  • Page 1 User Manual...

  • Page 2: Table Of Contents

    EN_Contents Welcome Packing List Diagram-Ninebot F3 Diagram-Ninebot F3 Pro Assembly Activation App Features Apple Find My Network Charging How to Ride WARNINGS Folding, Carrying, Unfolding Inflate the Tires Specifications Appendix: Phone Holder Installation Riding Safety Maintenance Recommended Maintenance Schedule Certifications Trademark Legal Statement Contact...

  • Page 3: Welcome

    Welcome Thanks for choosing the Segway eKickScooter Ninebot F3 series product! Segway Mobility 140 cm+ (4'6''+) Always wear a helmet, elbow pads and knee pads when riding. WARNING: The Segway Mobility App contains additional and/or supplemental warnings and instructions for the safe use of the eKickScooter.

  • Page 4: Packing List

    Packing List Note: Please keep the orginal packaging *The illustrations below are provided for at least 15 days! using the F3 Pro as an example. ● F3 Series ● Product Instructions ● Accessories ○ ○ Information Card × 1 Charger ×...

  • Page 5: Diagram-Ninebot F3

    Diagram-Ninebot F3 ○ ○ Handlebar Dashboard ○ ○ Snap Hook Brake Lever ○ ○ Left Direction Indicator Stem ○ ○ Folding Latch Charging Port ○ ○ Quick-release Lever Footboard ○ ○ Folding Mechanism Headlight ○ ○ Locking Loop Rear Shock Absorber ○...

  • Page 6: Diagram-Ninebot F3 Pro

    Diagram-Ninebot F3 Pro ○ ○ Handlebar Dashboard ○ ○ Snap Hook Brake Lever ○ ○ Left Direction Indicator Stem ○ ○ Folding Latch Charging Port ○ ○ Quick-release Lever Footboard ○ ○ Folding Mechanism Headlight ○ ○ Locking Loop Rear Shock Absorber ○...
  • Page 7 Press the button to use bell. *Hill-Hold Assist: After enabling this function in the Segway Mobility App, press the custom button to quickly activate Hill- Hold Assist when the vehicle is at complete stop. At this time, the driving wheel will be locked and the vehicle will not move forward when using the throttle.
  • Page 8 ● Dashboard Icon Name Description Left / Right The indicator flashes after pressing a direction indicator button. Both sides Direction direction indicators flash simutaneously after Emergency Flashers are turned Indicator When the icon lights up, it indicates that the scooter has been successfully Bluetooth connected to the mobile device.
  • Page 9 ● Speed Modes Speed Limit Model Mode 051701A 051702A （ECO Mode） 12 km/h （7.5 mph） （Drive Mode） 20 km/h (12.4 mph) （Sport Mode） 25 km/h (15.5 mph) （Walk Mode） 5 km/h (3.1 mph)

  • Page 10: Assembly

    Assembly Step 1 Open Close Unfold the stem and close the quick-release lever until the folding latch reaches the bottom. Make sure the quick release lever is locked firmly when you push the quick release lever down without lifting folding latch. Step 2 Slide the handlebar and the wires into the stem with the headlight facing forward.
  • Page 11 Step 3 Lift the vehicle out of the box, place it on the ground, and unfold the kickstand. WARNINGS Power off the scooter before assembly. The brake cable should not wrap around the stem.

  • Page 12: Activation

    Additional and/or supplemental warnings and instructions Scan the QR code to download the on how to use the product are also in the Segway Mobility Segway Mobility app to register or log in. app, and such information and/or notice is part of the user materials that an user shall know and learn.

  • Page 13: App Features

    Charging Limit *Notes on Energy Recovery Function: Function Introduction: Set the “Energy Recovery” level in the “Segway Mobility” App: Off/Strong/Weak ○ By default, the vehicle’s Energy Recovery feature is set to “off.” Users can enable or disable the Energy Recovery function in the “Segway Mobility”...
  • Page 14 ○ Once the Energy Recovery is enabled, it will remain on until the function is manually turned off via the “Segway Mobility” App. The feature is not automatically disabled in the event of the vehicle shutting down or running out of battery. The vehicle’s dashboard does not display Energy Recovery status, which can only be verified and adjusted (Off/Strong/Weak) in...
  • Page 15 ● CodeLock Enable / Disable CodeLock via Segway Mobility App, at homepage >> More Functions >> Locking Function, and choose DigitalCodeLock or Pattern CodeLock. ○ DIgital CodeLock Step 1 Step 3 Rider can also press the left and right buttons to check Enable Digital CodeLock via the App.
  • Page 16 ● Segway AirLock Enable/Disable AirLock via Segway Mobility App, at homepage >> More Functions >> Locking Function. ○ Pattern CodeLock Step 1 Step 1 Enable Pattern CodeLock via the App. Set a 4~8 password Set digital or pattern unlocking passcode first via the App.
  • Page 17 ○ After setting, if the vehicle detects abnormal movement Step 1 in a powered off state, the buzzer will send out an alert Enable Scheduled Charging via Segway Mobility App and for 5 seconds (a short alert every 0.5 second), and the set the charging schedule.

