• However for special types of requirements, customized Allowed and Denied Lists should be
programmed and should be assigned to a CDC table. Then after this CDC table should be assigned to
a station. Refer
starting with '0' except those starting with '022', configure an allowed list with string '022' and denied
list with string '0' and assign these lists to the CDC table.
• By default, CDC table 0 is assigned to each station.
As you know which parameters need to be configured for the CDC tables, proceed as follows,
Take a pen and a paper. Decide the types of Call Duration Controls to be programmed for each station.
1.
If the requirement can be met by using the default CDC tables, assign a default CDC table to a station
2.
using command 4920.
If the requirement cannot be met by the default CDC tables then configure the relevant parameters, for
3.
example, enabling CDC for Outgoing/Incoming calls, configuring the disconnection flag, CDC timer etc.
This completes programming one CDC table. Program remaining three CDC tables likewise, if required.
Assign the desired CDC table to the station using command 4920.
4.
A CDC table can be set to default using command 4901.
5.
As per above instructions, configure the following.
• Enter SE mode.
• To assign a CDC table to a station user, dial,
4920-1-Station-CDC table
Where,
Station is from 00 to 07.
CDC table is from 0 to 3.
• To assign the same CDC table to all stations at once, dial,
4920-*-CDC Table
If your requirement can be met by using the default CDC tables, you can leave after executing only the
above commands. If the requirement cannot be met by the default CDC tables then configure the relevant
CDC table parameters as described in following instructions.
• To enable/disable CDC for Outgoing Calls in a CDC table, dial,
4910-1-CDC Table-Code
Where,
CDC Table is from 0 to 3.
Code Meaning
0 CDC for Outgoing Call is to be disabled
1 CDC for Outgoing Call is to be enabled
• To enable/disable CDC for Outgoing Calls in all CDC tables at once, dial,
4910-*-Code
Matrix VISIONPRO System Manual
"Allowed and Denied Lists" for more details. For example, to disconnect all calls
