Check Items for Errors with Message(Continued)
Check item
5. Check the connection of JUNC_ID cable.
6. Check the connection of JUNC_FFC.
7. At the connection point of the ink tubes, ink
leakage, or bleeding did not occur?
8. I/C cable may be damaged.
9. JUNC_ID cable may be damaged.
10. JUNC_FFC may be damaged.
11. Ink ID board Assy may be damaged.
12. JUNCTION Board may be damaged.
13. MAIN board may be damaged.
1. Check if the message is displayed after
turning off the printer and turning it back on.
2. Check if the dedicated Smart chip cards are
used.
3. Check if the dedicated Smart chip cards are
broken or the chip portion is damaged.
4. Check if ink ID is correctly recognized in the
self-diagnosis function.
5. Ink ID board Assy may be damaged.
Check if Waste fluid bottle is full.
2. Check the connection of the connector of
Waste fluid level switch.
3. JUNCTION board may be damaged.
4. MAIN board may be damaged.
Action
Make sure to connect it securely.
Make sure to connect it securely.
Check the connection of Ink tube.
Replace I/C cable.
Replace JUNC_ID cable.
Replace JUNC_FFC.
Replace Ink ID board.
Replace it.
Replace MAIN board.
When the message is displayed: Refer to the
check item 2.
Replace with the dedicated Smart chip cards.
Replace Ink ID board.
Dispose of waste fluid.
Re-insert the connector of the waste liquid level
switch.
Replace it.
Replace it.
