Matrix Visionpro System Manual page 52

On-hook Detection Current
Code
or lower (in mA)
2
3
4
Default is 1 (10mA)
• To configure the same On-hook Detection Current or lower for all stations at once, dial,
4119-*-Code
• To configure the Ring Type/Ringing Signal for a station, dial,
4120-1-Station-Code
Where,
Station is the software port number of the station from 00 to 07.
Code Ring Type/Ringing Signal
0 Low Sinusoidal
1 Low Trapezoidal
2 Sinusoidal
3 Trapezoidal
Default is 3 (Trapezoidal)
• To configure the same Ring Type/Ringing Signal for all stations at once, dial,
4120-*-Code
• To configure the Internal Inter Digit Wait Timer for the system, dial,
3009-Seconds
Where,
Valid Range: 000 to 255 seconds.
Default is 007 seconds.
• Exit SE mode.
