Chapter 3: CPU Specifications and Operations
DL250–1 System V-memory (DL250 also)
1
System
2
V-memory
The default location for multiple preset values for UP/DWN and UP counter 1 or pulse
V3630–V3707
output function
3
V3710–V3767 The default location for multiple preset values for UP/DWN and UP counter 2.
V3770–V3777 Not used
4
V7620–V7627 Locations for DV–1000 operator interface parameters
V7620 Sets the V-memory location that contains the value
V7621 Sets the V-memory location that contains the message
5
V7622 Sets the total number (1 – 32) of V-memory locations to be displayed
V7623 Sets the V-memory location that contains the numbers to be displayed
V7624 Sets the V-memory location that contains the character code to be displayed
V7625 Sets the bit control pointer
6
V7626 Sets the power up mode
V7627 Change Preset Value password
7
Starting location for the multi–step presets for channel 1. Since there are 24 presets
V7630 available, the default range is V3630 – V3707. You can change the starting point if
necessary.
8 Starting location for the multi–step presets for channel 2. Since there are 24 presets
V7631 available, the default range is V3710– V3767. You can change the starting point if
necessary.
V7632 Reserved
9
V7633 Sets the desired mode for the high speed counter, interrupt, pulse catch, pulse train,
and input filter (see the D2-CTRINT manual, D2-CTRIF-M, for more information).
Location is also used for setting the with/without battery option, enable/disable CPU
10
mode change, and power-up in Run Mode option.
11
12
13
Contains set up information for high speed counter, interrupt, pulse catch,pulse train
14 V7634
output, and input filter for X0 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7635
output, and input filter for X1 (when D2–CTRINT is installed).
A
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7636
output, and input filter for X2 (when D2–CTRINT is installed).
B
C
D
3–46
DL205 User Manual, 4th Edition, Rev. B
Description of Contents
Default
Values/Ranges
N/A
N/A
N/A
V0 – V3760
V0 – V3760
1 – 32
V0 – V3760
V0 – V3760
V-memory for X, Y, or C
0,1,2,3,12
Default=0000
Default: V3630
Range: V0 – V3710
Default: V3710
Range: V0 – V3710
Default: 0060
Lower Byte Range:
Range: 0 – None
10 – Up
20 – Up/Dwn.
30 – Pulse Out
40 – Interrupt
50 – Pulse Catch
60 – Filtered Dis.
Upper Byte Range:
Bits 8 – 11, 14–15 Unused
Bit 12: With Batt. installed:
0 = disable BATT LED
1 = enable BATT LED
Bit 13: Power-up in Run
Default: 1006
Default: 1006
Default: 1006
