  • Page 1 ™ SR44 S TELLAR TARTER ANUAL SR44-M-WO 1st Edition, Revision B...
  • Page 2 BL NK P GE SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 3 ~ WARNING ~ Thank you for purchasing automation equipment from Automationdirect.com®, doing business as AutomationDirect. We want your new automation equipment to operate safely. Anyone who installs or uses this equipment should read this publication (and any other relevant publications) before installing or operating the equipment.
  • Page 4 ~ AVERTISSEMENT ~ Nous vous remercions d'avoir acheté l'équipement d'automatisation de Automationdirect.com®, en faisant des affaires comme AutomationDirect. Nous tenons à ce que votre nouvel équipement d'automatisation fonctionne en toute sécurité. Toute personne qui installe ou utilise cet équipement doit lire la présente publication (et toutes les autres publications pertinentes) avant de l'installer ou de l'utiliser.
  • Page 5 ~ WARNING ~ The owner, installer, and user are responsible for the correct installation and use of the Stellar™ SR44, for ensuring that only qualified personnel install the SR44, and for ensuring that the operation and maintenance of the unit complies with the relevant Codes of Practice, Regulations, and Statutory Requirements.
  • Page 6 BL NK P GE w–4 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 7 ™ TELLAR SR44 S TARTER ANUAL Please include the Manual Number and the Manual Issue, both shown below, when communicating with Technical Support regarding this publication. Manual Number: SR44-M-WO Issue: First Edition, Revision B Issue Date: 07/31/2019 Publication History Issue Date Description of Changes First Edition...
  • Page 8 BL NK P GE SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...

  • Page 9: Table Of Contents

    ™ SR44 S TELLAR TARTER ANUAL ABLE OF ONTENTS Chapter 1: Mechanical Installation ..... 1–1 Manual Overview ......... . 1–2 1 –...
  • Page 10 Table of Contents Chapter 4: Electromagnetic Compatibility ....4–1 4.0 – Electromagnetic Compatibility (EMC) ..... . 4–2 4.1 –...
  • Page 11 Table of Contents Appendix C: Technical Hints ......C–1 Technical Hints ..........C–2 Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters .
  • Page 12 Table of Contents BL NK P GE t–4 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 13 HAPTER HAPTER HAPTER ECHANICAL NSTALLATION NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... Manual Overview ....... . 1–2 Overview of this Publication .

  • Page 14: Manual Overview

    6:00 p.m. Eastern Time. We also encourage you to visit our web site where you can find technical and non-technical information about our products and our company. Visit us at www.automationdirect.com. Special Symbols When you see the “notepad” icon in the left-hand margin, the paragraph to its immediate right will be a special note.

  • Page 15: Chapter 1: Mechanical Installation

    Chapter 1: Mechanical Installation 1 – Mechanical Installation 1.1 – Mounting Mount the unit to a flat, vertical surface using the mounting holes (or slots) on its base-plate. The mechanical outline diagrams, shown in the “Mechanical Outline” section (1.9), give the dimensions and mounting hole positions for each model.

  • Page 16: Mechanical Installation

    Chapter 1: Mechanical Installation 1.6 – Assisted Flow An enclosure may need additional fans to maintain the required air temperature immediately surrounding the unit. This temperature is referred to as the Ambient Temperature. Use the following formula to determine whether or not fan(s) are required. An allowance has been incorporated into the formula so that the figure for “Q”...

  • Page 17: Clearance

    Chapter 1: Mechanical Installation 1.8 – Clearance To maintain adequate ventilation, each model of SR44 Soft Starter requires a minimum clearance to adjacent equipment and partitions. These clearances are specified in the following diagram and table. Soft Soft Starter Starter Outline of Unit Air Mounting...
  • Page 18 Chapter 1: Mechanical Installation 1.9 – Mechanical Outline – Chassis Size 1 SR44-9 to SR44-146 195.0 [7.68] 125.0 [4.92] 150.0 [5.91] 222.0 [8.74] SR44 size 1: SR44-9 to SR44-146 dimensions: mm [in] SR44 Chassis Size 1 Mounting Specifications Unit Mounting Holes Mass/Weight Model Number (kg [lb])
  • Page 19 Chapter 1: Mechanical Installation 1.10 – Mechanical Outline – Chassis Size 2 SR44-174 to SR44-370 250.0 [9.84] 340.0 Mounting Holes/Slots [13.39] SR44 size 2: SR44-174 to SR44-370 dimensions: mm [in] SR44 Chassis Size 2 Mounting Specifications Unit Mounting Holes Mass/Weight Model Number (kg [lb]) Bottom...
  • Page 20 Chapter 1: Mechanical Installation BL NK P GE 1–8 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 21 HAPTER HAPTER HAPTER LECTRICAL NSTALLATION NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 2.1 – Warnings & Agency Approvals ....2–2 2.1.1 –...
  • Page 22 HAPTER HAPTER HAPTER LECTRICAL NSTALLATION (Table of Contents continued from previous page) 2.6 – Power Supply Connections ....2–12 2.6.1 – Power Circuit Electrical Supply ......2–12 2.6.2 –...
  • Page 23 HAPTER HAPTER HAPTER LECTRICAL NSTALLATION BL NK P GE 2–1c...

  • Page 24: Chapter 2: Electrical Installation

    Chapter 2: Electrical Installation NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. 2.1 – Warnings & Agency Approvals 2.1.1 – Isolation Caution: The SR44 uses semiconductor devices in the main circuit, and is not designed to provide isolation.

  • Page 25: Electrical Connections - Specifications

    Chapter 2: Electrical Installation 2.2 – Electrical Connections – Specifications 2.2.1 – Electrical Supplies The SR44 requires two AC electrical power sources: 1) A balanced 3-phase main source to provide the power for the controlled motor. 2) A single-phase supply: 115V or 230V, 50Hz/60Hz, for the internal control circuitry. The soft starter must be connected to a 3-phase power supply and a 3-phase load for proper operation.

  • Page 26: Standard Wiring Configurations

    Chapter 2: Electrical Installation 2.3 – Standard Wiring Configurations The soft starter must be connected to a 3-phase power supply and a 3-phase load for proper operation. Attempted starts will result in a starter fault if either the 3-phase power or the 3-phase load is not connected.

  • Page 27: Wiring Diagram For In-Delta Connection Of Motors

    Chapter 2: Electrical Installation 2.3.2 – Wiring Diagram for In-Delta Connection of Motors For “In-Delta” connections, set the SR44 Parameter #6 (“Firing Mode”) to “1” (“Delta”). Figure 2.3.2: Wiring Diagram for In-Delta Connection of 6-Lead Motors Mains Supply (V Feeder cables Isolation and Protection forward Switch-gear...

  • Page 28: Motor Control Circuits

    Chapter 2: Electrical Installation 2.4 – Motor Control Circuits 2.4.1 – Bypass Control A separate bypass contactor may be connected in parallel with an SR44 Soft Starter. The bypass contactor allows a solid connection of the motor to the Main Supply, which will eliminate the heating effect associated with Soft Starter thyristor losses.

  • Page 29: Multiple Motor Starting & Stopping

    Chapter 2: Electrical Installation 2.4.2 – Multiple Motor Starting & Stopping The SR44 is capable of starting parallel-connected motors simultaneously, provided each motor has similar characteristics and load. For such configurations the unit rating should be at least the sum of the current ratings of all the motors. Alternatively, the SR44 can start and stop motors sequentially using bypass contactors under the control of the programmable relay set as a ’Top of Ramp’...

  • Page 30: Wiring Diagram For Motor Reversing

    Chapter 2: Electrical Installation 2.4.6 – Wiring Diagram for Motor Reversing Figure 2.4.6: Typical Power and Contactor Control Circuits for Motor Reversing Control Supply Mains 115VAC or 230VAC – set voltage switch acordingly Supply OFF - ENABLE FORWARD Feeder cables E-STOP STOP Isolation and Protection...

  • Page 31: Electrical Connections - Terminal Locations

    Chapter 2: Electrical Installation 2.5 – Electrical Connections – Terminal Locations 2.5.1 – General Electrical Connections Figure 2.5.1a: SR44 Chassis Size 1 Electrical Connections CONTROL VOLTAGE TERMINALS X1, X2 (Input) CONTROL VOLTAGE SELECTOR SWITCH Ensure that the selector switch position corresponds to the control supply used (either 115V or 230V) before you apply the control supply.
  • Page 32 Chapter 2: Electrical Installation 2.5.1 – General Electrical Connections (continued) Figure 2.5.1b: SR44 Chassis Size 2 Electrical Connections CONTROL VOLTAGE TERMINALS X1, X2 (Input) CONTROL VOLTAGE SELECTOR SWITCH Ensure that the selector switch position corresponds to the control supply used (either 115V or 230V) before you apply the control supply.
  • Page 33 Chapter 2: Electrical Installation 2.5.2 – Electronic Control Card Figure 2.5.2: Electronic Control Card Electrical Connections Keypad connection header. D5 (Green LED) Indicates the presence of the control supply. SR44 Electronic Control Card Output Output Relay Relay J7 Ribbon cable connector (output) (output)

  • Page 34: Power Supply Connections

    Chapter 2: Electrical Installation 2.6 – Power Supply Connections The soft starter must be connected to a 3-phase power supply and a 3-phase load for proper operation. Attempted starts will result in a starter fault if either the 3-phase power or the 3-phase load is not connected.