  • Page 18: Apple Find My Network

    A or B) Method A Method A Connect vehicle with Segway Mobility app, and enable Connect vehicle with Segway Mobility app, and disable Find My at homepage >> More Functions >> Locating Find My at homepage >> More Functions >> Locating vehicle >>...
  • Page 19 Owner can enable & disable Find My Beacon by squeezing Owner can update the firmware after connecting the brake lever by 9 times and pressing power button once in eKickScooter to Segway Mobility App. Non-owner is not unlocked status (position information). allowed to update the firmware.
  • Page 20 *Nearby Status and Separated Status If the vehicle has been paired with Find My, when the Only users of Apple devices need to read this Apple Find owner leaves away from the vehicle or turns off the My app instruction. Bluetooth of his or her mobile device after a riding, the vehicle will automatically enter Nearby status after a short * Use of the Works with Apple badge means that a...

  • Page 21: Charging

    Charging Step 1 Red——charging Open the charging Green——trickle charge port rubber plug. Step 2 Insert the charge plug. Step 3 Fasten the rubber plug when finished. WARNING! ○ Do not charge the battery if the charge port, the battery WW charger or power cord is wet. ○...
  • Page 22 When the battery power is under 30% and the vehicle is not powered on for about 7 consecutive days, the battery will enter into sleep mode. If this happens, your vehicle cannot be powered on. Please charge it for three seconds to activate the battery.

  • Page 23: How To Ride

    Note: For your safety, the motor will not engage until the eKickScooter reaches 3 km/h (1.9 mph). The Start Speed can be adjusted via Segway Mobility App. *Braking distance may vary significantly depending on the rider's weight and other conditions. Heavier riders may experience longer brake distances.
  • Page 24 Auto Headlight mode, then the headlight will direction indicator button. Press again to turn off. turn on/off in accordance with the ambient brightness. *Auto Headlight can be disabled via Segway Mobility App. Step 2 Slightly turn the handlebar to turn left/right.
  • Page 25 ● Cruise Control When the speed > 3.1 mph (5 km/h), press and hold the Cruise Control Button for two seconds to enable Cruise Control. Two beeps will be sounded and the cruise control icon will remain on when the vehicle enters cruise control. Press the Cruise Control button, use the throttle, or squeeze the brake lever to exit the cruise control.

  • Page 26: Warnings

    WARNINGS Always wear a helmet while DO NOT wear high heels when DO NOT overtake. riding. riding. DO NOT carry any passengers. DO NOT ride up and down stairs DO NOT ride the scooter with or jump over obstacles. only one foot or one hand. DO NOT park in the open space Watch your head when passing Avoid contacting obstacles with...
  • Page 27 DO NOT twist / press the throttle DO NOT carry heavy objects on Control your speed when going while pushing vehicle. the handlebar. downhill. DO NOT rotate the handle Do NOT keep your feet on the rear DO NOT use a mobile phone or violently while driving at high speed.
  • Page 28 DO NOT touch the brake after DO NOT touch the hub motor Avoid potholes. riding. after riding because it can get hot. SECURE your scooter properly during transportation to avoid battery damage from collision.

  • Page 29: Folding, Carrying, Unfolding

    Folding, Carrying, Unfolding ● Folding Step 1 Lift folding latch up and open the quick-release lever, then press the lever again and fold the stem. Step 2 Align the snap hook with the illustrated area at the rear of the pedal and press it down to hook onto the buckle.
  • Page 30 ● Carrying Lift by the stem to carry. ● Unfolding Disengage the snap hook from the buckle. Unfold the stem and close the quick-release lever. Make sure the folding latch reaches the bottom.
  • Page 31 Press the quick release lever firmly to make sure the × √ folding mechanism is tightened. * The scooter will make a "click" sound when the folding mechanism is tightened. × √ Make sure the folding latch is in the locked position before riding! * Stop riding immediately if the folding latch somehow cannot be locked.

  • Page 32: Inflate The Tires

    Inflate the Tires Step 1 Unscrew the valve cap. Step 2 Connect the valve stem extension to the tire valve stem. Caution: Ensure tires are properly inflated before riding. Operating the scooter with underinflated tires can cause permanent damage to the tires, affect riding safety, and may lead to the motor overworking and overheating (which could cause the motor to shut off unexpectedly).

