Trunk Landing Groups (TLGs)
A Trunk Landing Group is a group of stations on which incoming calls on a particular trunk land. VISIONPRO can
be configured to land trunk calls from different trunks on different stations during Day time and Night time.
VISIONPRO uses the station groups for this purpose where multiple stations can be present. It is possible to assign
a station group to a trunk. The trunk call would land on these stations as per the programming of the station group.
How it works
•
A station group should be assigned to a trunk as the Trunk Landing Group.
•
Different station groups can be assigned to a trunk during Day time and Night time. Incoming calls on a
trunk can be made to land on different stations during Day time and Night time.
•
By default, station group '00' as assigned to all trunks.
•
If the landing destination has set Call Forward, then calls landing on this trunk will be forwarded
accordingly.
How to configure
Decide the number of station groups to be used as Trunk Landing Groups, define a station group using
1.
commands 4702, 4703, 4704 and 4705. Refer
Assign a station group to a trunk for Day time using command 3301.
2.
Assign a station group to a trunk for Night time using command 3302.
3.
To configure as described in the above steps,
•
Enter SE mode.
•
Program the station groups as per your requirement. Refer
•
To assign a station group as the Trunk Landing Group for a trunk during Day time, dial,
3301-1-Trunk-Station Group
Where,
Trunk is the trunk software port from 0 to 2.
Station Group is from 00 to 15.
•
To assign the same station group as the Trunk Landing Group for all the trunks during Day time, dial,
3301-*-Station Group
•
To assign a station group as the Trunk Landing Group for a trunk during Night time, dial,
3302-1-Trunk-Station Group
Where,
Trunk is the trunk software port from 0 to 2.
Station Group is from 00 to 15.
•
To assign the same station group as the Trunk Landing Group for all the trunks during Night time, dial,
3302-*-Station Group
77
"Station Groups"
for more details.
"Station Groups"
for details.
Matrix VISIONPRO System Manual