  • Page 35: Control Card Connections

    Chapter 2: Electrical Installation 2.7 – Control Card Connections All the control inputs and outputs are on the Electronic Control Card (ELC), which is mounted within the unit. Diagrams in section 2.5 show the location of the electronic control card. 2.7.1 –...

  • Page 36: Typical Motor Power At Rated Voltage

    Chapter 2: Electrical Installation NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. 2.9 – Typical Motor Power at Rated Voltage The amperage values for the Soft Starter are the maximum continuous current for the model. The motor ratings are the nearest values for the output powers of standard squirrel-cage motors below the unit current rating of the SR44.

  • Page 37: Fuse And Current Ratings

    Chapter 2: Electrical Installation 2.10 – Fuse and Current Ratings 2.10.1 – Full-Load Current Limit and Short-Circuit Protection SR44 Fuse and Current Ratings for UL Applications (Table 2.10.1) UL Recognized JFHR2 Fuse Short Circuit Mersen Model Current Bussman (formerly Ferraz) Amps (RMS) Model #...

  • Page 38: External Fuse Requirements

    Chapter 2: Electrical Installation 2.10.1 – Full-Load Current Limit and Short-Circuit Protection (continued) SR44 Fuse and Current Ratings for Non-UL Applications* Fuse Short Circuit Bussman Edison Model Current FWP 700V E70S Amps (RMS) Model # Model # SR44-9 FWP-50B E70S50 SR44-16 SR44-23 FWP-80B...

  • Page 39: Overload Current Profile And Duty Cycle Ac-53A

    Chapter 2: Electrical Installation 2.10.3 – Overload Current Profile and Duty Cycle AC-53a IEC 60947-4-2 Motor Utilization Category: AC-53a (not operating in bypass mode) SR44 Index Ratings (for AC-53a) * Standard Operation Soft Starter Model Number AC-53a 99-10 9 to 105 SR44-9 to SR44-105 AC-53a 3-35...

  • Page 40: Overload Current Profile Ac-53B

    Chapter 2: Electrical Installation 2.10.4 – Overload Current Profile AC-53b IEC 60947-4-2 Motor Utilization Category: AC-53b (operating in bypass mode) SR44 Index Ratings (for AC-53b) * Bypassed Operation Soft Starter Model Number OFF-time AC-53b 9 to 105 SR44-9 to SR44-105 AC-53b 3-35 AC-53b...

  • Page 41: Overcurrent Trip Graph

    Chapter 2: Electrical Installation 2.10.5 – Overcurrent Trip Graph Overload start point ‡ (adjustable by P34 (or P93) ; default setting: 110%) 1000 Seconds to trip ‡ P35 (or P94) Default Delay = 140 Delay = 80 Delay = 30 Delay = 10 0.01 8 9 10...
  • Page 42 Chapter 2: Electrical Installation BL NK P GE 2–20 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 43 HAPTER HAPTER HAPTER PPLICATIONS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 3.1 – Motor Suitability and Associated Considerations ..3–2 3.1.1 – Suitability ..........3–2 3.1.2 –...
  • Page 44 HAPTER HAPTER HAPTER PPLICATIONS (Table of Contents continued from previous page) 3.2 – Rules for Specific Applications ....3–5 3.2.1 – In-Delta Operation ........3–5 3.2.2 –...
  • Page 45 HAPTER HAPTER HAPTER PPLICATIONS (Table of Contents continued from previous page) 3.4 – Principles of the Optimizing Mode ....3–15 3.4.1 – Principles ..........3–15 3.4.2 –...

  • Page 46: Chapter 3: Applications

    Chapter 3: Applications 3.1 – Motor Suitability and Associated Considerations The SR44 Soft Starter is based on a series of microprocessor-based optimizing soft starters which have been used world-wide in more than 100,000 critical and non-critical systems. Since 1983, these soft starters have successfully operated with almost every type of load and environment from the Antarctic to the Jungle.

  • Page 47: Maximum Motor Cable Length

    Chapter 3: Applications 3.1.4 – Maximum Motor Cable Length The length of the cable between the output terminals of the starter and the motor should not normally be greater than 100 meters [328 ft]. 3.1.5 – Power Factor Correction Capacitors Power factor correction capacitors applied to a single motor must ALWAYS be connected by a separate contactor placed on the SUPPLY side of the SR44 Soft Starter.

  • Page 48: Efficiency

    Chapter 3: Applications 3.1.11 – Efficiency Although the use of the soft starter introduces a power loss, the system still retains an overall efficiency of approximately 99.5%. If the optimizing function is selected, then the gain in motor efficiency at partial loads is far greater than the loss of efficiency arising from thyristor heat losses. If prolonged operation at full load is expected, the thyristor loss can be eliminated (as in some matched motor/pump drives) by closing a bypass contactor around the soft starter.

  • Page 49: Rules For Specific Applications

    Chapter 3: Applications 3.2 – Rules for Specific Applications 3.2.1 – In-Delta Operation The SR44 control system allows the soft starter to be installed “in the delta” connections of the motor, which can permit the use of a lower current rated unit. However, in this mode of operation it is important that the soft starter is connected in accordance with the relevant wiring diagram.

  • Page 50: Soft Stopping

    Chapter 3: Applications 3.2.7 – Soft Stopping Soft stopping can reduce positive surge pressures in pipelines on shutdown. It is necessary to make sure that the ramp-down time is long enough to remove the energy from the fluid before the firing of the thyristors is stopped.
  • Page 51 Chapter 3: Applications Table 3.2.13 – Applications Breakaway Application Remarks Torque (%FLT) Agitator Air compressor- rotary, unloaded start 25–35 Air compressor- reciprocating, unloaded start 50–100 Air compressor- screw type, unloaded start Usually two-pole motor Ball mill 30–50 Eccentric load, needs high starting torque motor Carding machine Often high inertia Centrifuge...

  • Page 52: Concepts And Principles Of Fixed-Speed Induction Motor Starting

    Chapter 3: Applications 3.3 – Concepts and Principles of Fixed-Speed Induction Motor Starting and Control Since its invention one hundred years ago, the standard three-phase induction motor has become one of the most familiar items of industrial equipment ever known. Due to its simplicity of construction, low cost, reliability, and relatively high efficiency, it is likely to remain the prime source of mechanical energy for the foreseeable future.
  • Page 53 Chapter 3: Applications Figure 3.3.2.1: Torque/Speed Curve – Induction Motor Pull Out Torque ( M TORQUE Locked Rotor Torque ( LRT, M Pull-up Torque Full Load Torque ( FLT, M Synchronous speed SPEED Figure 3.3.2.1 Torque/Speed Curve – Induction Motor Figure 3.3.2.2: Torque/Speed Curve –...

  • Page 54: Starting Induction Motors

    Chapter 3: Applications 3.3.2 – The Induction Motor (continued) Obviously, the larger the difference between the developed torque and the absorbed torque, the faster the acceleration and the quicker full speed is reached, and the greater the stresses experienced by the supply and drive systems during the acceleration process. An “ideal” start would accelerate the load with just sufficient force to reach full speed smoothly in a reasonable time, and with minimum stress to the supply and drive mechanisms.

  • Page 55: Electro-Mechanical Methods Of Starting

    Chapter 3: Applications 3.3.4 – Electro-Mechanical Methods Of Starting Method A: Direct-on-Line The most simple means of controlling energy flow to an induction motor is to interrupt the power supply by a single contactor. Very widely applied, the method is known variously as “direct-on- line”, “across-the-line”, “direct”, etc., and is the usual form of control where low cost is the first and most important consideration.

  • Page 56: The Semiconductor Motor Controller

    Chapter 3: Applications There are methods of control, for example, the Wauchope starter, which eliminate or reduce the reconnection transients. However, such starters are expensive and have reliability implications, and they are not widely applied for these reasons. The wye-delta starter also has disadvantages due to the restricted starting torque available (if you need 40% LRT to break-away, you can only increase the motor size, or revert to direct-on-line).

  • Page 57: Running Induction Motors

    Chapter 3: Applications 3.3.6 – Running Induction Motors Once a start has been completed, the motor operating efficiency becomes of interest. When working at or near full load, the typical three-phase induction motor is relatively efficient, and readily achieves efficiencies of 85% to 95%. However, as shown below, motor efficiency falls dramatically when the load falls to less than 50% of rated output.

  • Page 58: Reliability Considerations

    Chapter 3: Applications All SR44 Soft Starters are microprocessor controlled, and this gives them a number of advantages. Firstly, there are no adjustments to be made for the energy saving function; all calculations necessary to find the best degree of phase-back of the thyristors for any load condition is made by the microprocessor.

  • Page 59: Principles Of The Optimizing Mode

    Chapter 3: Applications 3.4 – Principles of the Optimizing Mode 3.4.1 – Principles Every wound-field electric motor must consume some minimum amount of energy to provide a magnetic field which enables it to work at all. With DC motors the field is under separate control, so that the amount of magnetizing energy can be adjusted to be sufficient to overcome losses and provide an armature reaction appropriate to the load.

  • Page 60: Advantages Of Energy Optimizing

    Chapter 3: Applications 3.4.2 – Advantages of Energy Optimizing A soft starter with an energy-optimizing feature alters the motor operation. The energy-optimizing function reduces the terminal voltage applied to the motor so that the energy needed to supply the field is more closely proportioned to the torque demand. The effect is shown in the Figure below. Figure 3.4.2.1: ‘Full Speed’...

