Chapter 4: System Design and Configuration
Ethernet Base Controller, H2-EBC(100)(-F)
1
The Ethernet Base Controller module, H2-EBC(100)(-F) provides a low-cost, high-
performance Ethernet link between a network master controller and an DirectLOGIC PLC
I/O slave system. Also, the H2-EBC100 supports the Modbus TCP/IP client/server protocol.
2
The Ethernet Base Controller (EBC) serves as an interface between the master control system
and the DL205/405 I/O modules. The control function is performed by the master
3
controller, not the EBC slave. The EBC occupies the CPU slot in the base and communicates
across the backplane to input and output modules. Various master controllers with EBC
4
slaves are shown in the diagram below.
5
6
7
8
9
10
11
12
13
The H2-EBC module supports industry standard 10BaseT Ethernet communications, the
H2-EBC100 module supports industry standard 10/100BaseT Ethernet communications and
14
the H2-EBC-F module supports 10BaseFL (fiber optic) Ethernet standards.
A
Communications
Data Transfer Rate
B
Link Distance
Ethernet Port
C
Ethernet Protocols
Serial Port
D
Serial Protocols
Power Consumption
4–22
DL205 User Manual, 4th Edition, Rev. B
Example EBC Systems: Various Masters with EBC Slaves
Modbus TCP/IP Masters
(H2-EBC100 only)
All H2/H4 Series EBCs
UDP/IP, IPX
10Mbps
H2-EBC100
TCP/IP, UDP/IP, IPX
Modbus TCP/IP
10/100Mbps
Specifications
10BaseT Ethernet
10Mbps max.
100 meters (328 ft)
K-Sequence, ASCII
450mA @ 5VDC
DirectLOGIC PLC/
WinPLC with ERM
OR
OR
Ethernet
Hub
H2-EBC H2-EBC100
10/100BaseT Ethernet
100Mbps max.
100 meters (328 ft)
RJ45
TCP/IP, IPX/Modbus TCP/IP,
TCP/IP, IPX
DHCP, HTML configuration
RJ12
K-Sequence, ASCII IN/OUT,
IN/OUT Modbus RTU
300mA @ 5VDC
PC-based Control System
EBC
Serial HMI
EBC
EBC
H2-EBC-F
10BaseFL Ethernet
10Mbps max.
2000 meters (6560 ft)
RJ45 ST-style fiber optic
TCP/IP, IPX
RJ12 None
None
640mA @ 5VDC
