Chapter 2: Installation, Wiring and Specifications

Environmental Specifications

1
The following table lists the environmental specifications that generally apply to the DL205
system (CPU, Bases, I/O Modules). The ranges that vary for the Handheld Programmer are
noted at the bottom of this chart. I/O module operation may fluctuate depending on the
2
ambient temperature and your application. Please refer to the appropriate I/O module
specifications for the temperature derating curves applying to specific modules.
3
Specification
Storage temperature
4
Ambient operating temperature*
Ambient humidity**
5
Vibration resistance
Shock resistance
6
Noise immunity
Atmosphere
7
* Operating temperature for the Handheld Programmer and the DV-1000 is 32° to 122° F (0° to 50° C) Storage temperature
for the Handheld Programmer and the DV-1000 is - 4° to 158° F (- 20° to 70° C).
** Equipment will operate below 30% humidity. However, static electricity problems occur much more frequently at lower
8
humidity levels. Make sure you take adequate precautions when you touch the equipment. Consider using ground
straps, anti-static floor coverings, etc., if you use the equipment in low humidity environments.
9

Power

The power source must be capable of supplying voltage and current complying with the base
power supply specifications.
10
Specification
11
Part Numbers
12
Input Voltage Range
13
Maximum Inrush Current
Maximum Power
Voltage Withstand (dielectric)
14
Insulation Resistance
Auxiliary 24 VDC Output
A
Fusing (internal to base power
supply)
B
C
D
2–8
DL205 User Manual, 4th Edition, Rev. B
–4° F to 158° F (–20° C to 70° C)
32° F to 131° F (0° C to 55° C)
30% – 95% relative humidity (non–condensing)
MIL STD 810C, Method 514.2
MIL STD 810C, Method 516.2
NEMA (ICS3–304)
No corrosive gases
AC Powered Bases
D2–03B–1, D2–03BDC1–1,
D2–04B–1, D2–04BDC1–1,
D2–06B–1 D2–06BDC1–1,
D2–09B–1 D2–09BDC1–1
100–240 VAC (+10%/ –15%) 10.2 – 28.8VDC (24VDC) with
50/60 Hz less than 10% ripple
30A 10A
80VA 25W
1 minute @ 1500 VAC between primary, secondary, and field ground
> 10 MΩ at 500 VDC
20–28 VDC, less than 1V p-p
None
300mA max.
Non–replaceable 2A @ 250V Non–replaceable 3.15A @
slow blow fuse 250V slow blow fuse
Rating
24 VDC Powered Bases 125 VDC Powered Bases
D2–06BDC2–1,
D2–09BDC2–1
104–240 VDC
+10% –15%
20A
30W
20–28 VDC, less than 1V p-p
300mA max.
Non–replaceable 2A @ 250V
slow blow fuse
