By default, station group '00' is assigned to all trunks during Day time as well as during Night time.
• Exit SE mode.
Example:
Program the system for following requirements:
• 3 CO lines (S/w ports 0 to 2) are interfaced with VISIONPRO.
• First two CO lines, CO1 and CO2 should land on station 21, 23, 25, 22 (S/w port 00, 02, 04, 01
respectively) during Day time. Rotation must be allowed.
• CO1 and CO2 should ring on each station for 10 seconds. Station should ring in the given sequence only.
• First two CO lines, CO1 and CO2 should land on station 21 (S/w ports 00) during Night time.
• CO1 and CO2 should ring on station 21 continuously.
• Third line should land on station 28 and 29 (S/w port 07 and 08 respectively) simultaneously during Day
time and Night time.
• CO3 should ring continuously on both the stations.
Solution. Dial following commands in SE mode,
Make Group 0 as per the requirement:
4702-1-00-0-00 (to configure the station group)
4702-1-00-1-02
4702-1-00-2-04
4702-1-00-3-01
4703-1-00-0-10 (to configure the Ring Timer)
4703-1-00-1-10
4703-1-00-2-10
4703-1-00-3-10
4704-1-00-0-0 (to configure continuous or non-continuous ring)
4704-1-00-1-0
4704-1-00-2-0
4704-1-00-3-0
4705-1-00-1 (to configure the rotation method)
Make Group 1 as per the requirement:
4702-1-01-0-00 (to configure the station group having the same station)
4702-1-01-1-00
4702-1-01-2-00
4702-1-01-3-00
4703-1-01-0-10 (to configure the Ring Timer)
4703-1-01-1-10
4703-1-01-2-10
4703-1-01-3-10
4704-1-01-0-1 (to configure continuous or non-continuous ring)
4704-1-01-1-1
4704-1-01-2-1
4704-1-01-3-1