  • Page 61: Optimizing With The Sr44 System

    Chapter 3: Applications 3.4.4 – Optimizing with the SR44 System NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. During start-up, the SR44 software uses a patented method to compute and store a reference value for the power factor.

  • Page 62: How Much Energy

    Chapter 3: Applications 3.4.5 – How Much Energy? The amount of energy used by a squirrel-cage induction motor operating with a soft starter in energy-optimizing mode is shown in the following figure (Figure 3.4.5.1), for the same duty cycle as Figure 3.4.1.2. By reducing the voltage when torque demand is below maximum, the magnetizing current is proportioned to the torque current.

  • Page 63: Estimating Energy Savings

    Chapter 3: Applications 3.4.6 – Estimating Energy Savings Basis for estimations: • 3-phase squirrel cage induction motor, standard type. • Supply: 380 to 440V, 50Hz. • Supply voltage > minimum working voltage on motor rating plate. • Operation 30% rated nameplate full load. Table 3.4.6.1: Estimations Energy Savings Estimations –...

  • Page 64: Chapter 3 Glossary Of Terms

    Chapter 3: Applications 3.5 – Chapter 3 Glossary of Terms Breakaway Torque The minimum torque required to achieve rotor movement for the motor with its load. Current Limit The current at which the ramp is held. For the SR44, current limit is only active during start-up where it contributes to the motor control function.

  • Page 65: Power Factor Conversion Chart

    Chapter 3: Applications 3.6 – Power Factor Conversion Chart Parameter 20 is the reference power factor that the SR44 computes during the start. Parameter 21 is the present power factor of the load. The keypad display shows each of these parameters in angular degrees.
  • Page 66 Chapter 3: Applications BL NK P GE 3–22 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 67 HAPTER HAPTER HAPTER LECTROMAGNETIC OMPATIBILITY NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 4.0 – Electromagnetic Compatibility (EMC) ... . 4–2 4.1 –...

  • Page 68: Chapter 4: Electromagnetic Compatibility

    Chapter 4: Electromagnetic Compatibility 4.0 – Electromagnetic Compatibility (EMC) As supplied, all SR44 Soft Starters meet the standards of emission and immunity levels defined in the IEC 60947-4-2 and EN 60947-4-2 product standards for AC Semiconductor Motor Controllers and Starters. However, the EMC performance of the controller can be significantly affected by the manner in which it is incorporated into the system in which it is intended to operate.

  • Page 69: Emc Basic Criteria

    Chapter 4: Electromagnetic Compatibility 4.5 – EMC Basic Criteria The electromagnetic compatibility of a product is defined by two criteria: 1) Immunity to electromagnetic disturbances generated externally to the product. 2) The type and amount of conducted and radiated electromagnetic emissions emanating from the product.

  • Page 70: Basic Emc Considerations

    Chapter 4: Electromagnetic Compatibility 4.7 – Basic EMC Considerations 4.7.1 – Immunity The product standard for immunity requirements is EN 60947-4-2:1996. All SR44 Soft Starter products meet, or exceed the industrial level immunity requirements laid down in this standard. 4.7.2 – Emissions Emissions are classified as low frequency (below 9kHz), known as harmonics, and high or radio frequency (above 9kHz).

  • Page 71: Emissions - Conducted

    Chapter 4: Electromagnetic Compatibility 4.7.5 – Emissions - Conducted Conducted emissions are able to travel great distances and may cause interference to any neighboring consumers connected to the common low-voltage supply network. Allowable levels for conducted emissions generated by semiconductor motor controllers and starters are influenced by the nature of the low-voltage power distribution network.

  • Page 72: Strategies For Attaining And Maintaining Emc Compliance

    Chapter 4: Electromagnetic Compatibility 4.7.7 – Strategies for Attaining and Maintaining EMC Compliance Where possible, minimize the effect of electrical interference by using the strategies listed below. • Locate the SR44 Soft Starter unit as close as reasonably possible to the motor terminal box in order to minimize cable length.
  • Page 73 HAPTER HAPTER HAPTER EYPAD TEMS ARAMETERS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 5.0 – How to Use This Chapter ..... . 5–2 5.0.1 –...
  • Page 74 HAPTER HAPTER HAPTER EYPAD TEMS ARAMETERS (Table of Contents continued from previous page) 5.4 – Menu Settings and Parameter Descriptions ..5–23 5.4.0 – Restoring Defaults ........5–23 5.4.1 –...
  • Page 75 HAPTER HAPTER HAPTER EYPAD TEMS ARAMETERS BL NK P GE 5–1c...

  • Page 76: Chapter 5: Keypad Menu Items And Parameters

    Chapter 5: Keypad Menu Items and Parameters NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. 5.0 – How to Use This Chapter SR44 Soft Starters have two basic types of settings that can be changed and/or viewed by users. •...

  • Page 77: Configuring The Sr44 Soft Starter

    Quick Start Once the unit is mounted and wired per the instructions in the “Stellar SR44 Soft Starter Basic Quick-start Guide”, or in the “Mechanical Installation” and “Electrical Installation” chapters of this User Manual, then select a suitable application from the “Applications Menu” described later in this chapter (5.2.2 &...

  • Page 78: User Interface

    Chapter 5: Keypad Menu Items and Parameters 5.1.2 – User Interface The Keypads There are three types of user interface for use with the SR44 (Only one interface may be used at any one time.): • The unit’s built-in keypad (Figure 5.1.2a), •...

  • Page 79: System Status Mode

    Chapter 5: Keypad Menu Items and Parameters 5.1.3 – System Status Mode Following the initial boot-up report (see section 5.1.9), the unit enters the Status Mode. In this mode the operating status of the unit is constantly displayed, resulting in a number of status messages: Non-Running Status Two messages indicate that the unit is not running the load at present.

  • Page 80: Data Entry Mode

    Chapter 5: Keypad Menu Items and Parameters 5.1.5 – Data Entry Mode The Data Entry Mode is entered as soon as the bottom level of the menu structure for that particular menu branch is reached, i.e., a menu item or parameter name is displayed in the top line of the keypad display, and the associated value is displayed in the bottom line of the display.

  • Page 81: Bit Masks

    Chapter 5: Keypad Menu Items and Parameters 5.1.8 – Bit Masks Some parameters can also be addressed via the appropriate Bit Parameter, instead of or as well as being accessed via the more commonly used menus. These Bit Parameters can only be accessed by the ‘Parameters’...

  • Page 82: Keypad Menu Structure

    Chapter 5: Keypad Menu Items and Parameters 5.2 – Keypad Menu Structure 5.2.1 – Abbreviated Map of Keypad Structure Level 0 Level 1 Level 2 Level 3 Stopped and ready Applications Settings Default (Keypad) Default Auto (etc.) Starter Disabled to Enable Auto Features Settings Auto Jog...

  • Page 83: Complete Keypad Menu Structure

    Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure We highly recommend that you configure the SR44 by first selecting and setting an application from the “Applications” menu that is similar to your application. If necessary, you can then ‘fine-tune’ your configuration by changing the settings of other parameters and menu items.
  • Page 84 Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure (continued) Keypad Menu Structure (continued) Horizontal Keypad Scrolling: Enter key = right (forward); # key = left (back) Level Level Parameter Parameter Level 2 Level 3 / Bit # / Bit # Disable Starter? P52 / B1&B2...
  • Page 85 Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure (continued) Keypad Menu Structure (continued) Horizontal Keypad Scrolling: Enter key = right (forward); # key = left (back) Level Level Parameter Parameter Level 2 Level 3 / Bit # / Bit # Rated Current (I P24 &...
  • Page 86 Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure (continued) Keypad Menu Structure (continued) Horizontal Keypad Scrolling: Enter key = right (forward); # key = left (back) Level Level Parameter Parameter Level 2 Level 3 / Bit # / Bit # Power Protection (full + optimise)
  • Page 87 Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure (continued) Keypad Menu Structure (continued) Horizontal Keypad Scrolling: Enter key = right (forward); # key = left (back) Level Level Parameter Parameter Level 2 Level 3 / Bit # / Bit # Map From 52 Parameter...
  • Page 88 Chapter 5: Keypad Menu Items and Parameters 5.2.2 – Complete Keypad Menu Structure (continued) Keypad Menu Structure (continued) Horizontal Keypad Scrolling: Enter key = right (forward); # key = left (back) Level Level Parameter Parameter Level 2 Level 3 / Bit # / Bit # P1 to P21 P22 to P40...

