Matrix Visionpro System Manual page 54

If required, default a station group using command 4701.
5.
If written on a plain sheet of paper, each group entry in the station group table would appear as shown below.
Station Number
Ring Timer
Continuous Ring
Rotation Method
To configure as per above instructions,
• Enter SE mode.
• To configure a station in a station group, dial,
4702-1-Station Group-Destination Index-Station
Where,
Station Group is from 00 to 15.
Destination Index is from 0 to 3.
Station is a software port number and varies from 00 to 07.
• To configure the same station in the same destination index in all station groups, dial,
4702-*-Destination Index-Station
• To configure the Ring Timer for which each station in the group should ring, dial,
4703-1-Station Group-Destination Index-Timer
Where,
Station Group is from 00 to 15.
Destination Index is from 0 to 3.
Timer is in seconds from 00 to 99.
• To configure the same Ring Timer value for stations with the same destination index in all station
groups, dial,
4703-*-Destination Index-Timer
• To configure continuous or non-continuous ring for a destination in the group, dial,
4704-1-Station Group-Destination Index-Continuous Ring
Where,
Station group is from 00 to 15.
Destination Index is from 0 to 3.
Continuous Ring Meaning
0 The station rings for the timer set
1 The station rings continuously till the call is answered
• To configure continuous or non-continuous ring for stations with the same destination index in all
station groups, dial,
4704-*-Destination Index-Continuous Ring
• To configure the rotation method for a station group, dial,
4705-1-Station Group-Rotation Method
Where,
Station group is from 00 to 15.
Rotation Method Meaning
0 Fresh call should always land on the first station within the group
Matrix VISIONPRO System Manual
Dest0 Dest1
Yes or No
Dest2 Dest3
