ECOM100# . . . . . . . . . . . . . . . . . . . . . . . . . . . . K
Workspace . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
Success . . . . . . . . . . . . . . . . . . . . X,Y,C,GX,GY,B
Error . . . . . . . . . . . . . . . . . . . . . . . X,Y,C,GX,GY,B
Error Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . V
To: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Subject:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Body:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
ECEMAIL Example
Rung 1: The ECOM100 Config IBox is responsible for coordination/interlocking of all
ECOM100 type IBoxes for one specific ECOM100 module. Tag the ECOM100 in slot 1 as
ECOM100# K0. All other ECxxxx IBoxes refer to this module # as K0. If you need to move
the module in the base to a different slot, then you only need to change this one IBox. V400
is used as a global result status register for the other ECxxxx IBoxes using this specific
ECOM100 module.V401 is used to coordinate/interlock the logic in all of the other ECxxxx
IBoxes using this specific ECOM100 module. V402-V502 is a common 130 byte buffer
available for use by the other ECxxxx IBoxes using this specific ECOM100 module.
1
NOTE: An ECOM100 IBox instruction is used without a permissive contact. The top line will be identified in
BOLD italics, and the instruction name and ID will be in BOLD characters.
Chapter 5: Intelligent Box (IBox) Instructions
Parameter
(example continued on next page)
DL205 User Manual, 4th Edition, Rev. B
DL205 Range
K0-255
See DL205 V-memory map - Data Words
See DL205 V-memory map
See DL205 V-memory map
See DL205 V-memory map
Text
Text
See PRINT and VPRINT instructions
ECOM100 Config
ECOM100
ECOM100#
Slot
Status
Workspace
Msg Buffer (65 WORDs)
1
2
3
4
5
6
7
8
9
IB-710
10
K0
K1
V400
11
V401
V402-502
12
13
14
A
B
C
D
5–281