  • Page 33: Specifications

    Specifications Item Parameter Name Segway eKickScooter Ninebot F3 Segway eKickScooter Ninebot F3 Pro Model 051701A 051702A L × W × H 1152 × 590 × 1262 mm (45.4 × 23.2 × 49.7 in) Product Info L × W × H 1152 ×...
  • Page 34 Item Parameter Nominal Energy 477 Wh Nominal 10.2 Ah Capacity Charging Ambient 0—55℃ (32—131°F) Battery Pack Temperature Charge Time Tracking, Smart Charge Scheduling, Battery Health Monitoring, Battery Short Circuit Protection, Overcurrent Protection, Temperature Protection, Management Overcharging Protection, Under Voltage Protection, Over-discharging System Protection, Customizable Charging Limit, IPX7 Water-resistant Battery Pack Nominal Power...

  • Page 35: Appendix: Phone Holder Installation

    Appendix: Phone Holder Installation As shown in the picture, use appropriate tool to dismantle Install the phone holder in the place of the original the removable part. Removable Part. (For specific installation steps, please refer to the phone holder manual). Note Phone Holder shall be purchased separately.

  • Page 36: Riding Safety

    Ninebot (Beijing) Tech Co., Ltd. and its subsidiaries and affiliates) , hereinafter referred to as, collectively, Ninebot Inc. nor Segway Inc. is responsible for any injuries or damage caused by a rider's inexperience or failure to follow the instructions in this document.
  • Page 37 Only use the original supplied charger. Do not use a charger from any other product models. 13. Use only Ninebot or Segway approved parts and accessories. Do not modify your eKickScooter. Modifications to your eKickScooter could interfere with the operation of the eKickScooter, could result in serious injury and/or damage, and could void the Limited Warranty.

  • Page 38: Maintenance

    ● DO NOT modify your eKickScooter. Modifications to your eKickScooter could interfere with the operation and performance of the eKickScooter, which may result in serious injury and/or damage, and could void the Limited Warranty. Only use Ninebot or Segway approved parts and accessories. Cleaning Use a soft, wet cloth to wipe the mainframe clean.
  • Page 39 NOTE 1. When the scooter is powered off, it will still cause battery consumption. If the scooter is not in use for a long time, charge the battery to 50% or above before storage. It's recommended to charge the battery once every 30 to 60 days, or it may cause damage to the battery performance due to over-discharge.

  • Page 40: Recommended Maintenance Schedule

    Recommended Maintenance Schedule To ensure safe riding, day to day care and regular maintenance are essential. You, the owner, have control and knowledge o f how often you use your scooter, how hard you use it and where you use it. It is the owner's responsibility to perform regular checks and bring your scooter to authorized service center for inspection and service.
  • Page 41 Every Every 6 Every 1 3 years months or year or Every 3 or every Item Component Maintenance Method every 500 every months 20,000 km (310 1,000 km km (12,427 miles) (621 miles) miles) To accelerate and decelerate, Function Hub Motor check if the hub motor is stalled or √...
  • Page 42 Press and hold the throttle, then Throttle release it, checking for acceleration √ √ √ and deceleration. After connecting with the Segway- Ninebot app: 1) Update the firmware to the latest version. App Detection √ √ √ 2) Check if the notification of the...
  • Page 43 Every Every 6 Every 1 3 years months or year or Every 3 or every Item Component Maintenance Method every 500 every months 20,000 km (310 1,000 km km (12,427 miles) (621 miles) miles) Controller Hub Motor Rear Wheel Assembly Throttle &...

  • Page 44: Certifications

    Certifications Neither Segway Inc. nor Ninebot is responsible for any changes or modifications not expressly approved by Segway Inc. or Ninebot. Such modifications could void the user's authority to operate the equipment. Use of the Works with Apple badge means that a product has been designed to work specifically with the technology identified in the badge and has been certified by the product manufacturer to meet Apple Find My network product specifications and requirements.

  • Page 45: Trademark

    Ninebot is the trademark of Ninebot (Beijing) Technology Co., Ltd., Powered by Segway and Rider Design are trademarks of Segway Inc., App Store, Apple logo, Apple, Apple Find My, AppleWatch, Find My, iPhone, iPad, iPadOS, Mac, macOS and watchOS are trademarks of Apple Inc. IOS is a trademark of Cisco and is used under license. Google Play and the Google Play logo are trademarks of Google LLC.

  • Page 46: Legal Statement

    The consequences for such an incident can be severe, including but not limited to injuries, bodily injuries, death, and/or damages to property. Segway shall not be liable for any claim, liability, and loss related to such consequences if it is due to the user's assumption of risk.

