Auxiliary Functions

Many CPU setup tasks involve the use of Auxiliary (AUX) Functions. The AUX Functions
perform many different operations, including clearing ladder memory, displaying the scan
time, copying programs to EEPROM in the handheld programmer, etc. They are divided into
categories that affect different system parameters. Appendix A provides a description of the
AUX functions.
You can access the AUX Functions from DirectSOFT or from the DL205 Handheld
Programmer. The manuals for those products provide step-by-step procedures for accessing
the AUX Functions. Some of these AUX Functions are designed specifically for the Handheld
Programmer setup, so they will not be needed (or available) with the DirectSOFT package.
The following table shows a list of the Auxiliary functions for the different CPUs and the
Handheld Programmer.
NOTE: The Handheld Programmer may have additional AUX functions that are not supported with the
DL205 CPUs.
AUX Function and
Description
AUX 2* — RLL Operations
21 Check Program
22 Change Reference
23 Clear Ladder Range
24 Clear All Ladders
AUX 3* — V-Memory Operations
31 Clear V Memory
AUX 4* — I/O Configuration
41 Show I/O Configuration
42 I/O Diagnostics
44 Power-up I/O
Configuration Check
45 Select Configuration
46 Configure I/O
AUX 5* — CPU Configuration
51 Modify Program Name
52 Display / Change Calendar X
53 Display Scan Time
54 Initialize Scratchpad
55 Set Watchdog Timer
56 Set CPU Network Address X
57 Set Retentive Ranges
58 Test Operations
59 Bit Override
5B Counter Interface Config.
5C Display Error History
230 240 250–1 260
X X
X
X
Chapter 3: CPU Specifications and Operations
AUX Function and
Description
AUX 6* — Handheld Programmer Configuration
61 Show Revision Numbers
62 Beeper On / Off
65 Run Self Diagnostics
AUX 7* — EEPROM Operations
71 Copy CPU memory to
HPP EEPROM
72 Write HPP EEPROM to CPU
73 Compare CPU to
HPP EEPROM
74 Blank Check (HPP EEPROM) X
75 Erase HPP EEPROM
76 Show EEPROM Type
(CPU and HPP)
AUX 8* — Password Operations
81 Modify Password
82 Unlock CPU
83 Lock CPU
Supported
X Not Supported
- Not Applicable
DL205 User Manual, 4th Edition, Rev. B
230 240 250–1 260 HPP
–
X X X X
X X X X
X X X X
X X X X
X X X X
X X X
X X X X
X X X X
–
–
–
3–15
