Chapter 5: Intelligent Box (IBox) Instructions
Analog Output Module Pointer Setup (ANLGOUT) (IB-461)
1
Analog Output Module Pointer Setup generates the logic to configure the pointer method for
one analog output module on the first PLC scan following a Program to Run transition.
230
2
This IBox determines the data format
240
and Pointer addresses based on the
250-1
CPU type, the Base#, and the Slot#.
3
260
The Output Data Address is the
starting location in user V-memory
4
DS5 Used
where the analog output data values
N/A
HPP will be placed by ladder code or
5
external device, one location for each
output channel enabled.
6 Since this logic only executes on the
first scan, this IBox cannot have any
input logic.
7
ANLGOUT Parameters
8
• Base # (K0-Local): specifies which base the analog module is in
• Slot #: specifies which PLC slot is occupied by the analog module
9
• Number of Output Channels: specifies the number of analog output channels that will be used
• Output Data Format (0-BCD 1-BIN): specifies the format of the analog output data (BCD or
10
Binary)
• Output Data Address: specifies the starting V-memory location that will be used to source the
11
analog output data
12
Base # (K0-Local) . . . . . . . . . . . . . . . . . . . . . . . K
13
Slot # . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . K
Number of Output Channels . . . . . . . . . . . . . . . K
Output Data Format (0-BCD 1-BIN). . . . . . . . . . K
14
Output Data Address . . . . . . . . . . . . . . . . . . . . . V
A
B
C
D
5–236
DL205 User Manual, 4th Edition, Rev. B
Parameter DL205 Range
K0-3
K0-7
K1-8
BCD: K0; Binary: K1
See DL205 V-memory map - Data Words
