Module Placement

Slot Numbering
The DL205 bases each provide different
numbers of slots for use with the I/O
modules. You may notice the bases refer to
3-slot, 4-slot, etc. One of the slots is
dedicated to the CPU, so you always have
one less I/O slot. For example, you have five
I/O slots with a 6-slot base. The I/O slots
are numbered 0 – 4. The CPU slot always
contains a CPU or a base controller (EBC)
or Remote Slave and is not numbered.
Module Placement Restrictions
The following table lists the valid locations for all types of modules in a DL205 system.
Module/Unit
CPUs
DC Input Modules
AC Input Modules
DC Output Modules
AC Output Modules
Relay Output Modules
Analog Input and Output Modules
Local Expansion
Base Expansion Unit
Base Controller Module
Serial Remote I/O
Remote Master
Remote Slave Unit
Ethernet Remote Master
Ethernet Slave (EBC)
CPU Interface
Ethernet Base Controller
WinPLC
DeviceNet
Profibus
SDS
Specialty Modules
Counter Interface (CTRINT)
Counter I/O (CTRIO)
Data Communications
Ethernet Communications
BASIC CoProcessor
Simulator
Filler
*When used in H2–ERM(100) Ethernet Remote I/O systems.
Chapter 4: System Design and Configuration
Power Wiring
Connections
Local CPU Base Local Expansion Base
CPU Slot Only
CPU Slot Only
(not Slot O)
(not Slot O)
CPU Slot Only
CPU Slot Only
CPU Slot Only
CPU Slot Only
CPU Slot Only
CPU Slot Only
Slot 0 Only
(not Slot O)
(not Slot O)
(not Slot O)
DL205 User Manual, 4th Edition, Rev. B
Slot 0 Slot 1 Slot 2 Slot 3 Slot 4
CPU Slot
I/O Slots
Remote I/O Base
CPU Slot Only
CPU Slot Only*
*
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
