DL260 System V-memory

System
V-memory
The default location for multiple preset values for UP/DWN and UP counter 1 or
V3630–V3707
pulse output function
V3710–V3767 The default location for multiple preset values for UP/DWN and UP counter 2
V3770–V3777
Not used
V7620–V7627
Locations for DV–1000 operator interface parameters
V7620
Sets the V-memory location that contains the value
V7621
Sets the V-memory location that contains the message
V7622
Sets the total number (1 – 32) of V-memory locations to be displayed
V7623 Sets the V-memory location that contains the numbers to be displayed
Sets the V-memory location that contains the character code to be displayed
V7624
Sets the bit control pointer
V7625
Sets the power up mode
V7626
Change Preset Value password
V7627
Starting location for the multi–step presets for channel 1. Since there are 24
V7630 presets available, the default range is V3630 – V3707. You can change the
starting point if necessary.
Starting location for the multi–step presets for channel 2. Since there are 24
V7631 presets available, the default range is V3710– V3767. You can change the starting
point if necessary.
V7632 Reserved
V7633 Sets the desired mode for the high speed counter, interrupt, pulse catch, pulse
train, and input filter (see the D2-CTRINT manual, D2-CTRIF-M, for more
information). Location is also used for setting the with/without battery option,
enable/disable CPU mode change, and power-up in Run Mode option.
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7634
train output, and input filter for X0 (when D2–CTRINT is installed)
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7635
train output, and input filter for X1 (when D2–CTRINT is installed)
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7636
train output, and input filter for X2 (when D2–CTRINT is installed)
Chapter 3: CPU Specifications and Operations
Description of Contents
DL205 User Manual, 4th Edition, Rev. B
Default Values/Ranges
N/A
N/A
N/A
V0 – V3760
V0 – V3760
1 – 32
V0 – V3760
V0 – V3760
V-memory for X, Y, or C
0,1,2,3,12
Default=0000
Default: V3630
Range: V0 – V3710
Default: V3710
Range: V0 – V3710
Default: 0060
Lower Byte Range:
Range: 0 – None
10 – Up
20 – Up/Dwn
30 – Pulse Ou
40 – Interrupt
50 – Pulse Catch
60 – Fltered Dis.
Upper Byte Range
Bits 8 – 11, 14–15 Unused
Bit 12: With Batt. installed:
0 = disable BATT LED
1 = enable BATT LED
Bit 13: Power-up in Run
Default: 1006
Default: 1006
Default: 1006
3–49
