AND Bit-of-Word (ANDB)
The And Bit-of-Word instruction logically ands a
230
normally open contact in series with another contact in
240
a rung. The status of the contact will be the same state
250-1
as the bit referenced in the associated memory location.
260
And Not Bit-of-Word (ANDNB)
The And Not Bit-of-Word instruction logically ands a
230
normally closed contact in series with another contact in
240
a rung. The status of the contact will be opposite the
250-1
state of the bit referenced in the associated memory
260
location.
Operand Data Type
V-memory
Pointer
In the following And Bit-of-Word example, when input X1 and bit 4 of V1400 is on output
DS Implied
HPP Used
Y5 will energize.
In the following And Not Bit-of-Word example, when input X1 is on and bit 4 of V1400 is
off output Y5 will energize.
DL250-1 Range
aaa
A
B See memory map
page 3-55
PB See memory map
page 3-55
DirectSOFT
X1 B1400.4
Handheld Programmer Keystrokes
STR 1
AND SHFT B
4
K
OUT 5
DirectSOFT
X1 B1400.4
Handheld Programmer Keystrokes
STR 1
ANDN SHFT B
4
K
OUT 5
