5.6 Adjustment Menu
(1-c)Confirming horizontal direction (left / right) (6-color setting)
Print Adjustment pattern
[Enter]
[Enter]
[Enter]
after printing [Enter]
Check Head Slant (Horizontal)
T I P
1pass Uni-D/Bi-D
PF:360dpi CR:360dpi
Check the slant (Horizontal) :
For CW printing, the nozzles combination are, from the media
origin side, A/C, A/E, B/D and B/F.
320cps,VSD1,Small dot
Connecting point enlargement Ex. Nozzle A,C
(1) Check th eposition of Black and each color.
In , No need for adjustments.
In , it adjust, respectively and be set to
. Refer to the
4.7.1 Head Adjustment (Horizontal Slant)
(2) Repeat printing and adjustment
until a result becomes .
5.6.4 Head Slant Check Menu
Check the Slant (Horizontal) at Connecting points (Refer to the following and an enlargement.)
Nozzle
According to the width of media,
following adjustment pattern is prnted
on three places or less.
for checking Vertical slant
B F B B D B A
VJ628XE-M-00
Origin side
for checking Horizontal slant
20mm
E A A C A