  • Page 89: Parameter Basic Information

    Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information • The parameters are accessed through the “Parameters” menu in Level 1 of the Keypad Menu Structure. • For SR44s with optional communcations accessories, the parameters can also be accessed through Modbus addressing, as described in the “Serial Communications”...
  • Page 90 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – flags Status 3 0 (1) Relay K1 Status 1 (2) Relay K2 Status 2 (4) (unused) 3 (8) (unused) –...
  • Page 91 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – 3000 amps Reserved – Rated Amps (100s) – amps Reserved – Rated Amps – 7.9688 amps 0.03125 Current – amps Peak Start I –...
  • Page 92 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – flags User Flags 1 0 (1) Kickstart 1 (2) Current Limit Timeout Sel'd 2 (4) Overload Selected 3 (8) Shearpin Selected –...
  • Page 93 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – flags I/O Polarity 0 (1) K1 Polarity 1 (2) K2 Polarity 2 (4) (Unused) 3 (8) (Unused) – 4 (16) I/p 1 Polarity 5 (32) (Unused)
  • Page 94 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – none Protection 2 – Start Ped 2 – seconds Start Time 2 – Kick Ped 2 – cycles Kick Time 2 –...
  • Page 95 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – flags User Flags22 0 (1) Low Voltage Soft-Stop (2) 1 (2) Not Global Enable 1 (2) 2 (4) Not Global Enable 2 (2) 3 (8) Pod Start/Stop (2) –...
  • Page 96 Chapter 5: Keypad Menu Items and Parameters 5.3 – Parameter Basic Information (continued) Parameter Basic Information (continued) Name / Function – none StopProfile – none Last App – 0*** 63.75 minutes 0.25 CoolingTime – – – – – – – Reserved –...

  • Page 97: Menu Settings And Parameter Descriptions

    Chapter 5: Keypad Menu Items and Parameters 5.4 – Menu Settings and Parameter Descriptions This section gives a description of the individual menus and the functions that their parameters perform. • Menu Settings and Parameters are presented in the same groups and sequence as they appear in the Keypad Menu Structure.

  • Page 98: Applications' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.2 – ‘Applications’ Menu This menu contains a list of typical applications for which a set of parameters have been predefined by the manufacturer. This feature provides a quick and easy way of setting up the unit. There are three exceptions to this list: 1) The first menu item, ‘Settings’, provides a brief report on the basic settings of the unit (see below and Appendix A.1.6).
  • Page 99 Chapter 5: Keypad Menu Items and Parameters 5.4.2 – ‘Applications’ Menu (continued) ‘Applications’ Menu User configurable settings: (These ‘Applications’ auto-features preset the SR44 for the selected application.) Default (keypad) * * * Range: n/a Default: n/a The ‘Default (keypad)’ setting provides a way to RESTORE all DEFAULT VALUES to the starter. It also sets the starter for starting and stopping from the local or remote KEYPAD.
  • Page 100 Chapter 5: Keypad Menu Items and Parameters 5.4.2 – ‘Applications’ Menu (continued) Crusher – Setting for Crusher application. (See “Appendix B: Applications Data” for details.) Grinder – Setting for Grinder application. (See “Appendix B: Applications Data” for details.) Hi Start Torque –...

  • Page 101: Auto Features' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.3 – ‘Auto Features’ Menu The Auto Features Menu contains commonly used parameters that may be automatically adjusted by the unit. ‘Auto Features’ Menu Explanation Diagram Auto EndStart LOAD Auto Stop Auto Auto Auto Pedestal Ramp...
  • Page 102 Chapter 5: Keypad Menu Items and Parameters 5.4.3 – ‘Auto Features’ Menu (continued) Auto Jog (P18.B3) Range: P18 / B3 Default: Off Scaling: n/a Type: R/W ‘Auto Jog’ turns ‘On’ and ‘Off’ automatic Jog detection. When ‘Auto Jog’ is ‘On’ and the soft-stop time is set greater than zero (0), the stop varies based upon the length of time the start signal is applied.
  • Page 103 Chapter 5: Keypad Menu Items and Parameters 5.4.3 – ‘Auto Features’ Menu (continued) Auto Bypass (P18.B2) Range: P18 / B2 Default: On Scaling: n/a Type: R/W ‘Auto Bypass’ turns ‘On’ and ‘Off’ the automatic detection of a bypass contactor. When ‘On’, a bypass contactor will be automatically detected.

  • Page 104: Basic' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.4 – ‘Basic’ Menu The Basic menu holds the parameters which control the primary functions of the unit. Changing the values of these parameters will vary the starting and stopping duties, the trip protection set for the unit, and the source of the start signal (Keypad or Remote).
  • Page 105 Chapter 5: Keypad Menu Items and Parameters 5.4.4 – ‘Basic’ Menu (continued) Starting (P51.B7) Range: P51 / B7 Default: On Scaling: n/a Type: R/W The ‘Starting’ setting sets the source for the start signal. If set to OFF (Keypad), the unit will Start/Stop when the Start/Stop button on the user interface is pressed.
  • Page 106 Chapter 5: Keypad Menu Items and Parameters 5.4.4 – ‘Basic’ Menu (continued) Protection (P-7) Range: 0 to 192 Default: 192 Scaling: n/a Type: R/W ‘Protection Mode’ controls which trips are available: • 64 = FULL = full protection with full volts after top of ramp; optimizing function turned off •...

  • Page 107: Advanced' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.5 – ‘Advanced’ Menu The Advanced Menu holds parameters that need to be changed only to solve specific sets of circumstances. ‘Advanced’ Menu Explanation Diagram LOAD KICK (P13) START Time STOP Dwell Kick Stop Time (P17) Time Time...
  • Page 108 Chapter 5: Keypad Menu Items and Parameters ‘Current’ Sub-menu of ‘Advanced’ Menu (continued) Low Current (‘Current’ sub-menu of ‘Advanced’ menu) (P51.B4) Range: P51/B4 Default: Off Scaling: n/a Type: R/W The ‘Low Current’ menu item turns ‘On’ and ‘Off’ the ‘Low Current’ trip. A ‘Low Current’ trip occurs when the current output measured by the unit falls below the level specified by the ‘Low Amps Level’...
  • Page 109 Chapter 5: Keypad Menu Items and Parameters ‘Current’ Sub-menu of ‘Advanced’ Menu (continued) C/L Time Out (‘Current’ sub-menu of ‘Advanced’ menu) (P51.B1) Range: P51/B1 Default: Off Scaling: n/a Type: R/W The ‘C/L Time Out’ menu item turns ‘On’ and ‘Off’ the ‘Current Limit Time Out’ trip. A ‘Current Limit Time Out’...
  • Page 110 Chapter 5: Keypad Menu Items and Parameters ‘Current’ Sub-menu of ‘Advanced’ Menu (continued) Shearpin (‘Current’ sub-menu of ‘Advanced’ menu) (P51.B3) Range: P51/B3 Default: On Scaling: n/a Type: R/W The ‘Shearpin’ menu item turns ‘On’ and ‘Off’ the ‘Shearpin’ trip. The ‘Shearpin’ trip is intended to catch transient current peaks which exceed the value specified in the ‘Shearpin Level’...
  • Page 111 Chapter 5: Keypad Menu Items and Parameters ‘Current’ Sub-menu of ‘Advanced’ Menu (continued) Overload Level (‘Current’ sub-menu of ‘Advanced’ menu) (P-34) Range: 0.5 to 1.25 x I Default: 1.0938 x I Scaling: n/a Type: R/W The ‘Start of Overload Level’ parameter holds the level in Amps at which an ‘Overload’ trip will start integrating.
  • Page 112 Chapter 5: Keypad Menu Items and Parameters 5.4.5 – ‘Advanced’ Menu (continued) Opt Rate (P-19) Range: 4 to 30 Default: 5 Scaling: n/a Type: R/W ‘Optimize Rate’ sets the speed at which the SR44 will reduce the voltage during optimizing. Some unstable loads benefit from a slower optimizing rate Optimise + (P121.B4)
  • Page 113 Chapter 5: Keypad Menu Items and Parameters 5.4.5 – ‘Advanced’ Menu (continued) Low Volts Stop (P52.B0) Range: P52 / B0 Default: Off Scaling: n/a Type: R/W This menu item turns ‘On’ or ‘Off’ the ‘Low Voltage Stop’ function. When ‘On’, this allows soft- stop pedestals of less than 40% to be set.
  • Page 114 Chapter 5: Keypad Menu Items and Parameters 5.4.5 – ‘Advanced’ Menu (continued) Cooling (P53.B5) Range: P53 / B5 Default: On Scaling: n/a Type: R/W This menu item turns ‘On’ and ‘Off’ the ‘Cooling’ (Inhibit Restart) function. Once this menu item has been turned ‘On’, and the unit has been started and subsequently stopped, the ‘Cooling’...
  • Page 115 Chapter 5: Keypad Menu Items and Parameters 5.4.5 – ‘Advanced’ Menu (continued) Thermistor Trip (reserved) (P51.B5) Range: P51 / B5 Default: Off Scaling: n/a Type: R/W ‘Thermistor Selected’ – Not Available. P126 Comms Trip (P-126) Range: Off / On Default: Off Scaling: n/a Type: R/W ‘Bus Action on Fail’...

  • Page 116: Monitoring' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.6 – ‘Monitoring’ Menu User-supplied current transformer is required if any of the current- and power-related monitoring features are needed in bypass mode. Refer to Electrical Installation Chapter 2, sections 2.4.1 & 2.5.2 for details. Power –...
  • Page 117 Chapter 5: Keypad Menu Items and Parameters 5.4.6 – ‘Monitoring’ Menu (continued) User-supplied current transformer is required if any of the current- and power-related monitoring features are needed in bypass mode. Refer to Electrical Installation Chapter 2, sections 2.4.1 & 2.5.2 for details. P22 Delay Angle (P-22) Range: 0 to 146.76 degrees...

