Chapter 5: Intelligent Box (IBox) Instructions
On Delay Timer (ONDTMR) (IB-301)
1
On Delay Timer will delay the "turning on" of the Output parameter by the specified
amount of time (up to 99.99 seconds) based on the power flow into the IBox. Once the IBox
230
loses power, the Output is turned off
2
240
immediately. If the power flow turns off
BEFORE the On Delay Time, then the
250-1
3
timer is RESET and the Output is never
260
turned on, so you must have continuous
4
power flow to the IBox for at least the
DS5 Used
specified On Delay Time before the
N/A
HPP
Output turns On.
5
This IBox utilizes a Timer resource
(TMRF), which cannot be used anywhere
6
else in your program.
7
ONDTMR Parameters
• Timer Number: specifies the Timer (TMRF) number which is used by the ONDTMR instruction
8
• On Delay Time (0.01sec): specifies how long the Output will remain on once power flow to the
Ibox is removed
9
• Output: specifies the output that will be delayed "turning on" by the On Delay Time.
10
Timer Number . . . . . . . . . . . . . . . . . . . . . . . . . T
On Delay Time . . . . . . . . . . . . . . . . . . . . . . . . K,V
11
Output . . . . . . . . . . . . . . . . . . . . X, Y, C, GX,GY, B
12
13
14
A
B
C
D
5–250
DL205 User Manual, 4th Edition, Rev. B
(up to 99.99 seconds).
Parameter
DL205 Range
T0-377
K0-9999; See DL205 V-memory map - Data Words
See DL205 V-memory map
