DL240 System V-memory

System
V-memory
V3630–V3707 The default location for multiple preset values for UP/DWN and UP counter 1 or pulse
output function.
V3710–V3767 The default location for multiple preset values for UP/DWN and UP counter 2.
V3770–V3773 Not used
V3774–V3777 Default locations for analog potentiometer data (channels 1–4, respectively).
V7620–V7627 Locations for DV–1000 operator interface parameters
V7620 Sets the V-memory location that contains the value.
V7621 Sets the V-memory location that contains the message.
V7622 Sets the total number (1 – 16) of V-memory locations to be displayed.
V7623 Sets the V-memory location that contains the numbers to be displayed.
V7624 Sets the V-memory location that contains the character code to be displayed.
V7625 Sets the bit control pointer
V7626 Power Up Mode
V7627 Change Preset Value Password.
Starting location for the multi–step presets for channel 1. Since there are 24 presets
V7630 available, the default range is V3630 – V3707. You can change the starting point if
necessary.
Starting location for the multi–step presets for channel 2. Since there are 24 presets
V7631 available, the default range is V3710– V3767. You can change the starting point if
necessary.
Contains the baud rate setting for Port 2. You can use AUX 56 (from the Handheld
Programmer) or, use DirectSOFT to set the port parameters if 9600 baud is
unacceptable. Also allows you to set a delay time between the assertion of the RTS
signal and the transmission of data. This is useful for radio modems that require a
V7632
key-up delay before data is transmitted.
e.g. a value of 0302 sets 10ms Turnaround Delay (TAD) and 9600 baud.
Chapter 3: CPU Specifications and Operations
Description of Contents
DL205 User Manual, 4th Edition, Rev. B
Default
Values/Ranges
N/A
N/A
N/A
Range: 0 – 9999
V0 – V3760
V0 – V3760
1 – 16
V0 – V3760
V0 – V3760
V-memory location for
X, Y, or C points used.
0,1,2,3,12
Default=0000
Default: V3630
Range: V0 – V3710
Default: V3710
Range: V0 – V3710
Default: 2 – 9600 baud
Lower Byte = Baud Rate
Lower Byte Range:
00 = 300
01 = 1200
02 = 9600
03 = 19.2K
Upper Byte = Time Delay
Upper Byte Range:
01 = 2ms
02 = 5ms
03 = 10ms
04 = 20ms
05 = 50ms
06 = 100ms
07 = 500ms
