MWX Slave Memory Address

Function Code
05 – Force Single Coil
05 – Force Single Coil
06 – Preset Single Register
06 – Preset Single Register
15 – Force Multiple Coils
15 – Force Multiple Coils
16 – Preset Multiple Registers
16 – Preset Multiple Registers

MWX Master Memory Addresses

Operand Data Type
Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Relays . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stage Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Timer Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Counter Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Special Relays. . . . . . . . . . . . . . . . . . . . . . . . . . . .
V–memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Global Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Global Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . .

MWX Number of Elements

Operand Data Type
V–memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Constant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

MWX Exception Response Buffer

Operand Data Type
V–memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 4: System Design and Configuration
MWX Slave Address Ranges
Modbus Data Format
484 Mode
584/984 Mode
484 Mode
584/984 Mode
484
584/984 Mode
484 Mode
584/984 Mode
MRX Master Memory Address Ranges
X 0–1777
Y 0–1777
C 0–3777
S 0–1777
T 0–377
CT 0–377
SP 0–777
V All (see page 3-56)
GX 0–3777
GY 0–3777
Number of Elements
V All (see page 3-56)
K Bits: 1–2000 Registers: 1-125
Exception Response Buffer
V All (see page 3-56)
DL205 User Manual, 4th Edition, Rev. B
Slave Address Range(s)
1–999
1–65535
4001–4999
40001–49999 (5 digit) or
400001–465535 (6 digit)
1–999
1–65535
4001–4999
40001–49999 (5 digit) or
4000001–465535 (6 digit)
DL260 Range
DL260 Range
DL260 Range
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
4–51
