CPU Setup Information

Even if you have years of experience using PLCs, there are a few things you need to do before
you can start entering programs. This section includes some basic things, such as changing
the CPU mode, but it also includes some things that you may never have to use. Here's a brief
list of the items that are discussed:
• Using Auxiliary Functions
• Clearing the program (and other memory areas)
• How to initialize system memory
• Setting retentive memory ranges
The following paragraphs provide the setup information necessary to get the CPU ready for
programming. They include setup instructions for either type of programming device you are
using. The D2–HPP Handheld Programmer Manual provides the Handheld keystrokes
required to perform all of these operations. The DirectSOFT Manual provides a description
of the menus and keystrokes required to perform the setup procedures via DirectSOFT.
Chapter 3: CPU Specifications and Operations
Status Indicators
PWR
RUN
BATT
CPU
Port 1
DL230
CPU
PORT1
Status Indicators
DL250-1
Mode Switch
Port 1
Port 2
Battery Slot
DL205 User Manual, 4th Edition, Rev. B
PWR
RUN
BATT
CPU
DL240
RUN
CPU
TERM
CH1
CH2
CH3
CH4
PORT 1
Port 2
PORT? 2
DL260
1
Mode Switch
2
3
Analog
Adjustments
4
5
6
7
8
9
10
11
12
13
14
A
B
C
D
3–11
