D2-16NA, AC Input

D2-16NA AC Input
Inputs per Module
Commons per Module
Input Voltage Range
Peak Voltage
ON Voltage Level
OFF Voltage Level
AC Frequency
Input Impedance
Input Current
Minimum ON Current
Maximum OFF Current
Base Power Required 5VDC
OFF to ON Response
ON to OFF Response
Terminal Type (included)
Status Indicator
Weight
Derating Chart
Points
16
12
8
4
0
0 10 20 30 40
32 50 68 86 104
Ambient Temperature (˚C/˚F )
110 VAC
CA
0
4
1
5
2
6
3
7
NC
110 VAC
CB
0
4
1
5
2
6
3
7
Internal module circuitry
INP UT
COM
110 VAC
Chapter 2: Installation, Wiring and Specifications
16
2 (isolated)
80-132 VAC
132 VAC
70 VAC minimum
20 VAC maximum
47-63 Hz
12 k @ 60 Hz
11 mA @ 100 VAC, 50 Hz
13 mA @ 100 VAC, 60 Hz
15 mA @ 132 VAC, 60 Hz
5 mA
2 mA
100 mA
5 to 30 ms
10 to 50 ms
Removable; D2-16IOCON
Logic side
2.4 oz. (68g)
IN 110
VAC
A
0 4
1 5
50 55 C ˚
2 6
122131 F ˚
3 7
B
D2--16NA
80- - 132VAC
10- - 20mA
50/60Hz
CA
0
4
1
5
2
6
3
7
NC
CB
0
4
1
5
2
6
3
7
V+
D2--16NA
To LE D
Optical
Is olator

F2-08SIM, Input Simulator

F2-08SIM Input Simulator
Inputs per Module
Base Power Required 5VDC
Terminal Type
Status Indicator
Weight
IN
F 2--08SI M
DL205 User Manual, 4th Edition, Rev. B
8
50 mA
None
Switch side
2.65 oz. (75 g)
SIM
0 4
1 5
2 6
3 7
0
ON
>
1
2
3
4
5
6
7
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
