8.2 Part Names and Functions
No. Name Normal
7 [Forward↓] key Media is fed in the forward
direction.
[–] key
-
8 [Power] key Turns printer ON and OFF.
(2-b)Display section
No. Name Color Status
9 Power lamp Blue Lamp
Power ON.
ON
Lamp
• Data is received and analyzed.
blinks
• Performing media initial operation.
Lamp
Power OFF.
OFF
10 Error lamp Oran Lamp An error has occurred
ge ON The error content is displayed on the LCD
Lamp The remaining amount of ink is low.
blinks
Lamp There is no error.
OFF
11 Heater Link Gree Lamp Blower heater is in the "Printer Link" condition.
lamp n ON
Lamp Blower heater is in the "Manual" condition.
OFF
12 Origin lamp Gree Lamp "Origin" is activated.
n ON
Lamp "Origin" is deactivated.
OFF
8.2.2 Operation panel
Setup menu display
-
• Changes to the previous item
in the displayed setting.
• The setting is changed to the
reverse direction.
• The numeric value is
decreased during numerical
input.
Turns printer ON and OFF.
Description
No. Name Color Status
13 Roll lamp Gree Lamp "Roll media" is set as "Media type".
n ON
14 Rigid lamp Gree Lamp "Media type" is set as "Rigid".
n ON
15 Long lamp Gree Lamp • Cleaning Mode is set to Long.
n ON • When the Normal lamp is also turned on, Cleaning
Mode is set to Short.
Lamp Cleaning Mode is set to Normal.
OFF
16 Normal lamp Gree Lamp • Cleaning Mode is set to Normal.
n ON • When the Long lamp is also turned on, Cleaning
Mode is set to Short.
Lamp Cleaning Mode is set to Long.
OFF
17 LCD display - - Displays operation status of the printer or an error
section message.
