Automationdirect.com DirectLOGIC DL205 Series User Manual page 251

Chapter 5: Standard RLL Instructions - Immediate
Or Immediate (ORI)
1
The Or Immediate connects two contacts in parallel. The
230
status of the contact will be the same as the status of the
240
associated input point at the time the instruction is executed.
2
250-1
The image register is not updated.
260
Or Not Immediate (ORNI)
3
The Or Not Immediate connects two contacts in parallel.
230
The status of the contact will be opposite the status of the
240
4
associated input point at the time the instruction is executed.
250-1
The image register is not updated.
260
5
Operand Data Type
6
Inputs
7
In the following example, when X1 or X2 is on, Y5 will energize.
DS Implied
8
HPP Used
DirectSOFT
9
10
11
12
In the following example, when X1 is on or X2 is off, Y5 will energize.
13
14
DirectSOFT
A
X2
B
C
D
5–34
DL205 User Manual, 4th Edition, Rev. B
X
X1
X2
X1
DL230 Range DL240 Range DL250-1 Range DL260 Range
aaa aaa
0–177 0–477
Y5
OUT
Y5
OUT
X aaa
X aaa
aaa
0–777
Handheld Programmer Keystrokes
$ B
ENT
STR 1
Q I
SHFT
OR 8
GX F
ENT
OUT 5
Handheld Programmer Keystrokes
$ B
ENT
STR 1
R I
SHFT
ORN 8
GX F
ENT
OUT 5
aaa
0–1777
C
ENT
2
C
ENT
2
