DL230 System V-memory

System
V-memory
V2320–V2377 The default location for multiple preset values for the UP counter.
V7620–V7627 Locations for DV–1000 operator interface parameters
V7620 Sets the V-memory location that contains the value.
V7621 Sets the V-memory location that contains the message.
V7622 Sets the total number (1 - 16) of V-memory locations to be displayed.
V7623 Sets the V-memory location that contains the numbers to be displayed.
V7624 Sets the V-memory location that contains the character code to be displayed.
V7625 Sets the bit control pointer.
V7626 Power Up mode change preset value password.
V7627 Reservered for future use.
V7630
Starting location for the multi–step presets for channel 1. The default value is
2320, which indicates the first value should be obtained from V2320. Since
there are 24 presets available, the default range is V2320 – V2377. You can
change the starting point if necessary.
V7631–V7632 Not used
V7633 Sets the desired mode for the high speed counter, interrupt, pulse catch, pulse
train, and input filter (see the D2-CTRINT Manual, D2-CTRIF-M for more
information). Location is also used for setting the with/without battery option,
enable/disable CPU mode change, and power-up in Run Mode option.
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7634
train output, and input filter for X0 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7635
train output, and input filter for X1 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7636
train output, and input filter for X2 (when D2–CTRINT is installed).
Contains set up information for high speed counter, interrupt, pulse catch, pulse
V7637
train output, and input filter for X3 (when D2–CTRINT is installed).
V7640–V7642 Additional setup parameters for the DV-1000
V7640 Timer preset value pointer
V7641 Counter preset value pointer
V7642 Timer preset block size (high byte) / Counter preset block size (low byte)
V7643–V7647 Not used
Fault Message Error Code — stores the 4-digit code used with the FAULT
V7751
instruction when the instruction is executed.
Chapter 3: CPU Specifications and Operations
Description of Contents
DL205 User Manual, 4th Edition, Rev. B
Default Values/Ranges
N/A
V0 – V2377
V0 - V2377
1 - 16
V0 - V2377
V0 - V2377
V-memory location for
X,Y, or C points used.
0,1,2,3,12 Default = 0000
Default: V2320
Range: V0 – V2320
N/A
Default: 0000
Lower Byte Range:
Range: 0 – None
10 – Up
40 – Interrupt
50 – Pulse Catch
60 – Filtered discrete In.
Upper Byte Range:
Bits 8 – 11, 14,15: Unused
Bit 12: With Batt. installed:
0 = disable BATT LED
1 = enable BATT LED
Bit 13: Power-up in Run
Default: 0000
Default: 0000
Default: 0000
Default: 0000
V2000 - V2377
V2000 - V2377
1 - 99
N/A
N/A
3–41
