F2–16TD2P, DC Output with Fault Protection
NOTE: Not supported in D2-230, D2-240
and D2-250 CPUs.
NOTE: Supporting Firmware:
D2-250-1 must be V4.80 or later
D2-260 must be V2.60 or later
NOTE: This module does not currently
support Think & Do 8.0. It does not
support Think & Do Live! or Studio.
Points
16
12
8
4
0
0 10 20 30 40
32 50 68 86 104 122
Ambient Temperature (°C/°F)
12–24VDC
0
L
L
1
L
L
2
L
L
3
L
L
24V
24VDC
+
0
L
L
1
L
L
2
L
L
3
L
L
24VDC
– +
24V
Reg
0V
Optical
Isolator
12–24VDC
V1
OUTPUT
L
Chapter 2: Installation, Wiring and Specifications
Derating Chart
OUT 12-24
VDC
A
50 55°C
0 4
131°F
1 5
2 6
V1
3 7
B
4 F2–16TD2P
5
10.2-26.4
VDC 0.25A
CLASS2
6
A
V1
0
7
4
1
0V
5
2
6
4
3
7
24V
5
0V
0
4
6
1
5
7
2
6
3
7
B
When the A/B switch is in the A position,
the LEDs display the output status of the
module's first 8 output points. Positon B
displays the output status of the mod-
ule's second group of 8 output points.
DL205 User Manual, 4th Edition, Rev. B
F2-16TD2P DC Output with Fault Protection
Inputs per module
16 (status indication)
Outputs per module
16 (current sourcing)
Commons per module 1
Output type
NMOS FET (open source)
Operating voltage
10.2 -26.4 VDC, external
Peak voltage
40 VDC
AC frequency
N/A
ON voltage drop
0.7 V (output current 0.5 A)
Overcurrent trip
0.6 A min., 1.2A max.
0.25 A continuous, 0.5 A
Maximum load current
peak
Jumper J6 installed: 200 A;
Maximum OFF current
J6 removed: 30 A
Base power required 5V 70 mA
OFF to ON response
0.5 ms
ON to OFF response
0.5 ms
Terminal type
Removable (D2-16IOCON)
Status indicators
Logic Side
Weight
2.0 oz. (25g)
Fuses
None
24 VDC e/ 10% @ 50 mA
External DC required
External DC overvoltage
27 V, outputs are restored
shutdown when voltage is within limits
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
2–41
