  • Page 1 User Manual...
  • Page 2 Welcome Thanks for choosing the Segway eKickScooter Ninebot MAX G3 series product! Installation Video — 16—55 years 160 cm+ — (5.25 ft+) — Segway Mobility Always wear a helmet, elbow pads and knee pads when riding. WARNING: The Segway Mobility App...
  • Page 3 — — —...
  • Page 4 Packing List Note: Please keep the orginal packaging for at least 15 days! ● Max G3 ● Product Instructions ● Accessories ① Information Card × 1 ① AC Cable × 1 ② M6 Screw × 5 ③ M4 Screw × 2 ④...
  • Page 5 Diagram ⃝ Right Direction Indicator ⃝ Dashboard ⃝ Brake Lever ⃝ Throttle ⃝ Front Position Lamp ⃝ Snap Hook ⃝ Headlight ⃝ Bell ⃝ Stem ⃝ Footboard ⃝ Charging Port ⃝ Buckle ⃝ Quick-release Lever ⃝ Rear Mudguard ⃝ Folding Latch ⃝...
  • Page 6 — use the throttle or squeeze the brake lever to disable it. — Default Electronic Horn. Customize Quick Features through the Segway Mobility App. After Custom Button setting, you can press the custom button to use it. Press the button to light up left/right signal, then the signal flashes, and press the button again Direction Indicator to turn it off.
  • Page 7 ● Dashboard ● Speed Modes Speed Limit Mode 051601A （ECO Mode） 12 km/h (7.5 mph) （Drive Mode） 20 km/h (12.4 mph) （Sport Mode） 25 km/h (15.5 mph) （Walk Mode） 5 km/h (3 mph) Icon Name Description Time It displays local time. —...
  • Page 8 Icon Name Description Trip It displays the riding distance of this riding. When the icon lights up, it indicates that the scooter has detected errors. The Warning number refers to the qty of errors. Remaining Mileage It displays the remaining range of the scooter. Traction Control When the icon lights up, it indicates that the Traction Control System (TCS) is System (TCS)
  • Page 9 Assembly Open Close Step 1 Unfold the stem and close the quick-release lever until the folding latch reaches the bottom. Make sure the quick release lever is locked firmly when you push the quick release lever down without lifting folding latch. —...
  • Page 10 Step 3 Get a friend to help you lift the scooter out of the box, place it on the ground, and unfold the kickstand. — — Step 4 — As shown in the picture, install License Plate Holder with 3 mm (7/64'') Allen Wrench.
  • Page 11 Step 1 Step 2 Charge the eKickScooter for three seconds to activate the Scan the QR Code displayed on the dashboard via Segway battery. Power on the eKickScooter. Mobility App or tap "Search vehicle" in App and pair with your eKickScooter. Follow the instructions and watch the Riding Safety video.
  • Page 12 *Notes on Energy Recovery Function: — Function Introduction: Set the “Energy Recovery” level in the “Segway Mobility” App: Off/Strong/Weak — ○ By default, the vehicle’s Energy Recovery feature is set to “off.” Users can enable or disable the Energy Recovery function in the “Segway Mobility”...
  • Page 13 ○ Once the Energy Recovery is enabled, it will remain on until the function is manually turned off via the “Segway Mobility” App. The feature is not automatically disabled in the event of the vehicle shutting down or running out of battery. The vehicle’s dashboard does not display Energy Recovery status, which can only be verified and adjusted (Off/Strong/Weak) in...
  • Page 14 ● CodeLock Enable / Disable CodeLock via Segway Mobility App, at homepage >> More Functions >> Locking Function, and choose DigitalCodeLock or Pattern CodeLock. ○ Pattern CodeLock ○ DIgital CodeLock Step 1 Step 1 Enable Digital CodeLock via the App. Set a four-digit password (e.g.
  • Page 15 ● Segway AirLock ● Abnormal Movement Alert Enable/Disable AirLock via Segway Mobility App, at Abnormal Movement Alert can be turned on / off via homepage >> More Functions >> Locking Function. Segway Mobility App. After setting, if the vehicle detects abnormal movement in...
  • Page 16 ● Scheduled Charging 定时充电 Enable Scheduled Charging via Segway Mobility App and set the charging schedule. Scheduled Charging (Enable before Each Charging) Scheduled Charging (Enable before Each Charging) Enable Scheduled Charging (only effective during this charging), and this function will be disabled utomatically after being fully charged or unplugging the charger.
  • Page 17 Method A Method A Connect vehicle with Segway Mobility app, and Connect vehicle with Segway Mobility app, and disable enable Find My at homepage >> More Functions >> Find My at homepage >> More Functions >> Locating Locating vehicle >> Enable, then it wil automatically switch vehicle >>...