  • Page 118: Permanent Store' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.7 – ‘Permanent Store’ Menu Save Param – Range: n/a Default: n/a ‘Save Parameters’ saves all the parameter settings to a permanent store. This means that if the control supply is removed from the main control board, the parameters will still remain stored and will be recalled the next time the unit boots up.

  • Page 119: Password' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.8 – ‘Password’ Menu Enter Password (P-5) Range: 0 to 255 Default: 0 Scaling: n/a Type: R/W ‘Password’ is used by the keypad; Keypad sees 0s as no password set. This option enables the user to temporarily unlock a unit by entering a previously set password. When the unit is ‘locked’, the user can read all parameters as usual, but the user cannot write to any parameters.

  • Page 120: Inputs' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.9 – ‘Inputs’ Menu Digital i/p 1 – Range: n/a Default: n/a ‘Digital Input 1’ gives access to the setup parameters for the first programmable input (see section 2.7.2 of Electrical Installation). An example showing how to set up a digital input is given in Appendix A.2.4.

  • Page 121: Outputs' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.10 – ‘Outputs’ Menu – Range: n/a Default: Run Relay The ‘K1’ menu item allows the customer to program the K1 relay (section 2.7.2 of Electrical Installation). At the bottom of the sub-menu is a list of programming shortcuts which will set up the relay for the user.
  • Page 122 Chapter 5: Keypad Menu Items and Parameters 5.4.10 – ‘Outputs’ Menu (continued) – Range: n/a Default: Bypass Relay The ‘K2’ menu item allows the customer to program the K2 relay (section 2.7.2 of Electrical Installation). At the bottom of the sub-menu is a list of programming shortcuts which will set up the relay for the user.

  • Page 123: Parameters' Menu

    Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu dummy parameter Range: 0 to 255 Default: 0 Scaling: 1 Type: R Dummy used for mapping unused bit parameters, etc. No keypad access. Station No Range: 1 – 32 Default: 1 Scaling: 1 Type: R/W...
  • Page 124 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Firing Mode Range: 0 to 1 Default: 0 Scaling: 1 Type: R/W ‘Firing Mode’: • 0 = Normal Motor (outside delta or star/wye) • 1 = Delta (inside delta no optimizing) An in-line isolation contactor controlled by the soft starter MUST be used with the In-Delta Firing Mode and motor connections.
  • Page 125 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Status 2 Range: 0 to 99 (flags) Default: 0 Scaling: 1 Type: R ‘Status 2’ flags – Read this parameter by individual bits. • Bit #: 0: Alarm – starter has detected a Fault and has tripped. 1: Overload Integrating –...
  • Page 126 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Start Ped P-11 Range: 10 to 60 percent Default: 20% Scaling: 1 Type: R/W ‘Start Pedestal’ sets the percentage of the unit’s rated supply voltage that is applied to the load before the ramp starts.
  • Page 127 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Auto Config P-18 Range: 0 to 255 (flags) Default: 6 Scaling: 1 Type: R/W ‘Auto Configuration’ – Set this parameter by individual bits. • Bit #: 0: Auto Ramp – gently ramps voltage to starter; acts somewhat like an automatic current limit. 1: Auto 3MC –...
  • Page 128 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Reference PF P-20 Range: 0 to 146.76 degrees Default: 146.76º Scaling: 0.57554 Type: R ‘Reference PF’ shows the Power Factor Angle that the SR44 has calculated as the target for the optimizing control loop.
  • Page 129 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Peak Start I P-27 Range: 0 to 255 Amps Default: 0A Scaling: 1 Type: R ‘Peak Start Current’ displays the peak current seen by the unit during the last start. Scaling is per the running current.
  • Page 130 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Shear Time P-33 Range: 5 to 255 cycles Default: 100 cycles Scaling: 1 Type: R/W ‘Shearpin Time’ sets the number of cycles a Shearpin Current must be present before tripping. The shearpin is active only during the running phase;...
  • Page 131 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) PF Angle P-39 Range: 0 to 127.5 degrees Default: 0° Scaling: 0.5 Type: R ‘Real Power Factor Angle’ displays the angle by which the sine curve of the voltage in a curcuit leads the sine curve on the current in that circuit.
  • Page 132 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) User Flags 1 P-51 Range: 0 to 255 (flags) Default: 142 Scaling: 1 Type: R/W ‘User Flags 1’ is a set of individual bits for user control or system status. (Other ‘User Flags’...
  • Page 133 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) User Flags 3 P-53 Range: 0 to 255 (flags) Default: 51 Scaling: 1 Type: R/W ‘User Flags 3’ is a second set of individual bits for user control or system status. (Other ‘User Flags’...
  • Page 134 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) K1 Map P-57 Range: 0 to 123 parameter # Default: 52 parameter Scaling: 1 Type: R/W ‘Map K1 To’ holds the parameter # for the internal starter function assigned to drive the K1 relay output.
  • Page 135 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) (reserved) P-67 (reserved) P-68 (reserved) P-69 (reserved) P-70 Cntactor Dly P-71 Range: 100 to 800 milli-seconds Default: 160 ms Scaling: 4 Type: R/W ‘Contactor Delay’. Following a start command, this is the delay allowed for the main incoming contactor to close.
  • Page 136 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) 2nd Last Trp P-74 Range: 0 to 17 trip number Default: 0 Scaling: 1 Type: R ‘2nd Last Trip’ holds the number of the second to last trip. •...
  • Page 137 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) 4th Last Trp P-76 Range: 0 to 17 trip number Default: 0 Scaling: 1 Type: R ‘4th Last Trip’ holds the number of the fourth to last trip. •...
  • Page 138 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) P-78 through P-96 define the 2nd parameter set, which can be used to define a different Start/Stop profile. See appendix A.2.1 (Using An Alternative Parameter Group) for more information. Protection 2 P-78 Range: 0 to 192...
  • Page 139 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Kick Time 2 P-82 Range: 10 to 40 cycles Default: 25 cycles Scaling: 1 Type: R/W ‘Kick Time 2’ – Use with 2nd parameter set. ‘Kick Time 2’ sets the number of cycles for which Kick Ped 2 (P81) is applied, if selected (P95/B0). (P-14 ‘Kick Time’...
  • Page 140 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) AutoConfig 2 P-86 Range: 0 to 255 (flags) Default: 6 Scaling: 1 Type: R/W ‘Auto Configuration 2’ – Use with 2nd parameter set. – Set this parameter by individual bits. •...
  • Page 141 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Low I time 2 P-88 Range: 5 to 255 cycles Default: 50 cycles Scaling: 1 Type: R/W ‘Low Current Time 2’ – Use with 2nd parameter set. ‘Low Current Time 2’ sets the number of cycles for which an Under Current situation must exist before tripping.
  • Page 142 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Ovld Level 2 P-93 Range: 0.5 to 1.25 x I Default: 1.0938 x I Scaling: 0.03125 Type: R/W ‘Start of Overload Level 2’ – Use with 2nd parameter set. ‘Start of Overload Level 2’...
  • Page 143 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) User Flags12 P-95 Range: 0 to 255 (flags) Default: 134 Scaling: 1 Type: R/W ‘User Flags 1, 2’ – Use with 2nd parameter set. ‘User Flags 1, 2’ is a set of individual bits for user control or system status. (Other ‘User Flags’...
  • Page 144 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) U1 I/P srce P-97 Range: 0 to 125 parameter # Default: 0 Scaling: 1 Type: R/W The ‘ipf1_addr’ parameter holds the parameter # for the internal starter input function assigned to drive the P99 internal starter output function.
  • Page 145 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) U2 I/P srce P-101 Range: 0 to 125 parameter # Default: 0 Scaling: 1 Type: R/W The ‘ipf2_addr’ parameter holds the parameter # for the internal starter input function assigned to drive the P103 internal starter output function.
  • Page 146 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) (reserved) P-105 (reserved) P-106 (reserved) P-107 (reserved) P-108 Bypass Upper Limit P-109 Range: 1 to 50 Default: 12 Scaling: 1 Type: R/W Bypass Upper Limit • Associated with P121/B4, Optimize +. «•»...
  • Page 147 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Status 4 P-112 Range: 0 to 255 (flags) Default: 0 Scaling: 1 Type: R ‘Status 4’ flags – Read this parameter by individual bits. • Bit #: 0: 60 Hz – the unit is using 60 Hz parameters. «•»...
  • Page 148 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) (reserved) P-117 (reserved) P-118 (reserved) P-119 Status 5 P-120 Range: 0 to 255 (flags) Default: 0 Scaling: 1 Type: R ‘Status 5’ flags – Read this parameter by individual bits. •...
  • Page 149 Chapter 5: Keypad Menu Items and Parameters 5.4.11 – ‘Parameters’ Menu (continued) Stop Smooth P-122 Range: 1 to 25 Default: 5 Scaling: 1 Type: R/W ‘Auto Soft Stop Smoothing’ is an arbitrary filter to smooth soft stop jitters caused by unstable load. This feature is turned ON or OFF by Bit 2 of Parameter 121.
  • Page 150 Chapter 5: Keypad Menu Items and Parameters 5.4.12 – ‘Trips’ Menu This menu holds all the parameters that are associated with control of the various trips Trips – Range: 0 to 17 trip number Default: 0 The ‘Trips’ sub-menu accesses a trip history of the unit’s last five trips. These trips are recorded automatically, and need no intervention from the user.
  • Page 151 Chapter 5: Keypad Menu Items and Parameters 5.4.12 – ‘Trips’ Menu (continued) ‘Trips’ Sub-menu of ‘Trips’ Menu Last Trip (‘Trips’ sub-menu of ‘Trips’ menu) (P-73) ‘Last Trip’ holds the number of the last trip. 2nd Last Trp (‘Trips’ sub-menu of ‘Trips’ menu) (P-74) ‘2nd Last Trip’...
  • Page 152 Chapter 5: Keypad Menu Items and Parameters 5.4.12 – ‘Trips’ Menu (continued) C/L Time Out (P51.B1) Range: P51 / B1 Default: On Scaling: n/a Type: R/W The ‘C/L Time Out’ menu item turns ‘On’ and ‘Off’ the ‘Current Limit Time Out’ trip. A ‘Current Limit Time Out’...
  • Page 153 Chapter 5: Keypad Menu Items and Parameters 5.5 – Definitions for Chapter 5 Dwell This is the period between ‘Top of Ramp’ and ‘Run’, which is designed to give unstable loads a chance to settle down, and to ensure that they are up to speed. Index Rating The Index Rating defines the duty of the starter.

