Chapter 3: CPU Specifications and Operations
System
1 V-memory
V7633 Sets the desired mode for the high speed counter, interrupt, pulse catch, pulse train,
and input filter (see the D2-CTRINT manual, D2-CTRIF-M, for more information).
Location is also used for setting the with/without battery option, enable/disable CPU
2
mode change
3
4
5
6
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7634
7
output, and input filter for X0 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7635
output, and input filter for X1 (when D2–CTRINT is installed).
8
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7636
output, and input filter for X2 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse train
V7637
output, and input filter for X3 (when D2–CTRINT is installed).
9
V7640–V7641 Location for setting the lower and upper limits for the CH1 analog pot.
10
V7642–V7643 Location for setting the lower and upper limits for the CH2 analog pot.
V7644–V7645 Location for setting the lower and upper limits for the CH3 analog pot.
11
V7646–V7647 Location for setting the lower and upper limits for the CH4 analog pot.
V7650–V7737 Locations reserved for setup information used with future options (remote I/O and data communications)
12
Locations for DV–1000 operator interface parameters.
V7720–V7722
Titled Timer preset value pointer
V7720
13
V7721 Titled Counter preset value pointer
V7722
HiByte-Titled Timer preset block size, LoByte-Titled Counter preset block size
V7746 Location contains the battery voltage, accurate to 0.1V. For example, a value of 32 indicates 3.2 volts
14
V7747 Location contains a 10ms counter. This location increments once every 10ms..
Fault Message Error Code — stores the 4-digit code used with the FAULT instruction when the instruction is
A V7751 executed. If you've used ASCII messages (DL240 only) then the data label (DLBL) reference number for that
message is stored here.
V7752 I/O configuration Error — stores the module ID code for the module that does not match the current config.
B
C
D
3–44
DL205 User Manual, 4th Edition, Rev. B
Description of Contents
Default
Values/Ranges
Default: 0000
Lower Byte Range:
0 – None
10 – Up
20 – Up/Dwn.
30 – Pulse Out
40 – Interrupt
50 – Pulse Catch
60 – Filtered Dis.
Upper Byte Range:
Bits 8 – 11, 15 Unused
Bit 12: With Batt. installed:
0 = disable BATT LED
1 = enable BATT LED
Bit 13: Power-up in Run
Bit 14: Mode chg. enable
(K-sequence only)
Default: 0000
Default: 0000
Default: 0000
Default: 0000
Default: 0000
Range: 0 – 9999
Default: 0000
Range: 0 – 9999
Default: 0000
Range: 0 – 9999
Default: 0000
Range: 0 – 9999
V2000–V2377
V2000–V2377
1–99
