Matrix Visionpro System Manual page 66

Trunk is the software port number from 0 to 2.
Code Pause Timer
0 500ms
1 1000ms
2 1500ms
3 2000ms
4 2500ms
Default code value is 1.
• To configure the same Pause Timer for all trunks, dial,
3106-*-Code
• To configure the Receive Gain (in dB) for a trunk, dial,
3107-1-Trunk-Code
Where,
Trunk is the software port number from 0 to 2.
Code Gain in
(dB)
01 10
02 9.5
03 9
04 8.5
05 8
06 7.5
07 7
08 6.5
09 6
10 5.5
11 5
12 4.5
13 4
14 3.5
15 3
16 2.5
17 2
18 1.9
19 1.8
20 1.7
Matrix VISIONPRO System Manual
Code Gain in
(dB)
22 1.5
23 1.4
24 1.3
25 1.2
26 1.1
27 1
28 0.9
29 0.8
30 0.7
31 0.6
32 0.5
33 0.4
34 0.3
35 0.2
36 0.1
37 0
38 -0.1
39 -0.2
40 -0.3
41 -0.4
Code Gain in
(dB)
43 -0.6
44 -0.7
45 -0.8
46 -0.9
47 -1
48 -1.1
49 -1.2
50 -1.3
51 -1.5
52 -1.6
53 -1.7
54 -1.8
55 -1.9
56 -2
57 -2.5
58 -3
59 -3.5
60 -4
61 -4.5
62 -5
Code Gain in
(dB)
64 -6
65 -6.5
66 -7
67 -7.5
68 -8
69 -8.5
70 -9
71 -9.5
72 -10
73 -10.5
74 -11
75 -11.5
76 -12
77 -12.5
78 -13
79 -13.5
80 -14
81 -14.5
82 -15
60