  • Page 154: Definitions For Chapter 5

    Chapter 5: Keypad Menu Items and Parameters 5.5 – Definitions for Chapter 5 (continued) Static Static, as in static loads. This term refers to loads with no moving parts, so induction motors, linear motors, etc., are non-static loads. An example of a static load would be a resistor bank. Top of Ramp This is the point at which the Soft Starter reaches maximum output voltage.
  • Page 155 HAPTER HAPTER HAPTER ERIAL OMMUNICATIONS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 6.1 – Overview ........6–2 6.2 –...

  • Page 156: Chapter 6: Serial Communications

    Chapter 6: Serial Communications WARNING: The owner, installer, and user are responsible for the correct installation and use of the SR44, and must ensure that only qualified personnel install the SR44. The owner, installer, and user must ensure that the installation, operation and maintenance of the SR44 complies with the relevant Codes of Practice, Regulations, and Statutory Requirements.

  • Page 157: Specifications

    Chapter 6: Serial Communications 6.2 – Quick Start (continued) 5) Function 06 (Write Single Register) Parameters in the SR44 are 8-bit bytes which are written to by 16-bit Modbus words. Only the low byte of the Modbus word in the PLC gets sent to the SR44 parameter. 6) Function 05 (Write Single Coil) This function is used to set or clear a single bit within the Read/Write parameters between 0 through 127.

  • Page 158: Parameter Memory Addresses

    Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses Parameter Memory Addresses Modbus * Parameter Bit #s ** Name / Function 40000 dummy parameter 40001 Station No 40002 Language 40003 Program Type 40004 Software Ver Password 40005 40006 Firing Mode 40007 Protection –...
  • Page 159 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function – – – Status 3 0 (1) Relay K1 Status 1 (2) Relay K2 Status 2 (4) (unused) 40010 3 (8)
  • Page 160 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function 40024 Reserved – Rated Amps (100s) 40025 Reserved – Rated Amps 40026 Current 40027 Peak Start I 40028 Low I Level 40029...
  • Page 161 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function 40048 Reserved – 40049 Reserved – 40050 Reserved – – – – User Flags 1 0 (1) Kickstart 1 (2) Current Limit Timeout Sel'd...
  • Page 162 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function – – – I/O Polarity 0 (1) K1 Polarity 1 (2) K2 Polarity 2 (4) – – (Unused) 40054 3 (8)
  • Page 163 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function 40078 Protection 2 40079 Start Ped 2 40080 Start Time 2 40081 Kick Ped 2 40082 Kick Time 2 40083 Dwell Time 2 40084...
  • Page 164 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function – – – User Flags12 0 (1) Kickstart (2) 1 (2) Current Limit Timeout Sel'd (2) 2 (4) Overload Selected (2) 40095 3 (8)
  • Page 165 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function 40109 Bypass Upper Limit 40110 Bypass Lower Limit 40111 Reserved – – – – Status 4 0 (1) 60 Hz 1 (2) Phase Rotation Sequence...
  • Page 166 Chapter 6: Serial Communications 6.4 – Parameter Memory Addresses (continued) Parameter Memory Addresses (continued) Modbus * Parameter Bit #s ** Name / Function – – – UserFlags 4 0 (1) – – Impact Load 1 (2) (unused) 2 (4) Auto Soft Stop Smoothing 40121 3 (8) Breaker Present...

  • Page 167: Serial Communication To Sr44

    Chapter 6: Serial Communications 6.5 – Serial Communication to SR44 SR44 parameters are stored in 8-bit bytes. Modbus reads the values from the slave as 16-bit words. Therefore two SR44 parameter bytes are packed into each Modbus word. The lowest parameter is in the data High of the word, and the next parameter is in the data Low.

  • Page 168: Reading Holding Registers (Modbus Function 03)

    Chapter 6: Serial Communications 6.5.1 – Reading Holding Registers (Modbus Function 03) This function is used to read a group of up to eight parameters from the SR44. The allowable address range for this function is 0-127 for working parameters and 1000–1127 for offline EEROM parameters.

  • Page 169: Writing Single Coil (Modbus Function 05)

    Chapter 6: Serial Communications 6.5.2 – Writing Single Coil (Modbus Function 05) This function is used to set or clear a single bit within the Read/Write parameters between 0 through 127. (Only the bits within parameters designated as Read/Write can be preset with this function;...

  • Page 170: Writing Single Register (Modbus Function 06)

    Chapter 6: Serial Communications 6.5.3 – Writing Single Register (Modbus Function 06) This function is used to set the value of a single parameter. It differs from the Modbus protocol in that only the data low byte of the query is written to the parameter address. The data high byte is ignored.

  • Page 171: P-124 Offline Commands

    Chapter 6: Serial Communications 6.5.4 – P-124 Offline Commands The SR44 has a mechanism for carrying out common functions, or offline ones which take a long time and require the SR44 to be off and disabled. Commands are carried out by writing various values to a Command Register (parameter 124).

  • Page 172: Read Exception Status (Modbus Function 07) - Starter 01

    Chapter 6: Serial Communications 6.5.5 – Read Exception Status (Modbus Function 07) – Starter 01 This function’s format is per the Modbus standard, but the bits in the value returned have different meanings shown below. This is the quickest of the Modbus functions, and should be used in the context of the SR44 to check if a station is present or check if it is busy.

  • Page 173: Example Plc Communications Programs

    6.7 – Example PLC Communications Programs 6.7.1 – CLICK PLC Example Program This information provided by AutomationDirect.com Technical Support is provided “as is” without a guarantee of any kind. These documents are provided by our Technical Support Department to assist others. We do not guarantee that the data is suitable for your application, nor do we assume any responsibility for them in your application.
  • Page 174 Chapter 6: Serial Communications 6.7.1 – CLICK PLC Example Program (continued) This rung will be performing nearly all the comms with the starter. It will continuously read parameters P8 and P9 (the soft starter is 8-bit based) and the CLICK performs communications by 16-bit words.
  • Page 175 Chapter 6: Serial Communications 6.7.1 – CLICK PLC Example Program (continued) This rung controls the interlocking of the 2 previous comm instructions. Since the Receive instruction is programmed to read continuously, this logic resets the interlock, UNLESS, the CLICK program calls for the Start/Stop Send instruction to be activated. Read Status Read Status Interlock...
  • Page 176 Chapter 6: Serial Communications 6.7.1 – CLICK PLC Example Program (continued) When "Stop PB" C22 is pressed (activated), a value of "8" (Stop) is copied to DS30, and C23 is set. This will activate the Send instruction, which will write the contents of DS30 to P124. Copy Single Stop PB...
  • Page 177 Chapter 6: Serial Communications 6.7.1 – CLICK PLC Example Program (continued) _Port_2_ Enable Time Ready_Flag Comm Control Comm Send (Port3) MODBUS Sending bSC100 bC11 Slave ID bC210 Modbus Function Code Slave Addr 400013 Sending Control Comm Time Comm Control Comm Success Old SoftStart Time Entry Success...
  • Page 178 Chapter 6: Serial Communications 6.7.1 – CLICK PLC Example Program (continued) This rung manipulates the data retrieved (DH10) from the soft starter paramters P11 and P12. Since each Modbus word actually has 2 values (1 in each byte), the data has to be manipulated to put each relevant value in its' own register.

