  • Page 4 Quick Start carefully to install and program this ultra-compact, Small and Home Office PBX. Know your PROTON 103 The PROTON 103 is an entry-level PBX with one trunk and three stations. The three stations are numbered as 2, 3 and 4 respectively. Figure 1: Overview of PROTON 103.
  • Page 5 7/27/2019 Proton-103 v1 Quick Start Figure 2: Trunk Port and Station Ports. Push back the Push back the Trunk Terminal Station 1 (2) Terminal using thumb. using thumb. Connect Connect Wires. Wires. Figure 3: Default Jumper Position.  A-B Position B-C Position Figure 4: LED indication.

  • Page 6: Before You Start

    7/27/2019 Proton-103 v1 Quick Start Figure 5: Removing the cover of PROTON 103. Push down with fingers. Before you Start Verify the package contents Unpack the box. Make sure that the package contains all the following items. If any item is missing or damaged, please contact the dealer/ reseller who sold you the PBX.
  • Page 7 (supplied). The screws must protrude slightly from the wall. Align the keyhole slots with the screws fixed on the wall. Slide the PROTON 103 down on the screws to secure it on the wall. Or ...
  • Page 8 10. Switch On mains to power the PROTON. The power LED, ‘ON’, will be turned on when mains switch is operated. Step 2: Configuring PROTON 103 PROTON is programmed by dialing code sequences for each station and feature group. The code sequence is typically: Dial Code-Station Number-Code.
  • Page 9 Dial 42-2 to set Station 2 as destination for Night Mode. Follow the same steps for Station 3 and 4. Exit Programming Mode • Dial ‘0’  . • You will hear the dial tone. Congratulations! PROTON 103 is now fully operational with its PBX features. http://slidepdf.com/reader/full/proton-103-v1-quick-start 9/12...
  • Page 10 Reinstate Default Setup? • Dial 19-Password (if not changed, use default 1234). • Dial 18-Password  - get confirmation tone. • Reconfigure the PROTON 103. Change Programming Password? • Dial 21-New Password (max. 4 digits). Forgot Programming Password? To restore default password: •...

  • Page 11: Step 3: Test Calls

    7/27/2019 Proton-103 v1 Quick Start Step 3: Test Calls Making a call  To make an external call: • Lift the handset. • Dial ‘0’  . • Wait for Dial tone. • Dial the desired number. • Talk. • Replace the handset to disconnect. To call another station: •...
  • Page 12 7/27/2019 Proton-103 v1 Quick Start MATRIX COMSEC PVT. LTD. Corporate Office: 394-GIDC, Makarpura, Vadodara - 390010, India. Tel.:+91 265 2630555, Fax: +91 265 2636598 E-mail: Info@MatrixComSec.com    0 Factory:    1    0 39-GIDC, Waghodia - 391760, Dist. Vadodara, India.    2 Tel.: +91 2668 262056/57   y...