  • Page 18 Owner can update the firmware after connecting the Owner can enable & disable Find My Beacon by squeezing brake lever by 9 times and pressing power button once in eKickScooter to Segway Mobility App. Non-owner is unlocked status (position information). not allowed to update the firmware.
  • Page 19 * Nearby Status and Separated Status If the vehicle has been paired with Find My, when the Only users of Apple devices need to read this Apple Find owner leaves away from the vehicle or turns off the My app instruction. Bluetooth of his or her mobile device after a riding, the vehicle will automatically enter Nearby status after a short * Use of the Works with Apple badge means that a...
  • Page 20 Charging ① Open the charging port rubber. ② Insert charger. ③ Close charging port when finished. — — — When charging with Ninebot eKickScooter Adaptor When the battery power is under 30% and the scooter is not (sold separately), please open the charging port powered on for about 7 consecutive days, the battery will enter cover on the lower end of stem and plug in the into sleep mode.
  • Page 21 Note: For your safety, the motor will not engage until the eKickScooter reaches 3 km/h (1.9 mph). The Start Speed can be adjusted via Segway Mobility App. *Braking distance may vary significantly depending on the rider's weight and other conditions. Heavier riders may experience longer brake distances.
  • Page 22 ● Steering ● Park Vehicle When turning left or right, press the “←” (left) or “→” (right) Put down the kickstand when you are getting off the button. Then the direction indicator will flash regularly eKickScooter. which can be turned off by pressing the corresponding button again.
  • Page 23 ● Auto Headlight When eKickScooter is powered on, press power button to switch to Auto Headlight mode, then the headlight will turn on/off in accordance with the ambient brightness. *Auto Headlight can be disabled via Segway Mobility App. — — —...
  • Page 24 ● Cruise Control When the speed > 3.1 mph (5 km/h), press and hold the Cruise Control Button for two seconds to enable Cruise Control. Two beeps will be sounded and the cruise control icon will remain on when the vehicle enters cruise control. —...
  • Page 25 Warnings Always wear a helmet, elbow DO NOT wear high heels when DO NOT use a mobile phone pads and knee pads when riding. riding. or wear earphones when riding the eKickScooter. DO NOT ride the scooter in the DO NOT ride the scooter with DO NOT ride on public roads, rain.
  • Page 26 DO NOT twist / press the throttle DO NOT carry heavy objects on Attention! Reduce the speed while pushing vehicle. the handlebar. while going downhill. DO NOT rotate the handle Do not keep your feet on the rear DO NOT attempt to overtake cars. violently while driving at high speed.
  • Page 27 DO NOT touch the brake after DO NOT touch the hub motor Avoid potholes. riding. after riding because it can get hot. SECURE your scooter properly during transportation to avoid battery damage from collision. — — —...
  • Page 28 Folding, Carrying and Unfolding Note: Operate after powering off. Warning: If the locking device becomes loose or cannot be locked properly, stop using the scooter immediately and contact customer service for assistance. Do not continue riding until the issue is resolved to ensure your safety. ●...
  • Page 29 ● Carrying Lift by the stem to carry. ● Unfolding — Disengage the snap hook from the buckle. Unfold the stem — and close the quick-release lever. Make sure the folding — latch reaches the bottom.
  • Page 30 × √ Press the quick release lever firmly to make sure the folding mechanism is tightened. * The scooter will make a "click" sound when the folding mechanism is tightened. — — Make sure the folding latch is in the locked position before ×...
  • Page 31 Inflate the Tires ① Unscrew the valve cap. — — ② Connect the valve stem extension to the tire valve stem. — Caution: Ensure tires are properly inflated before riding. Operating the scooter with underinflated tires can cause permanent damage to the tires, affect riding safety, and may lead to the motor overworking and overheating (which could cause the motor to shut off unexpectedly).
  • Page 32 Specifications Item Parameter Name Segway eKickScooter Ninebot MAX G3 Model 051601A Product Info L × W × H Approx. 1218 × 590 × 1299 mm (48 × 23.2 × 51.1 in) L × W × H (folded) Approx. 1218 × 590 × 592 mm (48 × 23.2 × 23.3 in) Net Weight Approx.
  • Page 33 Item Parameter Charge Time Tracking, Smart Charge Scheduling, Battery Health Monitoring, Short Circuit Protection, Overcurrent Protection, Battery Management Battery Pack Temperature Protection, Overcharging Protection, Under Voltage System Protection, Over-discharging Protection, Customizable Charging Limit, IPX7 Water-resistant Battery Pack Nominal Power 0.85 kW, 850 W Motor Max.
  • Page 34 Appendix: Phone Holder Installation As shown in the picture, use appropriate tool to dismantle Install the phone holder in the place of the original the removable part. Removable Part. (For specific installation steps, please refer to the phone holder manual). —...