  • Page 179: Irectlogic Plc Example Program

    Chapter 6: Serial Communications 6.7.2 – irectLOGIC PLC Example Program This information provided by AutomationDirect.com Technical Support is provided “as is” without a guarantee of any kind. These documents are provided by our Technical Support Department to assist others. We do not guarantee that the data is suitable for your application, nor do we assume any responsibility for them in your application.
  • Page 180 Chapter 6: Serial Communications 6.7.2 – irectLOGIC PLC Example Program (continued) This rung will be used when the user activates it. Ordinarily, it will only be active for a short period because the user is Starting or Stopping the soft starter. This rung will write the value contained in V6000 to the Command Register (P124).
  • Page 181 Chapter 6: Serial Communications 6.7.2 – irectLOGIC PLC Example Program (continued) When "Stop PB" is pressed, C23 is set and a value of 8 is loaded into V6000, which is the register that is written to P124 of the soft starter. Stop PB Stop SoftStart Command Register...
  • Page 182 Chapter 6: Serial Communications 6.7.2 – irectLOGIC PLC Example Program (continued) Loads the value in V6020 ("Soft Start Time Entry") and converts it to Binary and places the result in V6014. V6014 is the register that holds the value that is written to P12 ("Soft Start Time"). Entry from OIT, Last value of for example.
  • Page 183 Chapter 6: Serial Communications 6.7.2 – irectLOGIC PLC Example Program (continued) Converts the values from P11 and P12 (which are retrieved as a single 16-bit value) into 2 separate BCD values. P11 is "Soft Start Pedestal"; P12 is "Soft Start Time". Since values are stored in bytes, a single Modbus Read will obtain 2 values. This sequence will take the retrieved value, Shift Left by 25 bits to zero out the higher bits, then Shift Right by the same amount to put it back in its original location, convert to BCD, and this leaves the value for P12 and place it in V6012.

  • Page 184: Productivity3000 Plc Example Program

    Chapter 6: Serial Communications 6.7.3 – Productivity3000 PLC Example Program This information provided by AutomationDirect.com Technical Support is provided “as is” without a guarantee of any kind. These documents are provided by our Technical Support Department to assist others. We do not guarantee that the data is suitable for your application, nor do we assume any responsibility for them in your application.
  • Page 185 Chapter 6: Serial Communications 6.7.3 – Productivity3000 PLC Example Program (continued) This rung is always active and Auto-Polls the SoftStarter for Status. The tag “StarterStatusWord16” is converted into Bool tags via the Unpack Bit instruction (located in task “StatusBits”), so we will have a tag dedicated to various status conditions (Stopped, Starting, Current Limit, Alarm, etc.). These Bool tags could be used in ladder to verify operation or to set indicator lights, for example.
  • Page 186 Chapter 6: Serial Communications 6.7.3 – Productivity3000 PLC Example Program (continued) The following rungs are optional, and are included as an example of how to Read and Write to a parameter of the SoftStart. The SoftStart is 8-bit based, so Reads actually return 2 values which have to be separated (shown on the next rung with theShift/Rotate instructions) so we can use them. MODBUS READ In Progress ReadStarterInProg CPU-485...
  • Page 187 Chapter 6: Serial Communications 6.7.3 – Productivity3000 PLC Example Program (continued) This rung compares 1 tag, “SoftStartTimeEntry”, to another tag, “OldSoftStartTime”. This allows the ladder to perform a sequence if the first tag (assumed for example purposes to be coming from an HMI, but can also be changed from Data View). It will Copy the new value to the old value tag, and then start the Write/Read confirmation sequence.
  • Page 188 Chapter 6: Serial Communications BL NK P GE 6–34 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 189 HAPTER HAPTER HAPTER PTIONAL ARDWARE NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Chapter... 7.1 – SR44-RS485 Communication Card ....7–2 7.1.1 –...

  • Page 190: Chapter 7: Optional Hardware

    Chapter 7: Optional Hardware 7.1 – SR44-RS485 Communication Card 7.1.1 – Communication Card General Information An optional RS-485 communication adapter card is available for use with SR44 Soft Starters. • Communication Adapter Part Number: SR44-RS485 • Allows control to be switched between an integral Keypad or alternately through an external isolated network based on the Modbus standard •...

  • Page 191: Connecting The Communication Card

    Chapter 7: Optional Hardware 7.1.2 – Connecting the Communication Card 1) Isolate the SR44 from all electrical power sources. 2) Remove the front cover. 3) For size-2 soft starters (174A & higher), insert the Local/Remote extension cable through the starter and out the plugged hole in the bottom of the unit. Then connect the Local/Remote switch to the extension cable.

  • Page 192: Sr44-Kpd Remote Keypad

    Chapter 7: Optional Hardware 7.2 – SR44-KPD Remote Keypad 7.2.1 – Remote Keypad General Information An optional Remote Keypad is available for use with SR44 Soft Starters. • Remote Keypad Part Number: SR44-KPD • Remote Keypad requires installation of an SR44-RS485 communication card •...

  • Page 193: Connecting The Remote Keypad

    Chapter 7: Optional Hardware 7.2.2 – Connecting the Remote Keypad Remote Keypad requires installation of an SR44-RS485 communication card. 1) The RJ45 cable that is supplied with the remote keypad has two ferrites installed on it to ensure EMC compliance. Plug the end with the thinner ferrite into the Communication Card primary RJ45 socket.
  • Page 194 Chapter 7: Optional Hardware BL NK P GE 7–6 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 195 PPENDIX PPENDIX PPENDIX ETUP XAMPLES NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Appendix... A.1 – Setup Examples ......A–2 A.1.1 –...

  • Page 196: Appendix A: Setup Examples

    Appendix A: Setup Examples A.1 – Setup Examples This section holds common programming examples that any customer might wish to use. They explain how to set up the SR44 for common tasks. More advanced examples are given in section A.2. A.1.1 –...
  • Page 197 Appendix A: Setup Examples A.1.1 – How to Read the Setup Examples (continued) Press the # button to cancel the instruction, or the Enter button to confirm it. 9 Parameter 9 Parameter Press the Up Button multiple times (or scroll) until you reach the next menu item as shown.

  • Page 198: Enabling And Disabling The Sr44

    Appendix A: Setup Examples A.1.2 – Enabling and Disabling the SR44 The effect of this parameter is that the user cannot start the SR44 (running the motor) without enabling the unit first. Whenever the control supply to the SR44 is turned on, the unit powers up in an enabled state, and the display will indicate whether or not the unit is enabled.

  • Page 199: Note For A.1 Setup Examples

    Appendix A: Setup Examples Note for A.1 Setup Examples In the following examples, the default parameters are assumed to have been loaded before the start of the example, unless otherwise stated. This is to provide a common reference point for the instructions. A.1.3 –...

  • Page 200: Changing From 'Keypad Starting' To 'Remote Starting

    Appendix A: Setup Examples A.1.4 – Changing from ‘Keypad Starting’ to ‘Remote Starting’ With ‘Keypad Starting’ set, the unit is started from the keypad or remote keypad. While ‘Remote Starting’ is set, the unit is started with a start signal between S0 and S1. ‘Keypad Starting’ is the factory default value.

  • Page 201: Permanently Saving Parameters Set By The User

    Appendix A: Setup Examples A.1.5 – Permanently Saving Parameters Set by the User Follow this procedure to save parameters set by the customer. This example assumes that the unit has been disabled (see section A.1.2). 1. With ‘Starter Disabled’ shown on the display, press ENTER button. 2.

  • Page 202: Loading The Default Parameter Values With 'Keypad Starting' Optiona-8

    Appendix A: Setup Examples A.1.6 – Loading the Default Parameter Values with ‘Keypad Starting’ Option This example assumes that the unit has been disabled (see section A.1.2). 1. With ‘Starter Disabled’ shown on the display, press the ENTER button. 2. With ‘Applications’ shown on the top line of the display, press the ENTER button again. 3.

  • Page 203: Loading The Default Parameter Values With 'Remote Starting' Optiona-9

    Appendix A: Setup Examples A.1.7 – Loading the Default Parameter Values with ‘Remote Starting’ Option This example assumes that the unit has been disabled (see section A.1.2). 1. With ‘Starter Disabled’ shown on the display, press the ENTER button. 2. With ‘Applications’ shown on the top line of the display, press the button until ‘Permanent Store’...

  • Page 204: Viewing Basic Operating Parameter Values Via The Settings Menu

    Appendix A: Setup Examples A.1.8 – Viewing Basic Operating Parameter Values via the Settings Menu Option 1. With ‘Stopped and Ready’ shown on the display, press the ENTER button. 2. With ‘Applications’ shown on the top line of the display, press the ENTER button again. 3.

  • Page 205: Changing A Password

    Appendix A: Setup Examples A.1.9 – Changing a Password This example assumes that the unit has been disabled (see section A.1.2) and, if necessary, has already been unlocked (see section A.1.10). 1. With ‘Starter Disabled’ displayed, press the ENTER button. 2.

  • Page 206: A.1.10A - Unlocking And Locking The Keypad

    Appendix A: Setup Examples A.1.10a – Unlocking and Locking the Keypad 1. With ‘Stopped and ready’ displayed, press the ENTER button once. 2. With ‘Applications’ shown on the top line of the display, press the button until ‘Password’ takes its place on the top line. 3.

  • Page 207: Using The Pre-Programmed Relay Options

    Appendix A: Setup Examples A.1.11 – Using the Pre-programmed Relay Options This example shows the user how to program any relay on the unit via the pre-programmed options. The option shown in the example below is the ‘Alarm’, but the instructions apply to all of the pre-programmed relay options (see section 5.4.10), and for all of the relays since they are all programmable.