  • Page 47: Contact

    9. Segway reserves the right to make changes to the eKickScooter, release firmware updates, and update this manual at any time. Segway may make improvements and changes to the User Manual or the Important Information necessitated by typographical errors, inaccuracies of current information, or modifications to programs and/or equipment at any time and without notice.
  • Page 48 FOR FUTURE REFERENCE. THIS AGREEMENT CONTAINS LIMITED WARRANTY CLAUSES FOR CONSUMERS IN ASIA, PACIFIC, MIDDLE EAST & RUSSIA AND ARBITRATION CLAUSES WITH RESPECT TO SEGWAY EKICKSCOOTER NINEBOT MAX G3 (“PRODUCT”) AND ANY AND ALL TRANSACTION AND CLAIM RELATED TO AND/OR ARISING OUT OF THE PRODUCT.

  • Page 49: Limited Warranty

    Limited Warranty. The applicable Limited Warranty Period for the Limited Warranty commences on the date of the original purchase of the Product from either of Segway, Segway’s authorized reseller, Segway’s authorized distributor, or an authorized Dealer (each a “Segway Dealer” or collectively the “Segway Dealers”).

  • Page 50: Limited Warranty Service Process

    In the event the warranty services are required, please prepare for the following materials including (i) proof of the original purchase of the Product from Segway distributors, or resellers, or seller, or parties, or dealers, (ii) the Product’s serial number, and (iii) a description of the defect if applicable. Upon the verification of your eligibility to the Limited Warranty protection and/or services, you should provide your name, email address, and contact phone number.

  • Page 51: Limited Warranty Eligibility

    3.2.Your Product must be purchased from a Segway authorized reseller, or dealer, or distributor or parties. If not, you won't be able to enjoy the warranty rights of the genuine article, and you won't be able to receive the protection of the legal framework.

  • Page 52: Liability Disclaimer And Limitation

    5 LIABILITY DISCLAIMER AND LIMITATION NINEBOT AND OTHER NINEBOT PARTIES DO NOT ASSUME, OR AUTHORIZE ANYONE TO ASSUME ON ITS BEHALF, ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH A PRODUCT, ITS COMPONENT PARTS, ACCESSORIES, SERVICE REPAIR, OR THIS LIMITED WARRANTY. NINEBOT AND OTHER NINEBOT PARTIES ARE NOT RESPONSIBLE FOR ANY LOSS OF USE OF A PRODUCT, ITS COMPONENT PARTS, ACCESSORIES, OR FOR ANY INCONVENIENCE OR OTHER LOSS OR DAMAGE WHICH MIGHT BE CAUSED FROM ANY DEFECT IN A PRODUCT, ITS COMPONENT PARTS, ACCESSORIES, SERVICE REPAIR, OR...
  • Page 53 DAMAGES, SO TO THE EXTENT THAT SUCH LIMITATIONS OR EXCLUSIONS ARE NOT ALLOWED BY LAW, THEY MAY NOT APPL Y TO YOU. SOME COUNTRIES/STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPL Y TO YOU. TO THE EXTENT PERMITTED BY APPLICABLE LAW, NINEBOT PARTIES HEREBY DISCLAIM ANY LIABILITY AND THEREBY SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES, INCLUDING BUT NOT LIMITED DEATH, BODIL Y INJURY OR DAMAGES TO PROPERTY, ARISING OUT OF OR RELATED TO ANY CONDUCT (INCLUDING MISCONDUCT),...

  • Page 54: Claims And Dispute Resolution

    6 Claims and Dispute Resolution. THIE CLAUSE CONTAINED HEREIN ARE LEGALLY BINDING BETWEEN YOU AND NINEBOT, ITS AFFILIATES, THE PRODUCT’S MANUFACTURER, DISTRIBUTORS, SELLERS, AND DESIGNERS AND INCLUDING BUT NOT LIMITED TO EACH OF THOSE SPECIFICALLY NAMES AND NOT SPECIFICALLY NAMED ENTITIES’ PREDECESSOR COMPANIES, SUBSEQUENT COMPANIES, AFFILIATED COMPANIES, SUBSIDIARIES, PARENT COMPANIES, ADMINISTRATORS, SUCCESSORS, ASSIGNS, EMPLOYEES, AGENTS, ATTORNEYS, OFFICERS, DIRECTORS, MANAGERS, MEMBERS, AND REPRESENTATIVES, AND ANY INSURER OR REINSURER THEREOF (TOGETHER “NINEBOT PARTIES”).
  • Page 55 6.2 Opt-Out YOU MAY OPT OUT OF THIS DISPUTE RESOLUTION PROCEDURE BY PROVIDING NOTICE TO NINEBOT AND OTHER NINEBOT PARTIES NO LATER THAN THIRTY (30) CALENDAR DAYS AFTER THE DATE OF THE FIRST CONSUMER PURCHASER’S PURCHASE OF THE PRODUCT. TO OPT OUT YOU MUST SEND NOTICE BY E-MAIL TO NINEBOT AT SERVICE@NINEBOT.COM, WITH THE SUBJECT LINE: “ARBITRATION OPT OUT.”...