  • Page 208: Setting The Low Amps Level And Using The K2 Relay To Display The Status Of Low Current Bit

    Appendix A: Setup Examples A.1.12 – Setting the Low Amps Level and Using the K2 Relay to Display the Status of Low Current Bit This example shows the user how to set the Low Amps Level, and how to monitor the status of the Low Current bit via the K2 relay (see section 5.4.5).
  • Page 209 Appendix A: Setup Examples A.1.12 – Setting the Low Amps Level and Using the K2 Relay to Display the Status of Low Current Bit (continued) (continued from previous page) 7. With ‘Low Amps Level’ showing on the top line, press the buttons until the required level is set.
  • Page 210 Appendix A: Setup Examples A.1.12 – Setting the Low Amps Level and Using the K2 Relay to Display the Status of Low Current Bit (continued) (continued from previous page) 18. With ‘Map From’ on the top line of the display, press the button.
  • Page 211 Appendix A: Setup Examples A.1.13 – Using the K2 Relay to Mimic Programmable Input 1 This example shows the user how to energize a relay via the start signal. 1. With ‘Stopped and Ready’ shown on the display, press the ENTER button. 2.

  • Page 212: Using The K2 Relay To Mimic Programmable Input 1

    Appendix A: Setup Examples A.1.13 – Using the K2 Relay to Mimic Programmable Input 1 (continued) (continued from previous page) 7. With ‘8 Parameter’ showing, press the button until ‘10 Parameter’ is displayed. 8. Press ENTER to apply the change. 9.

  • Page 213: Advanced Setup Examples

    Appendix A: Setup Examples A.2 – Advanced Setup Examples A.2.1 – Using an Alternative Parameter Group For applications that require the control of two motors, or where the user requires different control characteristics for a single motor at different stages of the duty cycle, the SR44 Soft Starter offers two parameter groups.

  • Page 214: Changing The Parameter Group After The Unit Has Passed Top Of Ramp

    Appendix A: Setup Examples A.2.2 – Changing the Parameter Group After the Unit Has Passed Top of Ramp In this example the user is shown how to change parameter groups while running. This could be useful, for example, if two overload values were required; one for starting and the other for running.
  • Page 215 Appendix A: Setup Examples A.2.2 – Changing the Parameter Group After the Unit Has Passed Top of Ramp (continued) (continued from previous page) 8. With ‘0 Parameter’ shown on the display, press the button until ‘8 Parameter’ is displayed. 9. Press ENTER once to accept the change. 10.
  • Page 216 Appendix A: Setup Examples A.2.2 – Changing the Parameter Group After the Unit Has Passed Top of Ramp (continued) (continued from previous page) 17. Press the button once so that ‘P99 U1 O/P Dest’ is shown at the top of the display. 18.

  • Page 217: (Reserved For Future Use

    Appendix A: Setup Examples A.2.3 – (Reserved for Future Use) A.2.4 – Selecting Optimizing with Programmable Input 1 This example programs the S1 input to turn the Optimizing function Off and On. When the specified voltage is applied to and removed from the S1 input, the energy optimizing function is turned Off and On (note the inverse action).

  • Page 218: Selecting Optimizing With Programmable Input 1

    Appendix A: Setup Examples A.2.4 – Selecting Optimizing with Programmable Input 1 (continued) (continued from previous page) 9. With ‘Map To’ on the top line of the display, press the button once until ‘Bit Number’ is displayed. 10. Press ENTER once to select ‘Bit Number’. 11.
  • Page 219 PPENDIX PPENDIX PPENDIX PPLICATIONS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Appendix... SR44 Applications Data ......B–2...
  • Page 220 Appendix B: Applications Data SR44 Applications Data NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. The ‘Application’ tables show the specific individual settings that are configured by the SR44 ‘Applications’ menu ‘Level 2’ settings. Application Type Default (Keypad) Start Pedestal (%) 20 Stop Pedestal (%) 10...
  • Page 221 Appendix B: Applications Data SR44 Applications Data (continued) Application Type Conveyor Start Pedestal (%) 10 Stop Pedestal (%) 0 Start Time (s) 10 Soft-Stop Time (s) 7 Current Limit Level (x FLC) 3.5 Current Limit Time (s) 30 Auto Jog £ Optimize Rate Auto Pedestal Auto End Start...
  • Page 222 Appendix B: Applications Data SR44 Applications Data (continued) Application Type Screw Compressor Start Pedestal (%) 40 Stop Pedestal (%) 0 Start Time (s) 7 Soft-Stop Time (s) 0 Current Limit Level (x FLC) 7.185 Current Limit Time (s) 25 Auto Jog £ Optimize Rate Auto Pedestal Auto Stop £...
  • Page 223 Appendix B: Applications Data SR44 Applications Data (continued) Application Type High Torque Start Start Pedestal (%) 60 Stop Pedestal (%) 0 Start Time (s) 3 Soft-Stop Time (s) 0 Current Limit Level (x FLC) 4.375 Current Limit Time (s) 12 Auto Jog £...

  • Page 224: Appendix B: Applications Data

    Appendix B: Applications Data BL NK P GE B–6 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 225 PPENDIX PPENDIX PPENDIX ECHNICAL INTS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Appendix... Technical Hints ........C–2 Category: General .

  • Page 226: Appendix C: Technical Hints

    Appendix C: Technical Hints Technical Hints Category: General Motor Configuration Subject: If the motor starts OK but stalls as soon as a load is applied, then check the configuration of the motor, i.e., it may be that the motor is meant to be connected in delta but is actually connected in star (wye). Kick Start Subject: Kick start is not always suitable for use with rolling starts or very light loads.
  • Page 227 Appendix C: Technical Hints Technical Hints (continued) Category: Troubleshooting Reset Trip Subject: Trips can be reset by pressing the ‘#’ key on the keypad, or by changing the Start/Stop I/p to ‘Start’ if control is set to remote. Subject: Load (1) The Soft-Starter will trip (8) if a start is attempted with no motor connected on the output.
  • Page 228 Appendix C: Technical Hints BL NK P GE C–4 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...

  • Page 229: With Sr44 Soft Starters

    SING PPENDIX PPENDIX PPENDIX UTOMATION IRECT S WITH SR44 S TARTERS NOTE: SR44 soft starters have been discontinued. Please consider SR55 soft starters as a replacements. Contents of this Appendix... Compatibility Overview ......D–2 CLICK PLC I/O Compatible with SR44 Soft Starters .

  • Page 230: Compatibility Overview

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters Compatibility Overview • The SR44 control input accepts 12/24 VDC and 115/230 VAC. • The SR44 relay outputs are rated for 230 VAC @ 3A, and 24 VDC @ 3A. The inputs and outputs are compatible with PLC I/O as shown in the following tables. CLICK PLC I/O Compatible with SR44 Soft Starters CLICK PLCs Compatible with SR44 Soft Starters CLICK PLCs...

  • Page 231: Dl05/Dl06 Plc I/O Compatible With Sr44 Soft Starters

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters DL05/DL06 PLC I/O Compatible with SR44 Soft Starters DL05/DL06 PLCs Compatible with SR44 Soft Starters DL05 PLCs D0-05AA 8 AC IN / 6 AC OUT MICRO PLC W/AC P/S D0-05AD 8 AC IN / 6 DC OUT MICRO PLC W/AC P/S D0-05AR 8 AC IN / 6 RELAY OUT MICRO PLC W/AC P/S D0-05DD...

  • Page 232: Dl105 Plc I/O Compatible With Sr44 Soft Starters

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters DL105 PLC I/O Compatible with SR44 Soft Starters DL105 PLCs Compatible with SR44 Soft Starters DL105 PLCs F1-130AA 10 AC INPUT/8 AC OUTPUT 85-265VAC .5A 24VDC F1-130AD 10 AC INPUT/8 DC OUTPUT 85-265VAC .5A 24VDC F1-130AR 10 AC INPUT/8 RELAY OUTPUT F1-130DA...

  • Page 233: Dl305 Plc I/O Compatible With Sr44 Soft Starters

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters DL305 PLC I/O Compatible with SR44 Soft Starters DL305 PLCs Compatible with SR44 Soft Starters DL305 AC I/O D3-04TAS 4PT 110/220VAC ISOLATED OUTPUT D3-08TA-1 8PT 110/220VAC OUTPUT REMOVABLE TERM BLK D3-08TA-2 8PT 110/220VAC OUTPUT NON-REMOVABLE BLOCK D3-16TA-2 16PT 15-220VAC OUTPUT...

  • Page 234: Dl405 Plc I/O Compatible With Sr44 Soft Starters

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters DL405 PLC I/O Compatible with SR44 Soft Starters DL405 PLCs Compatible with SR44 Soft Starters DL405 AC I/O D4-08TA 8PT 18-220VAC OUTPUT D4-16TA 16PT 18-220VAC OUTPUT DL405 DC I/O D4-08TD1 8PT 12-24VDC SINK OUTPUT D4-16TD1 16PT 5-24VDC SINK OUTPUT D4-16TD2...

  • Page 235: Terminator I/O Compatible With Sr44 Soft Starters

    Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters Terminator I/O Compatible with SR44 Soft Starters Terminator I/O Compatible with SR44 Soft Starters Terminator I/O Discrete Output Modules T1H-08TDS 8PT 12-24VDC ISOLATED OUTPUT SINK/SOURCE 8 CMNS T1K-08TA 16PT 17-240VAC OUTPUT T1K-08TAS 8PT 17-240VAC OUTPUT ISOLATED COMMONS T1K-08TD1...
  • Page 236 Appendix D: Using AutomationDirect PLCs with SR44 Soft Starters BL NK P GE D–8 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 237 BL NK P GE SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...
  • Page 238 SR44 Series Soft Starter User Manual 1st Ed, Rev B 07/31/2019...

Table of Contents
